HDBitT HDMI over Fiber Optic Extender
User Manual
Important safety notice
Please read below safety instructions carefully before installation and operation:
Please pay attention to all the warnings and hints on this device.
Do not expose this unit to rain, moisture and liquid.
Do not put any stuff into the device.
Do not repair or open this device without professional people’ s guidance.
Make sure good ventilation openings to avoid product overheating damage.
Shut off power and make sure environment is safe before installation.
Do not plug-in/out the network cables and IR cables when it is in using to avoid cables
damage.
Use DC5V only. Make sure the specification matched if using 3rd party DC adapters.
1 Introduction
This HDMI over fiber optic incorporates HDBitT transport technology, allowing you to extend
20KM distance between the source device to display end and supporting IR pass back function. It
can be widely applied in video conference, medical system, shopping mall, multimedia
presentation etc filed.
2 Features
1. Single mode fiber optic transmission.
2. No need extra installation driver
3. Transmit 1080p signal up to 20KM
4. Support IR pas back for easy control
5. Avoid the electromagnetic interference in environment for long distance transmission
6. - Low signal loss, wide frequency band and strong anti interference
7. High- end aluminum alloy enclosure design
8. - Wall mountable design for convenient installation
3 PACKAGE CONTENTS
HDMI extender TX*1pcs
HDMI extender RX*1pcs
DC5V2A*2pcs
IR blaster extension cable*1pcs
IR receiver extension cable*1pcs
User’ s manual*1pcs
4 INSTALLATION REQUIREMENTS
1. Source device with HDMI output port(computer graphics card, DVD,PS3, HD monitor
equipment etc)
2. Display device with HDMI input port (HDTV, projector)
3. HDMI cable and single mode fiber optic cable
5 Panel description
1. Rear panel of HDMI extender TX
①power input (DC5V)
②HDMI signal input
③IR blaster extension cable port
④fiber optic signal send port
2. Rear panel of HDMI extender RX
①power input (DC5V)
②HDMI signal output
③IR receiver extension cable port
④fiber optic signal receive port
3.Front Panel of TX and RX
①Power status indicator
②Network connection indicator
③Data transmission indicator
④Reset button
6 Connection and operation
