HA305
HA305
Load break switch 3P 100A
Technical characteristics
Architecture
Type of order Short thumb-grip
Number of poles 3 P
Type of pole 3 P
Type of case Fixed built-in
Functions
Reversing switch No
Configuration
Number of modules 6
Controls and indicators
Motor drive integrated No
Main electrical features
Rated operational voltage Ue 380 / 415 V
Frequency 50
Voltage
Rated insulation voltage 800 V
Rated impulse withstand voltage 8000 V
Electric current
Rated operational current in AC21category
B 100 A
Acceptable current rating with AC22
category A 100 A
Cut off current 10 kA
Rated current 100 A
Short-circuit current with gI-gG fuses 50 kA
Rated short-time withstand current 1s 2.5 kA
Rated operational current in AC21 category
A 100 A
Acceptable current rating with AC22
category B 100 A
Rated operational current in AC23 category
A 63 A
Acceptable current rating with AC23
category B 63 A
Dimensions
Width of installed product 108 mm
Subject to technical modifications
Power
Total power loss under IN 9.3 W
Power loss per pole at In 3.1 W
Contact rating with 400 V in AC1 65 kW
Cover, door
Interlockable Yes
Installation, mounting
Fixation type DIN rail monting or back plate monting
Connection
Connection cross-sect. rigid cable 50mm² max.
Type of connection with screw
Equipment
Number of auxiliary contacts as normally
closed contact 0
Number of auxiliary contacts as normally
open contact 0
Number of auxiliary contacts as change-
over contact 0
Motor drive optional No
Standards
European directive WEEE concerned
Safety
Protection index IP IP20
Use conditions
Operating temperature -20…70 °C
Identification
meta_keyword
Switch disconnector;Load disconnecting switch;Main
switch;Switch;Disconnector
Subject to technical modifications
