All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
®
ASSEMBLY INSTRUCTION MODEL #FAR-6006-AG
WARNING: This product can expose you to Lead,
which is known to the State of California to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65Warnings.ca.gov
How to Install
18"
24.6"
16.6"
24.6"
7.6" 1.Screw one end of onto the light cluster.center stem
Pass the other end of it through the top cap and secure
with hex nut.
2.Place the check ring over the hex nut on the lower frame
and screw one end of the onto the lowertop hanging rod
frame. Pass the other end of the throughtop hanging rod
the top cap and secure with hex nut and washer.
7.Install the frame onto the outlet box.
8.Insert the glass rod into the frame.
5.Decide the preferred hanging height and choose the
chain needed.
6.Follow the safety cable installation step below.
Installation of safety cable
1.Pass the long threaded pipe on the hickey through the
center of outlet box. Attach it to the ceiling joist and
secure it with nuts.
2.Feed wires and safety cable up through chain and the
hole of screw collar loop. Have the wires and safety
cable exit through the side of hickey.
3.Feed safety cable through the cable lock and coil it around the
hickey twice then feed the cable through the lock again and
tighten it with lock screw.
4.Continue to run safety cable through the top of outlet box and
secure it to the ceiling joist.
3.Place the check ring over the hex nut on the upper frame
and screw one end of the lower hanging rod onto the
upper frame. Pass the other end of the lower hanging rod
through the top cap and secure with hex nut and washer.
4.Place the metal plate over the top cap and secure with the loop.
9 "5
Crystorama.com
Part Number
Part Numbers
PART NUMBER MODEL #FAR-6006-AG
C
B
D
E
F
G
J
K
L
N
H
P
R
Q
A.Mounting Hardware
(3)Wire Nut
(3)Wall anchor
(1)Mounting Plate
(2)Steel wire rope
I
O
M
Glass rod
Ø1.5"
4"
A
Crystorama.com
S
(1)Green Ground Screw
B.(1)Screw Collar Loop
C.(1)Canopy;Ø5.5″x1.2″h;XMO6006AGCAN5.5IN
D.(1)Collar Ring
E.(2)Quick Link
F.(1)Chain;72″Lx Ø6.0mmT;XMO6006AGCHA6.0MM
G.(1)Top Loop
H.(1)Metal plate
I.(6)Hex nut and washer
J.(1)Top cap
K.(3) Top Hanging Rod;Ø0.5"x14";XMO6006AGHROD14IN
L.(1)Center stem;Ø0.5"x14.3";XMO6006AGCSTEM14.3IN
M.(6)Check ring
N.(1)Lower frame
O.(1)Light cluster
P.(3)Lower Hanging Rod; 0.5"x13"XMO6006AGHROD13INØ
Q.(63)Glass rod;1.5"Wx4"H;XMO6000GLAROD4IN
R.(1)Upper frame
S.(6)Metal rod
S
