Les nedenfor 📖 manual på norsk for Infinity Reference 5032CF (2 sider) i kategorien Bilhøyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/2
3-7/8"
98mm
5-1/8"
129mm
3-3/16"
80mm
4-3/4"
120mm
2-1/4"
57mm
9/16"
29mm
1-3/4"
44mm
R E F E R E N C E
5032i
5032cf
5032gr
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage. Un numéro de série valable est exigé pour la couverture de la garantie.
Features,specifications and appearance are subject to change without notice.
Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division, 8500 Balboa Boulevard, Northridge, CA 91329 USA
www.infinitysystems.com
© 2009 Harman International Industries, Incorporated.All rights reserved.Tous droits réservés.s Part No.REF5032OM1/09
Infinity is a trademark of Harman International Industries,Incorporated,registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries, Incorporated,déposée aux États-Unis et/ou dans d’autres pays.
Declaration of Conformity
We,Harman Consumer Group, Inc.
2,route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group,Inc.
Château du Loir,France 1/09
5032i 5032cf
BL (T-m) 3.25 3.25
DCR (ohms) 2.30 2.30
Mms (g) 10.22 10.22
Sd (sq cm) 103.9 103.9
Cms (μm/N) 521 521
Vas (l) 7.89 7.89
Fs (Hz) 69.0 69.0
Qes 0.96 0.96
Qms 6.94 6.94
Qt 0.85 0.85
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf” version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling, Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling,RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5032i 5032cf 5032gr
Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY
2-Way 2-Way for 5-1/4" (130mm)
NO GRILLE
Impedance: 2 Ohms 2 Ohms
Power Handling, RMS: 45W 45W
Power Handling,Peak: 135W 135W
Frequency Response: 67Hz – 21kHz 67Hz – 21kHz
Sensitivity (2.83V, 1m): 92dB 92dB
Grilles are included with the “i” version; they are optional for the “cf”version
(use Reference model 5032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
2x
5032gr
1x
2x
2x
5032i
1x
2x
5032cf
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB”position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB”position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB”position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB”position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB”position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch.The normal setting for
this switch is the “0dB”position, which pro-
vides an apparently “flat” response.Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
ROTATING TWEETER
The Reference 5032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely high
frequencies, aiming the tweeter toward the
listening position will improve high-frequency
response and stereo imaging.
Before securing
the grille,
grasp the tweeter housing around
the edge and rotate the tweeter assembly
so that the tweeter faces the listener as
directly as possible.Then the grille may be
permanently secured.
Produkspesifikasjoner
| Merke: | Infinity |
| Kategori: | Bilhøyttaler |
| Modell: | Reference 5032CF |
Trenger du hjelp?
Hvis du trenger hjelp med Infinity Reference 5032CF still et spørsmål nedenfor, og andre brukere vil svare deg
Bilhøyttaler Infinity Manualer
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
19 Desember 2024
Bilhøyttaler Manualer
- Bilhøyttaler AudioControl
- Bilhøyttaler Kicker
- Bilhøyttaler Blaupunkt
- Bilhøyttaler Boss
- Bilhøyttaler Focal
- Bilhøyttaler Mtx Audio
Nyeste Bilhøyttaler Manualer
27 Oktober 2024
27 Oktober 2024
26 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
16 Oktober 2024
