Side 1/119
univers FWB manual
Wall-mounting cabinets
FWB, FWQ
Degree of protection IP44
Table of contents
2We reserve the right to make changes of a technical nature
Table of contents
1 About this manual 5
1.1 Aim of this manual 5
1.2 Warranty and liability 5
1.3 Symbols and warning signs used 6
2 For your safety 7
2.1 Proper use 7
2.2 Authorised sta requirements 8
3 Technical data 9
4 Information about the FWB, FWQ distribution board range 11
4.1 Cabinet delivery forms (complete / partially equipped / empty) 11
4.2 Body 12
4.2.1 Properties 12
4.2.2 Coding 23
4.2.3 Cabinet references overview 24
4.2.3.1 FWB references 24
4.2.3.2 FWQ references 27
4.2.4 Cabinet details 28
4.2.4.1 FWBxx 28
4.2.4.2 FWBxxA 29
4.2.4.3 FWBxxCSDB 30
4.2.4.4 FWBxxD 31
4.2.4.5 FWBxxD1 32
4.2.4.6 FWBxxGS 33
4.2.4.7 FWBxxK1 34
4.2.4.8 FWBxxK5 35
4.2.4.9 FWBxxM2 36
4.2.4.10 FWBxxN 37
4.2.4.11 FWBxxN3 38
4.2.4.12 FWBxxP 40
4.2.4.13 FWBxxP2 41
4.2.4.14 FWBxxS 42
4.2.4.15 FWBxxT1S 43
4.2.4.16 FWQxxD1 44
4.2.4.17 FWQxxN 45
4.2.4.18 FWQxxN1 46
4.2.4.19 FWQxxP 47
4.2.4.20 FWQxxP1 48
Table of contents
We reserve the right to make changes of a technical nature 3
5 Doors 49
5.1 Properties 49
5.2 Door coding 51
5.3 Door references: Single door with univers door plate (FZ598N) 52
5.4 Door references: Single door with 90SL door plate (FZ598) 55
5.5 Flush-mounting frame 57
5.5.1 properties 57
5.5.2 Flush-mounting frame references overview 57
5.5.3 Frame installation 58
6 Enclosure installation 60
6.1 Packaging 60
6.2 Cabinet feet 61
6.3 Wall installation 62
6.3.1 Wall installation measurements / dimensions 62
7 univers Z internal system 63
7.1 Coding 63
7.2 Supply of fully assembled panels 64
7.2.1 UWxxVx distribution panels 64
7.2.2 Multimedia panels 65
7.2.3 Hybrid panels 69
7.2.4 Protection class by Multimedia panels and Hybrid panels 71
7.3 Supply of individual panel versions 72
7.3.1 univers Z UN0xA mounting rails 72
7.3.2 UZ0xAx fixation towers 72
7.3.3 DIN rails U… 73
7.3.4 UM00M0 plastic mounting plate 75
7.3.5 UZxxMx steel mounting plates 78
7.4 Multimedia accessories 79
7.4.1 Patch panels without socket insertion 82
7.4.2 Berker Integro Design Flow patch panel with socket insertion 87
7.4.3 Patch panel with FLF socket insertion 89
7.4.4 FLF socket holder UM00H0 91
7.4.5 Set VZ00APZ with socket and bracket 93
7.4.6 Volta VZ00AS / VZ00ASF multisocket 93
7.4.7 UM00Sx multimedia covers 94
7.4.8 UM00Mx multimedia sets 95
8 Internal system accessories 96
8.1 Coding 96
8.2 Internal system accessories in detail 97
8.2.1 Flange FZ428 for rear cable entry 97
