Side 1/17

Operating instructions
Pressure sensor
PN52xx
704790 / 00 05 / 2010
UK

2
Contents
1 Preliminary note 3 ���������������������������������������������������������������������������������������������������
1�1 Symbols used 3 ������������������������������������������������������������������������������������������������
2 Safety instructions 3 �����������������������������������������������������������������������������������������������
3 Functions and features 4 ����������������������������������������������������������������������������������������
4 Function ���������������������������������������������������������������������������������������������������������������5
4�1 Processing of the measured signals 5 ��������������������������������������������������������������
4�2 Switching function 5 ������������������������������������������������������������������������������������������
5 Installation������������������������������������������������������������������������������������������������������������6
6 Electrical connection 6 ��������������������������������������������������������������������������������������������
7 Operating and display elements 7 �������������������������������������������������������������������������
8 Menu ��������������������������������������������������������������������������������������������������������������������8
8�1 Menu structure 8 ����������������������������������������������������������������������������������������������
8�2 Explanation of the menu 9 ��������������������������������������������������������������������������������
9 Parameter setting 10 ����������������������������������������������������������������������������������������������
9�1 Parameter setting general 10 ���������������������������������������������������������������������������
9�2 Configuring the display (optional) 12 ����������������������������������������������������������������
9�3 Setting the output signal 12 ������������������������������������������������������������������������������
9�3�1 Setting the output function 12 �����������������������������������������������������������������
9�3�2 Setting the switching limits 12 ����������������������������������������������������������������
9�4 User settings (optional) 12 ��������������������������������������������������������������������������������
9�4�1 Setting the delay time for OUT1 12 ���������������������������������������������������������
9�4�2 Setting the damping for OUT1 12 ������������������������������������������������������������
9�5 Service functions 13 �����������������������������������������������������������������������������������������
9�5�1 Reading the min�/max� values for the system pressure 13 ����������������������
10 Operation ���������������������������������������������������������������������������������������������������������13
10�1 Read the set parameter values 13 �����������������������������������������������������������������
10�2 Fault indication 13 ������������������������������������������������������������������������������������������
11 Scale drawing 14 ��������������������������������������������������������������������������������������������������
12 Technical data 14 ��������������������������������������������������������������������������������������������������
12�1 Setting ranges 16 �������������������������������������������������������������������������������������������
13 Factory setting 17 �������������������������������������������������������������������������������������������������

3
UK
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of buttons, switches or indications
→Cross-reference
Important note
Non-compliance can result in malfunctions or interference�
2 Safety instructions
• Read this document before installing the unit� Ensure that the product is suita-
ble for your application without any restrictions�
• Non-adherence to the operating instructions or technical data can lead to
personal injury and/or damage to property�
• Inallapplicationscheckcomplianceoftheproductmaterials(→chapter12
Technical data) with the media to be measured�
• Use in gases at pressures > 363 PSI (25 bar) only after contacting the manuf-
acturer ifm�
For units with cULus approval and the scope of validity cULus:
The device shall be supplied from an isolating transformer having a secondary
Listed fuse rated as noted in the following table�
Overcurrent protection
Control-circuit wire size Maximum protective device rating
Ampere
AWG (mm2)
26 (0�13) 1
24 (0�20) 2
22 (0�32) 3
20 (0�52) 5
18 (0�82) 7
16 (1�3) 10
The Sensor shall be connected only by using any R/C (CYJV2) cord, having
suitable ratings�
