Side 1/32
EN Instruction manual
Refrigerator
459922
We thank you for the confi dence you have shown by purchasing our appliance.
We wish you nd a lot of pleasure in its use.
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at temperatures above 0°C.
Important notes and warnings ................................... 3
Advice for saving power with refrigeration
appliances .................................................................... 5
Appliance description ................................................. 6
Installation and connection ........................................ 7
Changing the direction of door opening ................... 9
Operating the appliance with mechanic controls... 13
Operating the appliance with electronic controls .. 14
Appliance interior equipment ................................... 19
Recommended distribution
of food in the appliance ............................................ 23
Storing food in the refrigerator ................................ 24
Storing food in the FreshZone drawer .................... 25
Defrosting the appliance ........................................... 26
Cleaning the appliance ............................................. 26
Troubleshooting ........................................................ 27
Information about appliance noise .......................... 28
2
459922
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or metal capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Before connecting the appliance to the power
mains, please read carefully the instructions
for use which describe the appliance and its
correct and safe use. The instructions apply for
several appliance types/models; thus, settings or
equipment may be described herein which is not
available in your appliance.
Remove the packaging intended for protecting the
appliance or particular parts during transport.
Spacers are fi tted on the corners of the doors.
Remove them and insert the supplied plugs into
their slots (only in some models).
Before connecting the appliance to the power
mains, let the appliance rest in a vertical position
for approximately 2 hours. This will reduce the
possibility of operation faults due to the effect of
transport on the cooling system.
The appliance must be connected to the power
mains and grounded in compliance with the
effective standards and regulations.
The appliance may not be used outdoors and it
may not be exposed to rain.
Before cleaning the appliance, unplug the
appliance from the power mains (unplug the
power cord from the wall outlet).
If the power cord is damaged, it must be replaced
by a service technician or other adequately
trained person.
If the appliance will be out of use for a prolonged
period of time, switch it off using the relevant
button, and unplug the appliance from the power
mains. Empty the appliance, defrost it, clean it,
and leave the door ajar.
3
Important notes and warnings
459922
If LED lighting does not work, call a service technician. Do not attempt a
repair of the LED lighting yourself, as there is danger of contact with high
voltage!
To protect the environment, take the obsolete appliance to an authorized
home appliance collection center.
Packaging is made of environmentally friendly materials that can be recycled,
disposed of, or destroyed without any hazard to the environment.
Do not let the children play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Rating plate can be found in the appliance interior. If the language on the
rating plate is not the language of your choice or the language of your country,
replace it with the one supplied.
WARNING! Ventilation openings on the appliance or
built-in cupboard must be kept clean and unobstructed
at all times.
WARNING! Do not use any mechanical accessories or
other methods to defrost the appliance, except for those
expressly recommended by the manufacturer.
WARNING! During installation, cleaning, and removal
of appliance, be careful not to damage the insulation of
the parts of the cooling system. This will also prevent
pollution.
WARNING! Do not use any electric devices inside
the appliance, except for those allowed by the
manufacturer of this refrigeration appliance.
The symbol on the product or its packaging indicates that the product should not be
treated as normal household waste. The product should be taken to an authorized
collection center for waste electric and electronic equipment processing. Correct
disposal of the product will help prevent any negative effects on the environment and
health of people which could occur in case of incorrect product removal. For detailed
information on removal and processing of the product, please contact the relevant
municipal body in charge of waste management, your waste disposal service, or the store
where you bought the product.
4
459922
Install the appliance as specifi ed in the instruction manual.
Do not open the door more often than necessary.
Occasionally make sure air circulation underneath the appliance is unobstructed.
Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance).
If the gasket is damaged or does not provide a perfect seal for other reasons, have it replaced as
soon as possible.
Store the food in tightly sealed containers or appropriate packaging.
Before placing the food in the appliance, cool it to room temperature.
Defrost frozen food in the refrigerator compartment.
Remove the drawers from the freezer compartment as described in the instruction manual, in
order to make use of the entire interior.
Defrost your conventional freezer when an approximately 3-5 milimeter layer of of frost or ice has
built up on the refrigerated surfaces.
Make sure the layout of shelves in the compartment is uniform and that the food is placed so that
the air can freely circulate in the appliance interior (observe the recommended placement of food
as described in the instructions).
In appliances with a fan, do not block the fan slots.
If you do not need the fan or the ionizer, switch them off to reduce power consumption.
5
Advice for saving power with refrigeration
appliances
1
3
5
6
2
12
9
4
7
8
10
11
13
12
459922
Appliance interior equipment may change according to the appliance model.
The drawers are protected against pulling out. To remove a drawer from the appliance, open it,
then lift the front part and pull it out.
Some models also feature a control unit on the door.
* Only in some models
1 Control unit
2 Led lighting of refrigerator
interior
3 Fan with air ionizer (+ on/off
switch)*
4 Bottle rack*
5 Pull-out glass shelf (height
adjustable)
6 FreshZone drawer*
7 CrispZone fruit and vegetables
drawer with humidity control
8 Fruit and vegetables drawer
9 SimpleSlide height-adjustable
door bin
10 Multibox storage bin*
11 Bottle bin
12 Foot
13 Caster*
6
Appliance description
459922
Install the appliance in a dry and well ventilated room. The
appliance will operate correctly if the environment temperature
is in the interval specifi ed in the table. The appliance class is
indicated on the rating plate / label with the basic information
on the appliance.
Class Temperature
SN (subnormal) from +10°C to +32°C
N (normal) from +16°C to +32°C
ST (subtropical) from +16°C to +38°C
T (tropical) from +16°C to +43°C
Warning: Make sure the room where the appliance is installed is
large enough. There should be at least 1 m
3 of space per
8 grams of refrigerant. Amount of refrigerant is stated on the
rating plate in the appliance interior.
Appliance installation should be carried out by at least two
persons to avoid any physical injury or damage to the appliance.
The appliance must stand level or tilted slightly to the back,
stable on a solid base. At the front, the appliance is fi tted with
two adjustable legs that can be used to level the appliance. At
the rear side, casters allow for easier installation of the
appliance (only with some models).
• There should be a clearance of at least 5 cm between the
appliance and any cupboard installed above it, in order to
allow adequate cooling of the condenser unit.
The appliance is supplied with two spacers which should
be installed on the lower part of the housing to prevent from
pushing the appliance too close to the wall. Appliance may
also be installed without the spacers; however, this may
increase power consumption.
Do not expose the appliance to direct sunlight and do not
place it near any source of heat. If this cannot be avoided,
install an insulation panel.
Selecting the room
Installing the appliance
max
30 mm
> 90°
7
Installation and connection
459922
Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, at screwdriver
The procedure to change the direction of door opening should be carried out by at least two
persons.
1. Remove the upper hinge cover (A) and the covering cap (G).
2. Undo the upper hinge (B) and remove the door (C) from the lower hinge (D).
3. Tilt the appliance backwards (make sure you do not press against the condenser unit on the
rear wall of the appliance as this may damage the cooling system), unscrew the lower hinge (D)
and the foot (E), and move them to the opposite side. Make sure the washer is installed like it
was before disassembly.
4. Move the door hinges (F) to the opposite side and replace the door (C) back on the lower hinge (D).
5. Use the screws to attach the upper hinge (B) on the opposite side.
6. Replace the upper hinge cover (A) and the covering cap (G) on the opposite side.
7. Replacing the handle (H): remove the handle covering caps, undo the screws, and remove
the handle. Remove the hole plugs on the opposite side of the door and attach the handle.
Replace the covering caps on the handle. Insert the new hole plugs supplied in the bag with the
instruction manual into the holes where the handle was initially attached.
Replacing the hinged handle:
- Push a small screwdriver into the handle
slot as indicated in Figure 1 and remove
the cover.
- Remove the caps on the opposite side of
the door.
- Undo the three screws, making sure not
to disassemble the handle.
- Rotate the handle by 180° as indicated in
Figure 3 and attach it to the opposite
side of the door.
- Replace the cover and the caps.
1
1
1
11 2
2
2
22
3
3
3
33 4
4
4
44
9
Changing the direction of door opening
Version I – controls in
the appliance interior
459922
10
459922
Tools required: socket wrench No. 8, Phillips screwdriver, torx 25, at screwdriver
The procedure to change the direction of door opening should be carried out by at least two
persons.
1. Remove the upper hinge cover (A), the connector cover (B1) and the covering cap (M).
2. Disconnect the connector (C), undo the upper hinge (D) and remove the door (E) from the lower
hinge (I).
3. Remove the side panels (F) and (G), then unscrew and remove the middle panel (H).
4. Move the upper hinge (D) along with the connector and cable to the opposite side – make sure
to install the cable into the grooves in the panels like it was before disassembly. Then, replace
all three panels (F), (G), and (H).
5. Tilt the appliance backwards (make sure you do not press against the condenser unit on the
rear wall of the appliance as this may damage the cooling system), unscrew the lower hinge (I)
and the foot (J), and move them to the opposite side. Make sure the washer is installed like it
was before disassembly.
6. Move the cap (B2), door hinge (K) and retainer (L) to the opposite side and replace the door (E)
on the lower hinge (I).
7. Use the screws to attach the upper hinge (D) on the opposite side and reconnect the connector
(C).
8. Replace the upper hinge cover (A), the connector cover (B1) and the covering cap (M).
9. Replacing the handle (N): remove the handle covering caps, undo the screws, and remove
the handle. Remove the hole plugs on the opposite side of the door and attach the handle.
Replace the covering caps on the handle. Insert the new hole plugs supplied in the bag with the
instruction manual into the holes where the handle was initially attached.
11
Version II – Controls on
the door
459922
12
459922
Recommended setting is 5°C.
Use this setting after switching on the appliance for the fi rst
time, before cleaning, or before inserting a large amount of
food.
To activate the cooling boost function, press the key until the B
symbol lights up.D
If the function is not deactivated manually, it will be deactivated
automatically after approximately six hours. Refrigerator
compartment temperature will return to the most recent setting.
Cooling boost function can also be switched off before it is
automatically deactivated by setting a temperature for the
refrigerator compartment.
C
Refrigerator boost
15
459922
CONTROL UNIT 3
A On/off key
B Acoustic alarm off key
C Cooling boost on/off key
D Refrigerator temperature keys
C Refrigerator temperature display
G ECO function on/off key
Controls on the door
16
459922
Switching the appliance on: Switch on the appliance by briefl y
pressing the key. A
Switching off the appliance: To switch off the appliance, press
the key and hold it for 3 seconds. A
Us the keys to set the temperature. D
lower temperature ; higher temperature.
Refrigerator compartment temperature can be set in the range
from +1°C to 9°C.
After one of the keys is pressed, the most recent D
temperature setting will fl ash on the display unit . Use the E
D keys to set the desired temperature. Three seconds after
the last key is pressed, the most recent temperature setting is
automatically stored for the refrigerator compartment.
Use this setting after switching on the appliance for the fi rst
time, before cleaning, or before inserting a large amount of
food.
To activate the cooling boost, press the key.C
If the function is not deactivated manually, it will be deactivated
automatically after approximately six hours.
Refrigerator compartment temperature will return to the most
recent setting.
Cooling boost function can also be switched off before it is
automatically deactivated by setting a temperature for the
refrigerator compartment.
Switching the appliance
on/off
Adjusting the
temperature in the
appliance
Cooling boost
17
459922
If the temperature inside the appliance is too high, acoustic alarm
will be activated (intermittent tone) and the key will fl ash.B
Acknowledge and turn off the acoustic alarm by pressing the B
key.
The acoustic alarm will be activated every 24 hours if the
temperature in the appliance is not low enough and there
is danger of food spoilage. The alarm will be switched off
automatically as soon as the temperature in the refrigerator
drops to a level that no longer presents spoilage hazard.
When the appliance is switched on for the rst time, there is a
24-hour delay in temperature alarm operation as it takes some
time for appliance to reach the adequate temperature. Thus,
unnecessary activation of alarm is prevented.
If the temperature in the appliance is too high due to a power
supply failure, »9°C« will fl ash on the display unit.
Open door alarm: if the door is open for more than 2 minutes,
acoustic alarm will be activated and the key will fl ash. When B
the door is closed, the alarm will be deactivated. It can also be
switched off by pressing the key.B
To activate the function, press the key. With this function Eco G
activated, appliance will operate with optimum settings.
Use this function if you do not wish to manually adjust the
appliance settings.
To activate, press and hold the key (for three seconds); L will B
appear on the display .E
This will lock all keys except .B
To deactivate the safety lock, press the key and hold it for B
three seconds.
High temperature alarm
Eco function
Safety block (child
safety lock)
18
459922
(* Equipment depends on the model)
For easier access to food and clarity, the shelves can be partly
pulled out.
The shelves may be adjusted tu suit your preferences using
the guides in the refrigerator interior. To remove a shelf from
the refrigerator, pull it out tot he point when it is stopped by the
guide. Then, lift it slightly at the front part and pull it all the way
out.
Store perishables at the back of the shelf where the
temperature is the lowest.
Some models also feature a wire bottle holder. The bottle
holder is protected against being inadvertently pulled out It can
only be pulled out when it is empty. To pull it out, lift is slightly
at the back and pull it towards you. Place the bottle holder so
that the length of the bottles does not prevent proper closing of
the door. The holder can take a maximum load of 9 0.75-liter
bottles or 13 kilograms of total weight – see label on the right
side in the appliance interior.
Cans may also be placed on the bottle rack (lengthwise or
crosswise).
Some models feature an elastic mat on which bottles or cans
can be placed.
The mat can also be used as a trivet for hot pans.
The bin at the bottom of the refrigerator is intended for storing
fruit and vegetables. It provides humidity and prevents the
food from drying out.
Store the food in suitable packaging to prevent them from
emitting or taking on odours.
The bin has integrated humidity regulator which allows setting
the humidity according to the amount of food stored.
Shelf
1
1
1
11
2
2
2
22
Wire bottle rack*
Elastic bottle mat*
CrispZone – fruit and
vegetable bin with
humidity control
19
Appliance interior equipment
459922
Smaller amounts of food - push the control slider to the right;
Larger amounts of food - push the control slider to the left;
Removing the fruit and vegetable bin:
- Pull out the bin as far as it will go. Then, lift the front part
and pull it out completely.
Mounted on the refrigerator door are compartments (shelves or
bins) intended fro storing cheese, butter, eggs, yoghurt and other
smaller packages, tubes, cans, etc. There is a bottle shelf at the
lower end of the door.
The height of the door bins can be adjusted without having to
remove the bins from the appliance. Simply pull the two levers on
each side of the bin towards you and slide the bin up or down.
To remove a bin from the appliance, lift it as far as it will go and
pull it out.
bin offers a convenient way for storing food with a MultiBox
strong or pungent smell, e.g. ripened or blue-vein cheese,
sausages, onions, butter etc.
• The silicone lid provides an air-tight seal that prevents the
food from drying out and the odour to spread throughout the
refrigerator compartment.
• The silicon lid can also be used as an egg or ice tray.
• If the fl exible lid is used as an egg tray, place it directly on
the bottom of the door bin and use the open lower part of the
Multibox bin to store food in smaller packages – pâté, jams,
smaller tubes etc.
1
1
1
11
2
2
2
22
Interior side of the
refrigerator door
Adjustable door bins
Storage bin (MultiBox)*
20
459922
The fan placed under the refrigerator compartment ceiling or
hidden in the freezer unit will make sure the temperature is
distributed more evenly and reduce condensation (dew) on the
storage surfaces.
placed in the refrigerator compartment removes Air ionizer
most bacteria, viruses, gases, and unpleasant odours to make
sure the air in the refrigerator is always fresh. The food will
remain fresh and tasty longer.
Air ionizer can be switched on and off using the switch
located on the fan housing or on the side of the cooling tower
(depending on the model).
Control unit 1
Switching the fan and ionizer on and off
ON = OFF = 0
Fan*
Ionizer (IonAir)*
When the fan and the ionizer are switched on, a red dot will be
visible on the switch.
21
459922
Control unit 2 and 3
Switching the ionizer on/off
ON = I OFF = 0
When the ionizer is switched on, a red dot will be visible on the
switch.
(only with control units 2 and 3)
Innovative sensor technology allows adjusting appliance
operation to the user's habits or behaviour. Adaptive intelligent
system monitors, analyzes, and records on weekly basis the use
of appliance and adapts appliance operation to the perceived
patterns. If the appliance is able to anticipate increased
frequency of door opening, the appliance will automatically lower
the temperature before such time to reduce heating of the food
as the door is opened more often.
Adaptive Intelligent
Technology
22
459922
Sections of the refrigerator:
- : canned food, bread, wine, pastry etc.upper part
- : dairy products, ready-made meals, desserts, soft middle part
drinks, beer, cooked food, etc.
- : - meat, meat produce, delicatessen;Fresh bin
- : fresh fruit, vegetables, salads, root Fruit and vegetable bin
vegetables, potatoes, onions, garlic, tomatoes, tropical fruit,
sauerkraut, turnips etc.
Sections in the refrigerator compartment door:
- : eggs, butter, cheese etc.upper/middle door bins
- : beverages, cans, bottles etc.lower door bins
Recommended
distribution of food in
the appliance
23
Recommended distribution of food in the appliance
459922
Correct use of the appliance, appropriate packaging,
maintaining the right temperature, and observing the
food hygiene standards has a decisive impact on the
quality of food storage.
Observe the expiry dates for the food, specifi ed on
the packaging.
Food stored in the refrigerator should be kept in
closed containers or appropriate packaging to
prevent them from emitting or receiving odours.
Do not store infl ammable, volatile, and explosive
substances in the refrigerator.
Bottles with high alcohol content should be tightly
sealed and stored in an upright position.
Some organic solutions, essential oils in lemon and
orange peel, butter acid, etc. may damage the plastic
surfaces in case of a prolonged contact, causing
damage and premature ageing of these materials.
Unpleasant odour warns of lacking cleanliness of
the appliance or perished contents (see Cleaning the
Appliance).
If you are leaving home for a longer period of time,
remove perishables from the refrigerator.
Recommended storage time in the refrigerator
Type of food Time
eggs, marinades, smoked meat up to 10 days
cheese up to 10 days
root vegetables up to 8 days
butter up to 7 days
deserts, fruit, ready-to-eat food, chunks of
raw meat up to 2 days
sh, raw minced meat, seafood up to 1 day
Important warnings
regarding food storage
Food storage times
24
Storing food in the refrigerator
459922
In the compartment, food stays fresh longer than in a FreshZone
conventional refrigerator, retaining more fl avour and nutrients.
Decay and loss of mass are slowed down; therefore, fruit and
vegetables remain fresh and natural longer.
For optimum performance, the drawer should be fully closed.
When buying food, make sure it is fresh as this will determine
the quality of the food, as well as how long it will keep in the
fridge.
Store the food in closed containers or appropriate packaging
to prevent them from emitting or receiving odours.
Take the food from the drawer 30-60 minutes before use to
allow the aroma and fl avour develop at room temperature.
Food sensitive to low temperature and not appropriate for
storage in the drawer include the following: FreshZone
pineapple, avocado, bananas, olives, potatoes, eggplant,
cucumbers, beans, peppers (capsicum), melons, watermelons,
pumpkins, squash, zucchini etc.
To remove the drawer:
- Pull out the drawer until it is blocked.
- Then, lift it at the front and pull it all the way out.
Storing food in the FreshZone drawer
25

Produkspesifikasjoner

Merke: Gorenje
Kategori: Kjøleskap
Modell: R6192KX

Trenger du hjelp?

Hvis du trenger hjelp med Gorenje R6192KX still et spørsmål nedenfor, og andre brukere vil svare deg




Kjøleskap Gorenje Manualer

Kjøleskap Manualer

Nyeste Kjøleskap Manualer
