Les nedenfor 📖 manual på norsk for Infinity Reference 6032CF (2 sider) i kategorien Bilhøyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/2
4-1/4"
110mm
6-1/4"
159mm
3-9/16"
90mm
5"
127mm
2-1/16"
52mm
3/4"
19mm
1-3/4"
44mm
4-1/4"
110mm
6-1/4"
159mm
3-3/16"
80mm
5"
127mm
1-15/16"
49mm
7/16"
11mm
1-3/4"
44mm
6032i/6032cf 6032si
R E F E R E N C E
6032i
6032cf
6032si
6032gr
Declaration of Conformity
We, Harman International, Consumer Division
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 1/09
6032i 6032cf 6032si
BL (T-m) 4.00 4.00 4.30
DCR (ohms) 2.30 2.30 2.30
Mms (g) 12.98 12.98 12.69
Sd (sq cm) 132.7 132.7 132.7
Cms (μm/N) 277 277 221
Vas (l) 6.85 6.85 5.47
Fs (Hz) 83.9 83.9 95.0
Qes 0.98 0.98 0.94
Qms 6.16 6.16 7.89
Qt 0.85 0.85 0.84
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
