Side 1/14
User GUide
Ms-A5001
Digital signal processing ampli๏ฌer
123 4
๎
๎
๎๎๎๎๎ ๎๎๎๎๎๎
๎
๎
๎๎ ๎๎ ๎๎๎
๎๎๎๎๎
๎๎๎๎๎
40 A
40 A
2X40A
2 x 40A
+
-
1 x 80A
๎
๎๎๎๎๎
๎
๎
๎
๎
๎
๎๎๎๎
๎
๎๎๎๎๎
๎๎ ๎๎ ๎๎๎
๎
๎๎๎๎
๎
๎
1
3
6
5
8
8
9 10
10
11
11
2
1 Input-Level Control
This control is used to match
the input sensitivity to the signal
voltage for proper analog-to-
digital conversion. See page 7 for
details. DO NOT use this control
to set the relative output level of
amplifier channels!
2 Input Signal Selector
Lo/Hi/Hi2 sets input voltage and
impedance range. See page 7 for
details.
Audio Inputs
Use RCA audio cables for
preamp-level connections or
attach the included RCA to bare
wire adapters for speaker-level
input connections.
4
Pass-Through Outputs
Input channel 1 sends signals to
Output 1. Input channel 2 sends
signals to Output 2. The
MS-A5001โs filter settings do not
affect these channels.
5 Onboard Fuses
2 x 40A ATC type.
6
Display Panel
Displays the amplifierโs settings.
7
User Controls
These controls allow you to adjust
the amplifierโs settings. See page
9 for details.
8 +12V Power Input
Connects to your vehicleโs battery
with a 80A fuse within 18 inches
(45.7cm) of the batteryโs positive
terminal.
9 Remote Turn-On Input
Connects switched +5V to
+12V. Note: The MS-A5001 also
includes signal-sensing turn-on.
You may choose the turn-on
method during setup. See pages
5 and 9-10 for details.
10 Chassis Ground Input
Connect to a paint-free spot on
the vehicle chassis.
Speaker Outputs
Two mono speaker outputs.
These outputs send the same
output signal (in parallel) for
the added convenience of
connecting multiple subwoof-
ers. Be sure to account for
parallel resistance connections
when you determine the load on
the MS-A5001โs output. Do not
connect loads below a total of
two ohms.
Ms-A5001 FeATUres
3
11
3
FCC REGULATIONS
Caution:
Changes or modi๏ฌcations not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
Compliance statement:
1: This device is veri๏ฌed to comply with Part 15 of the FCC Rules. Operation subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
2: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,there is no guarantee that interference will not
occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
โข Reorient or relocate the receiving antenna.
โข Increase the separation between the equipment and receiver.
โข Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
โข Consult the dealer or an experienced radio/TV technician for help.
F
F
T
n
c
R
T
F
T
in
n
b
m
โข
โข
โข
IC
T
n
I
B
p
a
Ms-A5001
diGiTAL siGNAL-PrOCessiNG AMPLiFier
PLeAse reAd THis BeFOre YOU BeGiN!
JBLยฎ MS-series amplifiers include many features not found on conventional car-audio amplifiers. As a result, the setup
procedure for JBL MS-series amplifiers is different from that of conventional car-audio amplifiers. The following
overview of features and functions will help you plan a great system and make the best use of the MS-A5001โs
innovative features.
About the digital signal processing (DSP) included in MS-series amplifiers:
All of the signal processing in MS-series amplifiers is digital. Digital signal processing, along with the amplifiersโ intuitive
controls and display, make precise setup easy. Only the input-level controls are analog.
Will I lose my settings if I disconnect the amplifier or the carโs battery?
No. The MS-A5001 stores all of the DSP settings in nonvolatile memory, so you will not lose any settings if power
is removed.
Why are the input-level controls analog?
In order to provide the best signal-to-noise ratio and to maximize the resolution of the digital-to-analog conversion,
the maximum input-signal level to the analog-to-digital (A/D) converters must be precisely set. The control that sets
the level must be an analog control. The included setup CD and the procedure described in this manual make setting
the level simple and precise. Once you set the input-level control, do not use the control to โtuneโ the system. Use the
digital output-level control to adjust the relative level between amplifier channels to tune the system.
