ASSEMBLING & INSTALLATION INSTRUCTIONS
The drawing shown may not exactly match the product enclosed.
However, the installation instructions do apply to this product.
53640
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER.
ATTENTION! COUPER LE COURANT AU FUSIBLE OU UN DISJONCTEUR.
ASSEMBLING THE FIXTURE (Fig.1)
1. Shut off the power at the circuit breaker box. Remove old fixture and
all hardware from Junction Box.
2. Carefully unpack your new fixture and lay out all the parts on a clear
area. Be care not to lose any small parts necessary for installation.
3. Attach the mounting plate to the Junction Box with the two junction
box screws as shown. The side of the mounting plate marked "GND"
must face out. The junction box is not included.
4. While holding the lamp body towards the ceiling, connect the
electrical wires as Shown in Fig.2, making sure that all wire nuts are
secured. You may have to wrap the connections with electrical tape.
If your junction box has a ground wire (green or bare copper),
connect the lamp body ground wire to it. Otherwise connect lamp
body’s ground wire directly to the mounting plate with the green
screw provided. After wires are connected, tuck them carefully
inside the Junction Box.
5. Install the lamp body’s canopy onto the junction box, aligning the
side screw hole on mounting plate with mounting holes in canopy,
lock it securely with the mounting screws.
6. Raise the glass up towards lamp body’s lamp holder, using check
ring secure until tight it.
7. Install the light bulb(not included) in accordance with the fixture’s
specifications. NOTE: DO NOT EXCEED THE SPECIFIED
WATTAGE!
Your installation is now complete. Return power to the junction
box and test the fixture.
WHITE
HOUSE
Black
WIRES
(Hot)
FIXTURE
WIRES
BLACK
WIRES
FIXTURE
Bare
FIXTURE
WIRES
(Ground)
HOUSE
(Neutral)
WIRES
White Green or
WIRES
HOUSE
Copper(Ground)
GREEN
Thread
Thank you for purchasing a LIVEX product.
Need assistance with parts or assembly? Please call customer service at: 800-761-8056
Or visit us online at: WWW.LIVEXLIGHTING.COM
©COPYRIGHT ALL RIGHTS RESERVED.LIVEX LIGHTING,INC. DOC20221053640
FIG.2
FIG.1
