Side 1/7
Overview
Type VCO
Size 10HP Eurorack
Depth
Power 2x8 Eurorack
+12 mA 150 / 80
-12 mA 5
Loquelic Iteritas is a digital VCO with interpretations of three classic
synthesis algorithms involving dual pitch control. It creates a huge variety
of sounds parameterized by four tone and two pitch controls.
1
Noise Engineering
Loquelic Iteritas
Complex Digital Oscilator
+5 mA 0 / 90 (optional)
“I could kill someone with that”
-- DJ Surgeon
“This thing sounds fucking amazing
lots of stuff I’ve never heard before”
-- Surachai
1 Inch
Before Serial 555 After Serial 555
Patch Tutorial
e easiest way to get to know Loquelic Iteritas is to turn the knobs and
listen. Connect the output to your mixer and start twiddling.
Loquelic Iteritas is about continuous tone control. Hook any LFO up to any
of the four tone control inputs (Morph, Fold, Modulate, Damp).
Other interesting effects can be created by controlling the pitches
independently (by default the 1v/8va inputs are normaled to each other). For
instance, using a Tonnetz Sequent to produce musical intervals produces
interesting results.
2
Noise Engineering
Loquelic Iteritas
Complex Digital Oscilator
Interface
Pitch A
e pitch of oscillator A can be controlled by the 1v/8va input and offset by
it’s coarse and ne knobs. e pitch inputs are cross normaled.
Pitch B
e pitch of oscillator B can be controlled by the 1v/8va input and offset by
it’s coarse and ne knobs. e pitch inputs are cross normaled.
Damp
is a tone control. Consult the following pages detailing each mode to nd the
behavior of this knob in the specic mode.
Mod
is a tone control. In all modes it controls phase modulation between the two
pitch oscillators.
Fold
is a tone control. In all modes it controls the threshold of the wavefolding.
Morph
is a tone control. In all modes it controls the waveform of the oscillator
continually varying between sin, triangle and saw.
Algorithm
selects which algorithm is used. ese are detailed on the following pages.
Master
controls the sync of the oscillators. When in the middle position both
oscillators are free running. When A is selected oscillator B will sync to
oscillator A. when B is selected A will sync to B.
Sync
Sync will reset the state of the oscillators on a rising edge. Used for sync
modulation. is jack was added starting at serial 700.
Out
Out is the AC coupled audio output.
3
Noise Engineering
Loquelic Iteritas
Complex Digital Oscilator
Produkspesifikasjoner
| Merke: | Noise Engineering |
| Kategori: | Synthesizer |
| Modell: | Loquelic Iteritas |
