Cateye Rapid mini TL-LD635-R Bruksanvisning
Les nedenfor 📖 manual på norsk for Cateye Rapid mini TL-LD635-R (2 sider) i kategorien Lettelse. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/2
ø
21.5 – 32 mm
Always charge the product before use.
TL-LD635-R
Manual
RAPID
mini
Approx. 2 h
(USB 2.0)
Before using the light, read this manual
thoroughly and keep it for future reference.
ENG
Design Pat. Pending
Copyright© 2018 CATEYE Co., Ltd.
LD635R-180221 7
HOW TO CHARGE
SWITCH OPERATION
1
HOW TO MOUNT
2
3
(SP-14-R)
Light unit Bracket Bracket rubber pad
Bracket
rubber pad
Rubber band USB cable
(MICRO USB)
USB cable
To PC or USB battery charger
Charging Charging is
completed
Standard charging time
Switch (Indicator)
1
2
Attach securely in the mounting position.
Bracket
Rubber band OPTION :
WHEN USING THE CLIP
Clip
Click Lighting mode switch
Group Ride
Press and hold ON OFF
Approx. 20 h
Constant
Approx. 3 h
Rapid
Approx. 5 h
Flashing
Approx. 30 h
Automatic battery-saving function
When the remaining battery power
is low, the lighting mode switch
starts flashing and the lighting
mode changes to flash. Charge the
light as soon as possible.
1
3
2
2
1
44
or
WARNING!!!
• Check periodically to ensure that the light unit
is attached securely. Do not use a damaged
rubber band.
•
Always attention to the remaining battery power
by checking the indicator periodically while using.
CAUTION!
• Stop your bicycle to operate the switch.
• Do not place it within children’s reach.
• This unit is not totally waterproof. Please wipe
and dry it completely after using in rain.
Otherwise, it may cause failure.
• If the light unit or parts become dirty with mud,
etc., clean with a soft cloth which is moistened
with mild soap. Never apply paint thinner,
benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mAh (USB2.0)
USB battery charger.
• Avoid charging in direct sunlight or in a
vehicle parked under direct sunlight, and
make sure to charge only when the ambient
temperature is between 41°F and 104 °F (5
and 40°C).
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
• Do not subject the light to vibrations while
charging.
• When your PC is in sleep state, the unit
cannot be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging time is approximate values, and will
vary depending on the environmental and
usage conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place the
light inside a vehicle or near a heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service
life. Dispose of the battery as described in
“Cautions for dispose”.
Cautions on storage
Cool and dry storage is recommended. For long
period storage, it is important to charge the
battery 30 minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the
internal rechargeable battery and dispose of it
according to local regulations.
LIMITED WARRANTY
2-year Warranty: Light unit only
(excludes battery deterioration)
CatEye products are warranted to be free of defects from
materials and workmanship for a period of 2 years from
original purchase. If the product fails to work during normal
use, CatEye will repair or replace the defect at no charge.
Service must be performed by CatEye or an authorized retailer.
To return the product, pack it carefully and enclose the
warranty certificate (proof of purchase) with instruction for
repair. Please write or type your name and address clearly on
the warranty certificate. Insurance, handling and transportation
charges to CatEye shall be borne by person desiring service.
For UK and REPUBLIC OF IRELAND consumers, please return to
the place of purchase. This does not affect your statutory rights.
SPARE / OPTIONAL PARTS
Battery : Li-ion3.7v 320mAh
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times:
About 300 times (until the rated
capacity drops to 70%)
Dimensions/weight : 2-1/16” x 25/32” x 1-1/4” (52.2 x 20
x 31.6 mm) / 0.76 oz (21.5 g)
* The specifications and design are subject to change
without notice.
5342450 5342730
SPECIFICATIONS
(MICRO USB)
5342460
Bracket USB cable Clip
(C-2)
(SP-14-R)
2-8-25, Kuwazu, Higashi
Sumiyoshi-ku, Osaka 546-0041 Japan
Attn: CATEYE Customer Service
Section
Phone : (06)6719-6863
Fax : (06)6719-6033
E-mail : support@cateye.co.jp
URL : http://www.cateye.com
CO.,LTD.
[For US Customers]
CATEYE AMERICA, INC.
2825 Wilderness Place Suite 1200,
Boulder CO 80301-5494 USA
Phone : 303.443.4595
Toll Free : 800.5.CATEYE
Fax : 303.473.0006
E-mail : service@cateye.com
