Side 1/22

Quick guide

SLIDING RUNNERS AND SHELF GUIDES

Before using the oven remove the protective tape [a] and then

remove the protective foil [b] from the sliding runners.

REMOVING THE SLIDING RUNNERS [c]

Pull the lower part of the sliding runner to uncouple the lower

hooks (1) and pull the the sliding runners upwards, removing

them from the upper hooks (2).

REFITTING THE SLIDING RUNNERS [d]

Hook the upper hooks on the shelf guides (1) then press the

lower part of the sliding runners against the shelf guides, until

the lower hooks are clicking (2).

[c] [d]

REMOVING AND REFITTING THE SHELF GUIDES

1. To remove the shelf guides, rmly grip the external part of the

guide, and pull it towards you to extract the support and the

two internal pins from the lodging.

2. To reposition the shelf guides, position them near the cavity

and initially insert the two pins into their lodgings. Next,

position the external part near its lodging, insert the support,

and rmly press towards the wall of the cavity to make sure the

shelf guide is properly secured.

FIRST TIME USE

1. SETTING THE TIME

You will need to set the time when you switch on the appliance

for the rst time: Press icon and the two digits until the

for the hour start ashing on the display.

Use or to set the hour and press to conrm. The two

digits for the minutes will start ashing. Use o to set the

minutes and press to conrm.

Please note: When the icon is flashing, for example following

lengthy power outages, you will need to reset the time.

2. SET THE POWER CONSUMPTION

By default the oven is programmed to work at a power higher

than 3 kW (Hi): To operate the oven at a power that is compatible

with a domestic power supply less than 2,9 kW (Lo), you will

need to change the settings.

To go to the change menu, turn the selection knob to , then

turn it back to .

Press and hold for ve seconds immediately and

afterwards.

THANK YOU FOR BUYING A HOTPOINT-

ARISTON PRODUCT

In order to receive a more complete

assistance, please register your product on

www . hotpoint . eu/register

Before using the appliance carefully read the Safety

Instruction.

CONTROL PANEL DESCRIPTION

1 32 4 5 6

1. SELECTION KNOB

For switching the oven on by selecting a

function.

Turn to the position to switch the oven

o.

2. LIGHT

With the oven switched on, press to turn

the oven compartment lamp on or o.

3. SETTING THE TIME

For accessing the cooking time settings,

delayed start and timer.

For displaying the time when the oven is

o.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time settings

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions.

For automatic functions keep on /A.

Use o to change the setting, then press and hold for at

least two seconds to conrm.

3. HEAT THE OVEN

A new oven may release odors that have been left behind

during manufacturing: this is completely normal. Before starting

to cook food, we therefore recommend heating the oven with it

empty in order to remove any possible odors.

Remove any protective cardboard or transparent lm from the

oven and remove any accessories from inside it.

Heat the oven to 250 °C for about one hour. The oven must be

empty during this time.

Please note: It is advisable to air the room after using the appliance

for the first time.

FUNCTIONS & DAILY USE

CONVENTIONAL

For cooking any kind of dish on one shelf only.

FORCED AIR

For cooking dierent foods that require the same cooking

temperature on several shelves (maximum three) at the same

time. This function can be used to cook dierent foods without

odours being transferred from one food to another.

MAXI COOKING

For cooking large joints of meat (above 2.5 kg). We

recommend turning the meat over during cooking to ensure

that both sides brown evenly. We also recommend basting the

joint every so often to prevent it from drying out excessively.

PIZZA

For baking dierent types and sizes of pizza and bread. It

is a good idea to swap the position of the baking trays halfway

through cooking.

GRILL

For grilling steaks, kebabs and sausages, cooking

vegetables au gratin or toasting bread. When grilling meat, we

recommend using a Baking tray to collect the cooking juices:

position the pan on any of the levels below the wire shelf and

add 500 ml of drinking water.

TURBO GRILL

For roasting large joints of meat (legs, roast beef, chicken).

We recommend using a Baking tray to collect the cooking juices:

position the pan on any of the levels below the wire shelf and

add 500 ml of drinking water.

RISING

For helping sweet or savoury dough to rise eectively. Turn

the thermostat knob to the icon to activate this function.

ECO FORCED AIR

For cooking roasts and stued roasting joints on a single

shelf. Food is prevented from drying out excessively by gentle,

intermittent air circulation. When this ECO function is in use, the

light will remain switched o during cooking but can be switched

on again by pressing .

BREAD AUTO

This function automatically selects the ideal temperature

and baking time for bread. For best results, carefully follow the

recipe. Activate the function when the oven is cold.

PASTRY AUTO

This function automatically selects the ideal temperature

and baking time for cakes. Activate the function when the oven

is cold.

AUTOMATIC OVEN CLEANING - PYRO

For eliminating cooking spatters using a cycle at very high

temperature.

1. SELECT A FUNCTION

To select a function, turn the to the symbol for selection knob

the function you require: the display will light up and an audible

signal will sound.

2. ACTIVATE A FUNCTION

To start the function you have selected, turn the thermostat knob

to set the temperature you require.

To interrupt the function at any time, switch o the oven, turn

the selection knob and the .thermostat knob to

Please note: During cooking you can change the function by

turning the selection knob or adjust the temperature by turning

the thermostat knob.

The function will not start if the thermostat knob is on 0 °C. You can

set the cooking time, cooking end time (only if you set a cooking

time) and a timer.

AUTOMATIC

To start the automatic function you have selected (“Bread”

or “Pastry”), keep the thermostat knob at the position for

automatic functions ( /A).

To nish cooking, turn the selection knob to position .

Please note: You can set the cooking end time and timer.

RISING

To start the “Rising” function, turn the thermostat knob to the

relevant symbol; if the oven is set to a dierent temperature, the

function will not start.

Please note: You can set the cooking time, cooking end time (only

if you set a cooking time) and a timer.

3. PREHEATING AND RESIDUAL HEAT

Once the function starts, an audible signal and a ashing icon

on the display indicate that the preheating phase has been

activated. At the end of this phase, an audible signal and the

xed icon on the display will indicate that the oven has

reached the set temperature: at this point, place the food inside

and proceed with cooking.

Please note: Placing the food in the oven before preheating has

finished may have an adverse effect on the final cooking result.

After cooking and with the function deactivated, the icon

may continue to remain visible on the display even after the

cooling fan has switched o to indicate that there is residual

heat in the compartment.

Please note: The time after which the icon switches off varies

because it depends on a series of factors such as ambient

temperature and function used. In any case, the product should be

considered to be off when the pointer on the selection knob is at

“ ”.0

4. PROGRAMMING COOKING

You will need to select a function before you can start

programming cooking.

DURATION

Keep pressing until the icon and “00:00” start ashing

on the display.

Use or to set the cooking time you require, then press

to conrm.

Activate the function by turning the thermostat knob to the

temperature you require: an audible signal will sound and the

display will indicate that cooking is complete.

Notes: To cancel the cooking time you have set, keep pressing

until the icon starts flashing on the display, then use

to reset the cooking time to “00:00”. This cooking time includes a

preheating phase.

PROGRAMMING THE END COOKING TIME/DELAYED START

After a cooking time has been set, starting the function can be

delayed by programming its end time: press until the icon

and the current time start ashing on the display.

Use or to set the time you want cooking to end and press

to conrm.

Activate the function by turning the thermostat knob to the

temperature you require: the function will remain paused until

it starts automatically after the period of time that has been

calculated in order forcooking to nish at the time you have set.

Notes: To cancel the setting, switch the oven off by turning the

selection knob to the position.

END OF COOKING

An audible signal will sound and the display will indicate that

the function has nished.

position “ ” to switch the oven o.

Please note: If the timer is active, the display will show “END”

alternately with the remaining time.

5. SETTING THE TIMER

This option does not interrupt or program cooking but allows

you to use the display as a timer, either during while a function is

active or when the oven is o.

Keep pressing until the icon and “00:00” start ashing on

the display.

Use or to set the time you require and press to conrm.

An audible signal will sound once the timer has nished

counting down the selected time.

Notes: To cancel the timer, keep pressing until the icon

starts flashing, then use to reset the time to “00:00”.

6. AUTOMATIC CLEANING FUNCTION – PYRO

Do not touch the oven during the Pyro cycle.

Keep children and animals away from the oven during and

after (until the room has nished airing) running the Pyro

cycle.

Remove all accessories - including shelf guides - from the oven

before activating the function. If the oven is installed below

a hob, make sure that all the burners or electric hotplates are

switched o while running the self cleaning cycle.

For optimum cleaning results, remove excessive residuals

inside the cavity and clean the inner door glass before using

the pyrolytic function. We recommend only running the Pyro

function if the appliance contains heavy soiling or gives o bad

odors during cooking.

To activate the automatic cleaning function, turn the selection

knob and the thermostat knob to the icon. The function will

be activated automatically, the door locked and the light inside

the oven switched o: The display will show the time remaining

to the end, alternating with “PYRO”.

Once the cycle has been completed, the door remains locked

until the temperature inside the oven has returned to a safe

level. Air the room during and after running the Pyro cycle.

COOKING ABLE T

RECIPE FUNCTION PREHEAT TEMPERATURE

(°C)

DURATION

(MIN)

LEVEL AND

ACCESSORIES

Leavened cakes

Yes 170 30 - 50 2

Yes 160 30 - 50 2

Yes 160 40 - 60 4 1

Biscuits/tartlets

Yes 160 25 - 35 3

Yes 150 35 - 45 4 2

Pizza / Focaccia

Yes 190 - 250 15 - 50 1/2

Yes 190 - 250 20 - 50 4 2

Lasagne / baked pasta / cannelloni / ans 190 - 200 45 - 65Yes 2

Turn the selection nob k to select a different function or to

Notes: Delay to start functionality is not available for Grill and

Turbo Grill functions.

Produkspesifikasjoner

Merke:	Hotpoint
Kategori:	Stekeovn
Modell:	FA5 841 P IX HA

Trenger du hjelp?

Hvis du trenger hjelp med Hotpoint FA5 841 P IX HA still et spørsmål nedenfor, og andre brukere vil svare deg

Ditt navn*

Din e-post*

Skriv spørsmålet ditt her

Stekeovn Hotpoint Manualer

Hotpoint FIT 804 H AV HA Bruksanvisning

15 Desember 2024

Hotpoint PCN 640 T (AN) R /HA Bruksanvisning

14 Desember 2024

Hotpoint FIT 834 AN HA Bruksanvisning

14 Desember 2024

Hotpoint PCN 750 T (OW) R /HA Bruksanvisning

14 Desember 2024

Hotpoint FA4S 544 IX HA Bruksanvisning

14 Desember 2024

Hotpoint FIT 834 AV HA Bruksanvisning

14 Desember 2024

Hotpoint FA5S 841 J IX HA Bruksanvisning

14 Desember 2024

Hotpoint FA3S 844 P IX HA Bruksanvisning

14 Desember 2024

Hotpoint FA3S 844 IX HA Bruksanvisning

14 Desember 2024

Hotpoint HS5G5CHW/IT Bruksanvisning

14 Desember 2024

Stekeovn Manualer

Nyeste Stekeovn Manualer

Philco PHD 64 TB Bruksanvisning

17 Desember 2024

Philco PHS 692 DC Bruksanvisning

17 Desember 2024

Philco PHS 604 DC Bruksanvisning

17 Desember 2024

Riviera Bar QFR300 Bruksanvisning

17 Desember 2024

Privileg BAKO Turn&Go Steam 500 Bruksanvisning

17 Desember 2024

Thetford XL Duplex SOG10 series Bruksanvisning

17 Desember 2024

Exquisit EHE 155-2 UBZ Bruksanvisning

17 Desember 2024

Thetford Triplex SHB70 series Bruksanvisning

17 Desember 2024

Thetford SHG40 series Bruksanvisning

17 Desember 2024

Exquisit EHE 146-2.1 Bruksanvisning

17 Desember 2024
