Side 1/48
Fridge
User manual
2www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
3
www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
EN
CONTENTS
1. IMPORTANT SAFETY AND ENVIRON
MENTAL INFORMATION 4
1.1. Caring for the environment 6 ............................................................................................................................................................
1.2. Cleaning, sanitization and maintenance of the ice and/or water dispenser (if present) ...............................................................6
1.3. Information for regulatory authorities 7 ........................................................................................................................................
1.4. To save energy 7 ...................................................................................................................................................................................
1.5. Environmental labelling 7 ..................................................................................................................................................................
2. INSTALLATION 8
2.1. Installation ...........................................................................................................................................................................................8
2.2. Connection to the water system 8 ...................................................................................................................................................
2.3. Connection to the electrical power supply 9 ................................................................................................................................
2.4. Refrigerant ..........................................................................................................................................................................................9
3. BEFORE STARTING 10
3.1. To know your fridge well 10 .................................................................................................................................................................
3.2. Manufacturer’s liability....................................................................................................................................................................10
3.3. Technical support 10 ..............................................................................................................................................................................
3.4. Technical specifications 10 ..................................................................................................................................................................
3.5. Product plate 10 ......................................................................................................................................................................................
3.6. General description 12 ..........................................................................................................................................................................
3.7. Electronic Control 14 ..............................................................................................................................................................................
3.8. Main control panel 14 ............................................................................................................................................................................
4. SWITCHING THE APPLIANCE ON 15
4.1. Turning on and o 15 .............................................................................................................................................................................
5. COMPARTMENT TEMPERATURE SETTING 18
5.1. How to adjust the temperature to meet dierent needs 18 .......................................................................................................
5.2. Information and malfunction messages on the display 19 ........................................................................................................
6. FUNCTIONS AND SETTINGS 20
6.1. Functions .............................................................................................................................................................................................20
6.2. Settings ................................................................................................................................................................................................27
7. LAYOUT 33
7.1. Positioning, adjusting and internal drawers removal. 33 ...........................................................................................................
8. ACTIVATING AND USING THE ICE MAKER 34
8.1. Activation and use of the Ice Maker.............................................................................................................................................34
8.2. Internal water filter (not 0F models) 35 ...........................................................................................................................................
8.3. External water filter for freezer colu
mn Ice Maker .........................................................................................................................35
9. LIGHTING 36
9.1. Compartment
lighting 36 .................................................................................................................................................................................
10. CONSERVATION OF FOODS 36
10.1. General directions 36 .............................................................................................................................................................................
10.2. How to maintain good food quality 37 .............................................................................................................................................
10.3. Tips for food storage 38 ........................................................................................................................................................................
11. CARE AND CLEANING 41
11.1. Care and Cleaning 41 .............................................................................................................................................................................
11.2. Internal cleaning 41 ...............................................................................................................................................................................
11.3. Cleaning of the ventilation grill, filter and condenser 42 ............................................................................................................
11.4. Upper condenser 42 ...............................................................................................................................................................................
11.5. Lower condenser 43 ..............................................................................................................................................................................
12. TROUBLESHOOTING GUIDE 44
12.1. Troubleshooting Guide 44 .....................................................................................................................................................................
12.2. Malfunction messages appearing on the display 46 ....................................................................................................................
5
www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
EN
1.2. I daily usen
>Cleaning and maintenance meant to be performed
by the user must not be carried out by unsupervised
children.
>Never defrost or clean the appliance with a steam
cleaner! The steam may penetrate electrical parts
and cause a short-circuit. Risk of electric shock!
>Do not use pointed or sharp-edged implements to
remove frost or layers of ice. You could damage the
refrigerant tubes.
Leaking refrigerant may cause eye injuries or ignite.
>Do not misuse the plinth, pull-out drawers, doors,
etc. as a point of support or as a support.
>Take care that no objects get stuck in the doors.
>Before cleaning the appliance, pull out the power
cord plug or turn o the safety switch. Do not pull out
the power cord plug by tugging on the power cord.
>Store high-percentage alcohol tightly closed and
standing up.
>Keep plastic parts and the door seal free of oil and
grease. Greases attack the plastic material and the
door seal becomes brittle and porous.
>Never cover or block the appliance’s ventilation
openings.
>Allow the use of the appliance only to children
aged 8 years or older. Supervise children during
cleaning and maintenance.
>According to current regulations, children be-
tween 3 and 8 years of age may remove food from
or load it into the appliance, but we highly discourage
allowing children under 8 years of age to perform
these operations or to use the appliance in general.
>Keep children under the age of 8 at a safe distance
unless they are constantly supervised and make
sure that they do not play with the appliance.
>Do not use mechanical, electrical or chemical de-
vices other than those recommended by the manu-
facturer to speed up the defrosting process.
>Do not damage the cooling circuit (if it can be
accessed).
>Do not use electrical appliances inside the food
storage compartments, if these are not those rec-
ommended by the manufacturer.
>In the event of damage to the cooling circuit, avoid
the use of open flames and ventilate the area properly.
>Do not use the appliance or parts of it in any way
other than those specified in this manual.
>Keeping the door open for long periods can cause
the temperature in the appliance compartments to
rise considerably.
>Perform cleaning of surfaces that may come into
contact with food and accessible drainage systems
regularly.
>Store raw meat and fish in suitable containers in
the refrigerator, so that it does not come into contact
with other food or drip onto it.
>If the appliance is left empty for long periods of
time, switch it o, defrost it, clean it, dry it and leave
the door open to prevent the development of mould
inside.
>Never rest sharp metal objects such as knives,
forks, spoons and lids on the appliance during use.
>Do not use abrasive or corrosive cleaning agents
(e.g. scouring powders, stain removers or metallic
scouring pads and sponges) on glass parts.
>Do not sit on the appliance.
>Do not sit or lean on the door or on any open
drawers.
>Do not put pressure on the door or handle to move
the appliance.
>Do not use electrical appliances (e.g. hair dryers)
or sprays for defrosting which may ruin
the plastic parts.
> Do not use the appliance to cool rooms for any
reason.
> Always unplug the appliance in the event of a mal-
function or when performing cleaning or maintenance.
> Do not keep liquids in tins or glass containers in
the freezer.
> Do not place heavy objects on top of the appliance.
6www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
1. IMPORTANT SAFETY AND ENVIRONMENTAL INFORMATION
Symbols used in the Guide:
Note
Tips for the correct use of the appliance
Important
Directions to avoid appliance damage
Warning
Directions to prevent injury
1.1. Caring for the environment
>This appliance complies with the European WEEE
Directive (2012/19/EU) and must be disposed of sepa-
rately from other waste at the end of its service life.
>This appliance does not contain substances in
quantities sucient to be considered hazardous to
health and the environment, in accordance with cur-
rent European directives.
>Make sure you dispose properly of all packing
materials.
Electric voltage | Electrocution hazard
Disconnect the mains power supply. Unplug
the appliance.
>The appliance must not be disposed of with urban
waste. Contact local waste disposal centres about
how to dispose of recyclable waste.
>Prior to disposal, cut the power supply cord and
remove the door and/or drawers.
>During disposal, avoid damage to the refrigeration
circuit.
>Neither the refrigeration circuit nor the insulation
contain substances that are damaging to the ozone
layer
>Our appliances are packaged in non-polluting and
recyclable materials.
>Deliver the packing materials to the appropriate
recycling centre.
Plastic packaging | Choking hazard
Do not leave the packaging or any part of it
unattended.
Do not let children play with plastic bags.
1.2. Cleaning, s
anitization and
maintenance of the ice and/or water
dispenser (if present)
Failure to follow the instructions regarding sanitis-
ing can compromise the hygienic safety of the water
dispensed.
>When using the appliance for the first time and eve-
ry time the filter is changed, it is recommended to let
the water flow in the circuit using the “Circuit manual
cleaning” function (see chap. 8) Circuit manual clean-
ing (option, not on 0FR models) on page 25).
>If the water dispenser has not been used for more
than 4/5 days, it is advisable to clean the circuit and
run o the first litre of water.
>Reposition the removable water dispenser (if pre-
sent), ensuring your hands are hygienically clean.
>Clean the ice bucket or drawer regularly using only
drinking water.
>The filter must be changed when indicated on the
control panel or when the ice/water dispenser has not
been used for more than 30 days.
>With each filter replacement, sanitise the ice and/or
water dispensing system using a food grade disinfect-
ant (with sodium hypochlorite), which does not alter
the characteristics of the materials. Rinse with at least
2 litres of water before use.
>Only original spare parts supplied by the manufac-
turer should be used when replacing components in
the ice and water dispenser.
>Any work on the appliance must be carried out by a
qualified technician or the After-sales Service.
Warning
To avoid contamination of food, please re-
spect the following instructions:
>Opening the door for long periods can
cause a significant increase in temperature
inside the appliance compartments.
>Perform regular cleaning of surfaces
that may come in contact with food and of
accessible drainage systems.
>Store raw meat and fish in suitable con-
tainers in the refrigerator, so that it does not
come into contact with other food or drip
onto it.
>Two-star frozen-food compartments are
suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
C
C
D
E
B
A
A
G
H
F
7
www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
EN
Warning
>Two-star frozen-food compartments are
suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
>One-, two- and three-star compartments
are not suitable for the freezing of fresh food.
>If the refrigerator is left empty for a long
period, switch it o, defrost, clean and dry it,
and leave the door open to prevent mould de-
veloping within the appliance.
1.3. Information for regulatory
authorities
>For Ecodesign tests, the installation and set-up of
the appliance must comply with standard EN 62552.
>Ventilation requirements, dimensions and mini-
mum space from the rear wall are provided in the
“Installation” chapter of this manual.
>Contact the manufacturer for additional information.
1.4. To save energy
>Correct use of the appliance, correct packaging of
foodstus, a constant temperature and food hygiene
all have eects on the quality of storage.
>Keep the number of times that the doors are
opened and the length of time they remain open to a
minimum to avoid excessive warming.
>Clean the condenser periodically to prevent the
appliance from losing eciency (see page 42).
>Defrost frozen food in the refrigerator compart-
ment in order to make use of the cold stored in the
frozen foods.
1.5. Environmental labelling
PACKAGING MATERIAL KEY
Material Abbreviation Numbering
A
Low-density
polyethylene LLDPE 4
B
Uncorrugated
cardboard PAP 21
C
Polystyrene PS 6
D
Wood FOR 50
E
Iron FE 40
F
Polyvinyl
chloride PVC 3
G
Polypropylene
terephthalate PET 1
H
Corrugated
cardboard PAP 20
8www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
2. INSTALLATION
2.1. Installation
Make sure that installation is performed correctly,
adhering to all of the instructions in the specific in-
stallation guide provided with the appliance.
Warning
If any model has water connections, make
them before connecting the machine to the
electrical system.
>The appliance must be connected to ground in
compliance with electrical system safety standards.
>Position the appliance with the aid of a second
person.
>Never use the open door to lever the appliance
into position.
>Avoid exerting too much pressure on the door
when open.
>The appliance must not be installed near heat
sources. If this is not possible, suitable insulation
must be used.
>The appliance must not be exposed to direct sun-
light.
>Do not use the appliance outdoors.
>Installation and servicing should be carried out
by qualified personnel in compliance with current
standards.
>Ensure that an authorised technician performs
the electrical connection.
>If the power supply cable is damaged, to avoid any
danger, contact technical support immediately and
they will replace it, so as to prevent any risk.
>Always put on the necessary Personal Protective
Equipment (PPE) before performing any work on the
appliance (installation, maintenance, positioning or
handling).
>Before performing any operation involving the ap-
pliance, switch o the power supply.
>If installed near another refrigerator, refer to the
installation guide.
>Do not try to repair the appliance yourself or with-
out the assistance of a qualified technician.
>Do not install/use the appliance outdoors.
>WARNING: Make sure that the power supply cable
does not become caught or damaged when position-
ing the appliance.
>To prevent instability of the appliance, install and
secure it correctly as indicated in the instructions
provided in this manual.
>This device can be used up to a maximum height
of 2000 meters above sea level.
2.2. Connection to the water system
Models equipped with an Ice Maker require a connec-
tion to the domestic water supply system.
It must be carried out using only the supplied new
water inlet hose with ¾” thread (do not use or reuse
previously used pipes).
The system pressure must be between 0.05 MPa and
0.5 MPa (between 0.5 bar and 5 bar).
Any pressure outside of this range may cause the
water system to malfunction or leak.
Important
Do not use extension cords and/or multiple
adapters for connection.
Warning
Make sure that installation is performed
correctly and in accordance with all of the
instructions in the specific installation man-
ual provided with the appliance.
Warning
Do not attempt to use a locally-sourced
threaded garden hose adapter or braided
supply line. It will strip the threads on the
appliance’s water connection solenoid.
11
www.fhiaba.com · sales@fhiaba.com · Info Line 800-344222
EN
F
RO
S
T
FR
E
E
REFRIGE RAT
O
R
Serial Number .
Location of the serial number inside the compartment.
Model .
Features .
Type .
Climate classes
> SN (Sub Normal) from +10°C to +32°C
> N (Normal) from +16°C to +32°C
> ST (Subtropical) from +18°C to +38°C
> T (Tropical) from +18°C to +43°C
The product plate is positioned
on the side opposite door opening.
Gross pacity (l)ca
Net pacity Fridge (l)ca
Net pacity Fresco (l)ca
Net pacity Freezer(l)ca
Freezing Capacity (kg/12h)
Refrigerant Fridge/Fresco (gr)
Refrigerant Freezer (gr)
Refrigerant Type
Climatic Class
Defrost Heater (W)
Total Absorbed Current (A)
Voltage (V~)
Frequenzy (Hz)
Lighting Neon/Led (W)
Temperature Rise Time
MADE IN ITALY
582
425
131
5,5
48
60
R600a
SN/T
367
1.5
220-240 V
50-60 Hz
10
10
MODEL
TYPE
SERIAL NUMBER
XS8990TST6I
M899
F20200101000006
FROST FREE
REFIGERATOR
VARIABLE TEM COMP.P.
Produkspesifikasjoner
| Merke: | Fhiaba |
| Kategori: | Kjøleskap |
| Modell: | RS900TST3 |
Trenger du hjelp?
Hvis du trenger hjelp med Fhiaba RS900TST3 still et spørsmål nedenfor, og andre brukere vil svare deg
Kjøleskap Fhiaba Manualer
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
Kjøleskap Manualer
- Kjøleskap Teka
- Kjøleskap Maytag
- Kjøleskap Thomson
- Kjøleskap Amana
- Kjøleskap Uniprodo
- Kjøleskap Miele
- Kjøleskap Whirlpool
- Kjøleskap Etna
- Kjøleskap Haier
- Kjøleskap KitchenAid
- Kjøleskap NewAir
- Kjøleskap Insignia
- Kjøleskap Adler
- Kjøleskap Pelgrim
- Kjøleskap Royal Catering
- Kjøleskap LG
- Kjøleskap Bosch
- Kjøleskap Jocel
- Kjøleskap BEKO
- Kjøleskap Exquisit
- Kjøleskap Grundig
- Kjøleskap Hisense
- Kjøleskap Sharp
- Kjøleskap Electrolux
- Kjøleskap Severin
- Kjøleskap Café
- Kjøleskap Balay
- Kjøleskap Siemens
- Kjøleskap Koldfront
- Kjøleskap Arcelik
- Kjøleskap Danby
- Kjøleskap Bartscher
- Kjøleskap Smeg
- Kjøleskap Hoover
- Kjøleskap Philips
- Kjøleskap TCL
- Kjøleskap Russell Hobbs
- Kjøleskap Hotpoint
- Kjøleskap Amica
- Kjøleskap IKEA
- Kjøleskap Ignis
- Kjøleskap AEG
- Kjøleskap Rosieres
- Kjøleskap Inventum
- Kjøleskap Artusi
- Kjøleskap Cecotec
- Kjøleskap Samsung
- Kjøleskap Neff
- Kjøleskap Delonghi
- Kjøleskap Bomann
- Kjøleskap Edgestar
- Kjøleskap Kogan
- Kjøleskap Caple
- Kjøleskap PKM
- Kjøleskap Marvel
- Kjøleskap Yamaha
- Kjøleskap Midea
- Kjøleskap Sauber
- Kjøleskap Candy
- Kjøleskap Liebherr
- Kjøleskap Viking
- Kjøleskap Orbegozo
- Kjøleskap Kuppersbusch
- Kjøleskap Gorenje
- Kjøleskap Summit
- Kjøleskap Accucold
- Kjøleskap Brandt
- Kjøleskap Gram
- Kjøleskap Panasonic
- Kjøleskap Monogram
- Kjøleskap Vox
- Kjøleskap Westinghouse
- Kjøleskap Orava
- Kjøleskap Schneider
- Kjøleskap Kluge
- Kjøleskap Bertazzoni
- Kjøleskap Privileg
- Kjøleskap MPM
- Kjøleskap Cosmo
- Kjøleskap Khind
- Kjøleskap Euro Appliances
- Kjøleskap Bauknecht
- Kjøleskap Frigidaire
- Kjøleskap GE
- Kjøleskap Concept
- Kjøleskap Guzzanti
- Kjøleskap XO
- Kjøleskap Omega
- Kjøleskap Hitachi
- Kjøleskap Fisher Paykel
- Kjøleskap Hyundai
- Kjøleskap Chiq
- Kjøleskap Nevir
- Kjøleskap Eqtemp
- Kjøleskap Infiniton
- Kjøleskap Indesit
- Kjøleskap Daikin
- Kjøleskap Zephyr
- Kjøleskap Asko
- Kjøleskap Blaupunkt
- Kjøleskap Mitsubishi
- Kjøleskap Marshall
- Kjøleskap Scandomestic
- Kjøleskap Cylinda
- Kjøleskap AYA
- Kjøleskap Costway
- Kjøleskap Dometic
- Kjøleskap Blaze
- Kjøleskap Husky
- Kjøleskap Fridgemaster
- Kjøleskap Eldom
- Kjøleskap Fisher And Paykel
- Kjøleskap Elba
- Kjøleskap Philco
- Kjøleskap Jenn-Air
- Kjøleskap Wisberg
- Kjøleskap ECG
- Kjøleskap HomeCraft
- Kjøleskap Igloo
- Kjøleskap ATAG
- Kjøleskap Freggia
- Kjøleskap Becken
- Kjøleskap Element
- Kjøleskap Avanti
- Kjøleskap Acros
- Kjøleskap Kucht
- Kjøleskap Glem Gas
- Kjøleskap True
- Kjøleskap Perlick
- Kjøleskap Toshiba
- Kjøleskap BeefEater
- Kjøleskap Hansa
- Kjøleskap Thor
- Kjøleskap Sub-Zero
- Kjøleskap Koolatron
- Kjøleskap Coca-Cola
- Kjøleskap Kenmore
- Kjøleskap Meireles
- Kjøleskap Fagor
- Kjøleskap Edesa
- Kjøleskap IFB
- Kjøleskap Profilo
- Kjøleskap Gaggenau
- Kjøleskap Milectric
- Kjøleskap Tisira
- Kjøleskap Hiberg
- Kjøleskap LERAN
- Kjøleskap Zerowatt
- Kjøleskap Baumatic
- Kjøleskap Iberna
- Kjøleskap Ilve
- Kjøleskap Wolkenstein
- Kjøleskap Hoover-Grepa
- Kjøleskap Primo
- Kjøleskap Svan
- Kjøleskap Landmark
- Kjøleskap Signature
- Kjøleskap Trisa
- Kjøleskap Corberó
- Kjøleskap Atosa
- Kjøleskap Scancool
- Kjøleskap FrigeluX
- Kjøleskap Mora
- Kjøleskap DAYA
- Kjøleskap Salora
- Kjøleskap Consul
- Kjøleskap Aconatic
- Kjøleskap Kuhla
- Kjøleskap Hestan
- Kjøleskap Yolco
- Kjøleskap Sangiorgio
- Kjøleskap Ardes
- Kjøleskap Ideal
- Kjøleskap Avallon
- Kjøleskap Continental Edison
- Kjøleskap Icecool
- Kjøleskap Crosley
- Kjøleskap Pitsos
- Kjøleskap Winia
- Kjøleskap Schaub Lorenz
- Kjøleskap Linarie
- Kjøleskap United
- Kjøleskap Kalamazoo
- Kjøleskap Kaiser
- Kjøleskap Robinhood
- Kjøleskap De Dietrich
- Kjøleskap Orima
- Kjøleskap Zanussi
- Kjøleskap Lec Medical
- Kjøleskap Aspes
- Kjøleskap Benavent
- Kjøleskap Vedette
- Kjøleskap Kernau
- Kjøleskap Cookology
- Kjøleskap Hanseatic
- Kjøleskap Goddess
- Kjøleskap Edy
- Kjøleskap Thetford
- Kjøleskap Pando
- Kjøleskap U-Line
- Kjøleskap Equator
- Kjøleskap Romo
- Kjøleskap Rhino
- Kjøleskap Cooluli
- Kjøleskap Hoshizaki
- Kjøleskap SEIKI
- Kjøleskap Premium
- Kjøleskap Corona
- Kjøleskap Coors Light
- Kjøleskap Turbo Air
- Kjøleskap Emperor's Select
- Kjøleskap Beverage-Air
- Kjøleskap Delfield
- Kjøleskap Galanz
- Kjøleskap Snaigė
- Kjøleskap Avantco
- Kjøleskap Zanker
- Kjøleskap Miller Lite
- Kjøleskap Lanbo
- Kjøleskap Listo
- Kjøleskap Cool Head
- Kjøleskap Schmick
- Kjøleskap Helkama
- Kjøleskap Brandy Best
- Kjøleskap Waltham
- Kjøleskap Valberg
- Kjøleskap Rex
- Kjøleskap Momcube
- Kjøleskap Bompani
- Kjøleskap Prima
- Kjøleskap Sheffield
- Kjøleskap Stoves
- Kjøleskap Bushman
- Kjøleskap Richome
Nyeste Kjøleskap Manualer
31 Mars 2025
31 Mars 2025
31 Mars 2025
31 Mars 2025
30 Mars 2025
30 Mars 2025
29 Mars 2025
29 Mars 2025
29 Mars 2025
29 Mars 2025
