Side 1/4
FOR HOUSEHOLD USE ONLY
SPECIFICATION:
MODEL NO. : IDX- 2000S
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 2000 Watts
BOX DIMENSION : _____________
UNIT DIMENSION : _____________
GROSS WEIGHT : _____________
UNIT WEIGHT : _____________
IMPORTANT SAFEGUARD:
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Read all instructions carefully.
2. Do not use the Induction Cooker on any metal table.
3. Do not use the Induction Cooker next to devices, which react
sensitively to magnet (e.g. radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, ammable materials, etc. away from the
Induction Cooker and from the convenience outlet where the Induction
Cooker is plugged.
5. Before using the Induction Cooker, check if the voltage indicated
corresponds with the convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the cord is
damaged it should be replaced with the same type and size or bring the
Induction Cooker to the nearest Authorized Service Center.
7. Do not use the two-way socket with other appliance.
8. Do not place the unit near gas stove, an electric burner, in heated oven
or near any hot surface.
9. Do not touch the Induction Cooker and the power plug with wet hands.
10. Do not block the ventilation slots of the Induction Cooker. Keep a
minimum distance of 10cm to 20cm away from the wall or from other
items.
11. damaged, unplug The Induction Cooker’s surface is made of glass, if
immediately.
12. Do not insert objects like wires or tools into the ventilation slots, this
may cause electric shocks.
13. Do not allow the cord to touch the hot surface of the unit.
14. The Induction Cooker does not heat up during cooking, but the heat
from the cookware can be transferred to in the Induction Cooker. Do
not touch the hot surface of the glass.
15. Scientic tests have proven that Induction Cookers are safe to use.
However, persons with a pacemaker should keep a minimum distance
of 60cm from the unit while using.
1
7. Do not use caustic detergents to clean the unit. It may damage
the unit by chemical reaction.
8. Do not use benzene, thinner, scrubbing brush or polishing
powder to clean the induction cooker.
REMINDER: Please do not forget to ll up and send the
warranty card with receipt to our email address
imarexfb@evergoodinc.com
Distributed By: Topgadget Distributions, Inc.
2120 A.linao St., Malate, Manila
Made in China
6
TROUBLESHOOTING:
CLEANING AND MAINTENANCE:
1. Turn o the power and pull out the plug before cleaning.
2. Clean the unit after it cools down completely.
3. Select proper detergent to remove the dirt.
4. Use neat wet cloth to clean the unit after removing the dirt.
5. Do not clean the unit directly with water.
6. Clean the induction glass plate and pan before cooking,
otherwise, dirt after charring is dicult to clean and the plate
may get discoloration.
7. You may clean air vent or air entry’s dirt by vacuum cleaner to
suck up or by cotton. If there is dirt with oil, it is right to use
toothbrush with a little detergent to clean the surface. Never
clear inside with water or any kind of liquid.
5
16. Do not place any metal kitchen utensils, pan lids, knives or other
metal objects on the cooker. These may heat up when the
Induction Cooker is turned on.
17. Do not place any magnetic objects on the glass surface while the
Induction Cooker is in use.
18. To protect against electric shock, do not immerse the Induction
Cooker in water.
19. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliances by
person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
20. This induction cooker is intended for tabletop use only.
21. Do not use the Induction Cooker for other than intended use.
22. Not intended for outdoor use.
23. For household use only, not intended for any business purposes.
24. Save this instruction for future references.
HOW TO USE:
1. Connect power plug. Switch on the main power switch located
at the back portion of the unit. A “Beep” sound will be an
indication that the unit is in sleeping mode.
2. The power indicator Press “ON/OFF” key for standby mode.
turns red and digital display shows “----“.
3. Place the cookware in the center of the ceramic plate.
4. Power Setting: Press the “Power/Temp./Timer”. The digital
display shows “2000”, indicating the default power is 2000W.
Press “ ” or “+“ - key to adjust the power level. It can be adjusted
from 200W to 2000W.
Note: User can choose to adjust either “Power” or “Temp”.
5. Temp Setting: Press the “Power/Temp/Timer”. The digital
display shows “240”, indicating that the default temperature is
240°C. -Press “ ” or “+“ key to adjust the temperature. It can be
adjusted from 80°C to 240°C.
6. Timer Setting: Press the “Power/Temp./Timer” key. The digital
display shows “0:00”, indicating the default time is 0 minute.
Press “ ” or “+“ key to adjust the temperatu- re. It can be
adjusted from 0:01 to 4:00.
2
PROBLEM
POSSIBLE CAUSES
There is no warning sound
and the indicator light of
“on/off” does not light.
- Check whether the plug desquamate with
supply socket.
- Check the power supply switch or the fuse
open circuit.
- Check for power failure.
“E0”
- Check-Unusable cooking cookware.
- Check-No pot.
“E1”
- Check if the voltage too low.
- Check whether the socket is loose.
- Check is the line diameter is too small.
“E2”
- Check if the voltage too high.
“E5”
-Check whether the environment
temperature is very high or not.
- Check whether there is some block on the
air inlet or outlet. Whether the fan is working
or not.
-Check whether the keep warm temperature
is already
-Reached the temperature set or not.
- Check if the fan still working, it maybe the
adjustment of the unit itself, try it again after
10 minutes.
“E4”
-Check thermostat was broken.
“E6”
- Check radiator was broken.
“E3”
- Check-The pot has no water in.
“E7”
-Check-Line error.
