Installation instructions
Electronic pressure sensor
PC90xx
706296 / 00 12 / 2019
UK
2
Contents
1 Preliminary note 2 ���������������������������������������������������������������������������������������������������
1�1 Symbols used 2 ������������������������������������������������������������������������������������������������
2 Safety instructions 2 �����������������������������������������������������������������������������������������������
3 Functions and features 3 ����������������������������������������������������������������������������������������
4 Einsatzbereich �����������������������������������������������������������������������������������������������������3
5 Function ���������������������������������������������������������������������������������������������������������������4
6 Installation������������������������������������������������������������������������������������������������������������5
7 Electrical connection 5 ��������������������������������������������������������������������������������������������
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference
Information
Supplementary note
2 Safety instructions
• The device described is a subcomponent for integration into a system�
- The manufacturer is responsible for the safety of the system�
- The system manufacturer undertakes to perform a risk assessment and to
create documentation in accordance with legal and normative requirements
to be provided to the operator and user of the system� This documentation
must contain all necessary information and safety instructions for the operator,
the user and, if applicable, for any service personnel authorised by the
manufacturer of the system�
3
UK
• Read this document before setting up the product and keep it during the entire
service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and features).
• Only use the product for permissible media (→ Technical data).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
• Installation, electrical connection, set-up, programming, configuration, operation
and maintenance of the product must be carried out by personnel qualified and
authorised for the respective activity�
• Protect units and cables against damage�
3 Functions and features
The pressure sensor detects the system pressure and converts it into an analogue
output signal�
4 Einsatzbereich
Type of pressure: relative pressure
Order no. Measuring range Permissible
overload pressure *)Bursting pressure
bar PSI bar PSI bar PSI
PC9050 0���400 0…5800 600 8700 1600 23200
PC9010 0���345 0���5000 600 8700 1600 23200
PC9023 0���44,8 0���650 200 2900 1000 1450
PC9014 0���20,7 0���300 60 870 600 8702
*) With static overload pressure or max� 100 million pressure cycles�
MPa = (measured value in bar) ÷ 10
kPa = (measured value in bar) x 100
