Thank you
for purchasing the Infinity Kappa Series
10.1t tweeter. We’ve organized this manual to make your installa-
tion as simple and trouble-free as possible. Please read it thor-
oughly before proceeding. Remember to keep your sales receipt
with this manual in a safe place so both are available for future
reference.
®
K
A P PA
S
ERIES
10.1t
I N S T R U C T I O N S
- 2 -
IMPORTANT:
Installation of automotive
stereo components can require extensive
experience with a variety of mechanical and
electrical procedures. Although these
instructions explain how to install a Kappa
10.1t in a general sense, they do not show
the exact installation methods for your par-
ticular vehicle. If you do not feel you have
the experience, do not attempt the installa-
tion yourself, but instead ask your
Authorized Infinity Car Audio Dealer about
professional installation options.
WARNING:
Playing loud music in an automo-
tive environment can permanently damage
your hearing, as well as hinder your ability
to hear traffic. The maximum volume levels
achievable with Infinity speakers, combined
with high power amplification, may exceed
safe levels for extended listening. We rec-
ommend using low volume levels when dri-
ving. Infinity accepts no liability for hearing
loss, bodily injury or property damage as a
result of use or misuse of this product.
S PPEAKER LACEMENT
Kappa speakers are designed to be easily
installed in stock speaker locations. While
mounting your speakers in the original fac-
tory locations will, in most cases, provide
excellent sonic results, the best sounding
installations are a result of adherence to a
few basic rules.
• For the most spacious stereo image,
place the left and right speakers as far
apart as possible.
• For enhanced center image, place the
left and right speakers so they are
equidistant from the listening position.
If possible, try to place them as far
forward as possible.
• For best treble response when tweeters
are flush mounted in the I-Mount™, aim
them at the listening position by adjust-
ing the tweeter angle in the cup, tighten-
ing the small metal locking nut behind
the assembly and rotating the entire
assembly in its mounting location before
tightening the large plastic locking nut
behind the panel (see Fig 1, p.2).
INSTALLATION ARNINGS AND IPSW T
• Always wear protective eyewear when using
any tools.
• Turn off all audio systems and other electrical
devices before you start. Disconnect the (–) neg-
ative lead from your vehicle’s battery.
• Keep components in their package until final
installation. When moving a speaker, always
rest it with the cone or dome facing up. Never
use force to install any speaker.
• Check clearances on both sides of a planned
mounting surface before drilling any holes or
installing any screws. Remember that the
screws can extend behind the surface.
• At the installation sites, locate and make a note
of all fuel lines, hydraulic brake lines, vacuum
lines and electrical wiring. Use extreme caution
when cutting or drilling in and around these
areas.
CAUTION: In some cars, fuel tanks may be
located directly beneath the rear deck. Check
for adequate speaker basket clearance before
considering this location!
• Before drilling or cutting holes, use a utility
knife to remove unwanted fabric or vinyl, to
keep material from snagging in a drill bit or
saw.
• For door installations, check the clearance with
the windows throughout the range of the win-
dow’s travel, and verify that a mounted speaker
will not interfere with the window crank or
power window mechanism.
• If mounting components elsewhere, check for
clearance around rear-deck torsion bars, glove
box or other structural elements.
• Do not mount components where they will get
wet.
Figure 2. Use this template to flush-mount a
Kappa10.1t tweeter.
T IWEETER NSTALLATION
Figure 1. After installing the surface-mount plate, push the
Kappa10.1t onto the mounting plate to snap it into place.
DIAM. = 1.56"
(39.5 mm)
OPENING FOR
FLUSH-MOUNT
CUP
TRIM RING EDGE
- 3 -
Figure 3. After the Kappa10.1t tweeter is in its cup,
hand tighten the nut to flush-mount the assembly on
the panel.
NOTE:You must use the crossover supplied
with the 10.1t tweeter. The crossover is con-
tained in the shrink tube attached to the
included speaker wire. If you must shorten
the wire, do not remove the crossover, and
be sure that its orientation is correct (indi-
cated by position of connectors).
A NOTE ON P HOWER ANDLING
The Kappa 10.1t tweeters are designed to
produce reasonable volume levels with little
amplifier power. However, the addition of
an amplifier to drive your speakers and a
subwoofer will enhance the dynamic range
of your system, and help overcome the
ambient noise in a moving vehicle. Kappa
speakers are designed to handle the power
of a dedicated amplifier driven at or below
its rated power. If an amplifier is driven far
above its rated power, the output signal will
“clip,” and the additional power present in a
clipped signal can damage any speaker.
Distorted or “fuzzy” sound from your
speakers is an indication that the amplifier
has exceeded its rated power, and you
should reduce the volume level.
G CENERAL ARE
The loudspeaker grilles may be cleaned with a
slightly damp cloth. Do not use any cleaners or
solvents on the grilles or the speaker drivers.
SPECIFICATIONS
10.1t
Type: Component Tweeter
Speaker Impedance: 4 ohms
Power Handling: 50 watts per channel
with crossover
Frequency
Response (± 3dB): 8kHz ~ 22kHz
Sensitivity: 89Hz @ 2.83 V, 1 watt
Crossover Frequency: 8000Hz
Cut-out Diameter Tweeter: 1-5/8" (42 mm)
DECLARATION OF CONFORMITY
We, Infinity Systems A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
Steen Michaelsen
Infinity Systems A/S
Birkerød. DENMARK. 2/98
declare in own responsibility, that the product described in this owner’s manual is in compliance with technical standards:
EN 50 081-1/1992
EN 50 082-1/3.1995
®
Infinity Systems, Inc. • 250 Crossways Park Drive,
Woodbury, NY 11797 USA • (516) 496-3400 • FAX (516) 682-3583
