PRODUCT SPECIFICATIONS
Lorex Corporation
10440 Little Patuxent Parkway, Ste, 300,
Columbia, MD 21044, United States
© 2023 Lorex Corporation
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to
modify product design, specifications & prices without notice and without incurring any obligation. E&OE.
(23-0075-LOR) 10242023-1
lorex.com
E842CA Series
Disclaimers:
1. Compatible with select Lorex Network Video Recorders HD recorders. For a full list of compatible recorders visit: www.lorex.com/compatibility
2. Color nighttime video typically switches to black & white IR night vision when there is not sufficient ambient light to ensure optimal low-light image quality.
3. Stated IR illumination range is based on ideal conditions in typical outdoor nighttime ambient lighting (up to 98ft/30m in total darkness). Actual range and image clarity depends on installation location, viewing area and light
reflection/absorption.
4. Audio recording is disabled by default. Audio recording without consent is illegal in certain jurisdictions. Lorex Technology does not assume liability for any use of its product that fails to conform with local laws.
5. Not intended for submersion in water. Installation in a sheltered location recommended.
6. Cable length is dependent on product configuration. See product packaging for details.
*A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing.
Lorex products are designed for consumer and business use only and not for US federal governments, federally-funded projects or contractors subject to NDAA.
4K IP Wired Bullet Camera
MODEL INFORMATION
E842CA White Camera Brown Box 6-95529-05145-1
E842CAB Black Camera Brown Box 6-95529-05144-4
Package Weight 2.84lb / 1.28kg
Package Dimensions
(W × D × H)
15.9 × 5.7 × 4.5” /
403 × 145 × 114mm
Package Cube 0.23cbf / 0.006cbm
General
Video Transmission
Technology IP
Image Sensor 1/2.7” 8 Megapixel progressive
CMOS)
Imager Type CMOS
Day/Night AUTO
Mechanical IR Cut Filter Yes
Effective Pixels H:3840 x V:2160
Optical
Viewing Angle H: 106°; V: 56°; D: 125°
Lens/Lens type 2.8mm F2.0/ Fixed-Focal
Video Output
Video Format NTSC
Video Compression H.265; H.264; H.264H; H.264B;
MJPEG (Only supported
by the sub stream)
Resolution Selection 3840 × 2160 (3840 × 2160); 3072
× 2048 (3072 × 2048);3072
×1728 (3072 × 1728); 2880 ×
1620 (2880 × 1620);2688 × 1520
(2688 × 1520); 3M (2048 × 1536);
2304×1296 (2304 × 1296); 1080p
(1920 × 1080); 1.3M (1280 ×960);
720p (1280 × 720); D1 (704 ×
576/704 × 480); VGA(640 × 480);
CIF (352 × 288/352 × 240)
Aspect Ratio 16 : 9
Dynamic Range 120 dB
Wide Dynamic Range True WDR
Gain Control Auto/Manual
Noise Reduction 3D DNR
Smart IR Yes
HDR Yes
Termination RJ45
Audio
Microphone/Speaker Yes/No
Siren No
Two-way Talk No
Night Vision
Ambient Nighttime
Conditions 150ft (45m)
Total Darkness 98ft (30m)
Color Night Vision Yes
Special Features
Smart Motion
Detection Plus Yes - Person and Vehicle
Detection
Additional Specifications
Camera Housing Material Metal
SD Card Slot Yes*
Power Requirements PoE (Power over Ethernet Class
-802.3af)/12V DC
Camera Dimensions
(W x D x H) 166.2 mm × 70 mm × 70 mm
(6.54” × 2.76” × 2.76”)
Camera Weight 0.48 kg (1.06 lb)
Operating Temperature -40°F (-40°C) ~ +140°F (+60°C)
Humidity ≤95%
Environmental Rating IP67
