Side 1/2

4-1/4"

110mm

6-3/16"

156mm

6-7/16"

163mm

4-3/8"

110mm

8-15/16"

226mm

6-11/16"

169mm

9-3/8"

237mm

3-1/16"

77mm

7/8"

21mm

3-11/16"

92mm

R E F E R E N C E

9633i

9633cf

9633gr

Declaration of Conformity

We,Harman Consumer Group,Inc.

2,route de Tours

72500 Château du Loir

France

declare in own responsibility that the products described in this owner’s

manual are in compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Klaus Lebherz

Harman Consumer Group,Inc.

Château du Loir,France 1/09

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6" x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling, RMS: 100W 100W

Power Handling, Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product,please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product,please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

9633i 9633cf

BL (T-m) 4.30 4.30

DCR (ohms) 2.30 2.30

Mms (g) 21.70 21.70

Sd (sq cm) 236.4 236.4

Cms (μm/N) 442 442

Vas (l) 34.69 34.69

Fs (Hz) 51.4 51.4

Qes 0.87 0.87

Qms 6.34 6.34

Qt 0.77 0.77

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i” version; they are optional for the “cf” version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6" x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i” version; they are optional for the “cf” version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf”version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf” version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6"x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf” version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

9633i 9633cf 9633gr

Type: 6" x 9" 3-Way 6"x 9" 3-Way NO GRILLE GRILLE ONLY for 6" x 9"

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 100W 100W

Power Handling,Peak: 300W 300W

Frequency Response: 46Hz – 30kHz 46Hz – 30kHz

Sensitivity (2.83V, 1m): 94dB 94dB

Grilles are included with the “i”version; they are optional for the “cf” version (use Reference model 9633gr).

WARRANTY:

Reference Series speakers are warranted against defects.The duration of the

speaker’s warranty depends on the laws in the country in which it was purchased.Your local Infinity car

audio retailer can help you determine the length of your warranty.To register your product, please visit us

at www.infinitysystems.com.

Designed and engineered in the USA. Conception et design aux É.U.A.

A valid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.

Features, specifications and appearance are subject to change without notice.

Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.

Harman International, Consumer Division, 8500 Balboa Boulevard, Northridge, CA 91329 USA

www.infinitysystems.com

Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.

Infinity est une marque commerciale de Harman International Industries, Incorporated, déposée aux États-Unis et/ou dans d’autres pays.

9633gr

2x 1x

9633i

9633cf

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position),by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

TWEETER-LEVEL

CONTROL

This speaker system is equipped with a

tweeter-level switch.The normal setting for

this switch is the “0dB” position, which pro-

vides an apparently “flat” response.Tweeter

output may be increased according to the

user’s preference, or to compensate for off-

axis placement (where the speaker does not

directly face the listening position), by set-

ting the switch to the “+3dB” position.

Produkspesifikasjoner

Merke:	Infinity
Kategori:	Bilhøyttaler
Modell:	Reference 9633cf

Trenger du hjelp?

Hvis du trenger hjelp med Infinity Reference 9633cf still et spørsmål nedenfor, og andre brukere vil svare deg

Ditt navn*

Din e-post*

Skriv spørsmålet ditt her

Bilhøyttaler Infinity Manualer

Infinity Kappa 572.5CF Bruksanvisning

19 Desember 2024

Infinity Kappa 692.9I Bruksanvisning

19 Desember 2024

Infinity Kappa 462.5CFP Bruksanvisning

19 Desember 2024

Infinity Kappa 682.7CF Bruksanvisning

19 Desember 2024

Infinity Kappa 462.7CFP Bruksanvisning

19 Desember 2024

Infinity Kappa 652.9I Bruksanvisning

19 Desember 2024

Infinity Kappa 572.1CF Bruksanvisning

19 Desember 2024

Infinity Kappa 652.1I Bruksanvisning

19 Desember 2024

Infinity Kappa 65.7CS Bruksanvisning

19 Desember 2024

Infinity Kappa 652.7I Bruksanvisning

19 Desember 2024

Bilhøyttaler Manualer

Nyeste Bilhøyttaler Manualer

Focal ISUB MBZ 2 LHD v2 Bruksanvisning

27 Oktober 2024

Focal ISUB MBZ 2 RHD v2 Bruksanvisning

27 Oktober 2024

AudioControl PNW-XN3 Bruksanvisning

26 Oktober 2024

Kicker 51KSC6504 Bruksanvisning

16 Oktober 2024

Kicker 51KSC6704 Bruksanvisning

16 Oktober 2024

Kicker 51KSC504 Bruksanvisning

16 Oktober 2024

Kicker 51KSC6804 Bruksanvisning

16 Oktober 2024

Kicker 51KSC404 Bruksanvisning

16 Oktober 2024

Kicker 51KSS369 Bruksanvisning

16 Oktober 2024

Kicker 50CSC4104 Bruksanvisning

16 Oktober 2024
