Thank you
for choosing the Kappa Perfect T.
The PerfectT has been designed to provide smooth
high-frequency reproduction, high power handling
and ease of installation.
This manual includes information that will make your
installation as simple and trouble-free as possible.
Please read this manual thoroughly before you begin
your installation. Don’t forget to send in your warranty
registration card, and keep your sales receipt some-
where safe in case you need warranty service.
perfectT
1"component tweeter
instructions
IMPORTANT
Installation of automotive stereo compo-
nents can require extensive experience per-
forming a variety of mechanical and electri-
cal procedures. Although these instructions
explain how to install a Kappa Perfect T
component system in a general sense, they
do not show the exact installation method
for your particular car. If you feel you may
not have the necessary tools or experience,
ask your authorized Infinity car-audio dealer
about professional installation options.
WARNING
Playing loud music in an automobile can
permanently damage your hearing as well
as hinder your ability to hear traffic. We
recommend listening at a low volume while
driving. Infinity accepts no liability for hear-
ing loss, bodily injury or property damage
resulting from use or misuse of this product.
S PPEAKER LACEMENT
Figures 1 & 2 show possible speaker
placements in the order of more desirable
to less desirable. Kick-panel mounting will
provide the best staging and imaging in
most vehicles.
A NOTE ROSSOVER PPLICATIONABOUT C A
Passive crossover design involves precise
circuit design and component selection. A
well-designed crossover circuit provides an
electrical response intended to be combined
with the electrical properties of the speaker
to provide a particular acoustic response.
The crossover included with the PerfectT
has been optimized to provide flat response
when used with the PerfectT. Do not use the
PerfectT with a passive crossover intended
for use with another tweeter, or connect
more than one tweeter to the crossover
provided with the PerfectT.
T IWEETER NSTALLATION
TWEETER
and
WOOFER
on kick panel
TWEETER
on kick panel
WOOFER
in factory-
door location
Figure 1.
Mounting the woofer and tweeter in
the kick panel
Figure 2.
Mounting the woofer in the door and
the tweeter in the kick panel
Figure 3.
Mounting the tweeter in the doors
1
2
–
+
1
2
Figure 4.
Surface-mounting the tweeter
Figure 5.
Flush-mounting the tweeter
- 2 -
1
2
(+) BIG LUG & RED WIRE
(-) SMALL LUG & BLK WIRE
(+) RED WIRE
(-) BLK WIRE
- 3 -
SPECIFICATIONS
System
Frequency response: 3.5kHz 21kHz, ±3dB–
Power handling: 100W RMS, 400W Peak
(with HPF provided)
Nominal impedance: 4 Ohms
Sensitivity: 90dB
Crossover frequency: 3.5kHz
Thiele and Small Parameters
Revc: 3.31 Ohms
Levc: .02mH
Sd: .0005M3
Vas: .0016 liters
Cms: 44 uM/N
Mms: .3064g
Mmd: .3g
Fs: 1370.65Hz
Qms: 5.4
Qes: 2.19
Qts: 1.56
Voice-coil diameter: 1" (25.4mm)
Mounting depth: 1-3/16" (31mm)
Cut-out diameter: 1-3/4" (45mm)
G CENERAL ARE
The loudspeaker grilles may be cleaned with
a damp cloth. Do not use any cleaners or
solvents on the grilles or the speaker cones.
