Timex Weekender TW2P62100 Bruksanvisning
Les nedenfor 📖 manual på norsk for Timex Weekender TW2P62100 (3 sider) i kategorien Klokke. Denne guiden var nyttig for 5 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/3
1www.timex.com
www.timex.com
W-91
BAS IC OPERAT IONS
• 6 o’clock eye shows seconds.
• 10 o’clock eye shows “minutes elapsed” for chronograph.
• 2 o’clock eye shows “1/20 seconds elapsed” for chronograph.
• Chronograph second hand shows “seconds elapsed” for chronograph.
EXTENDED WARRANTY
Available in U.S. only. Extend your warranty for an additional 4 years from date of purchase
for $5. You can pay with AMEX, Discover, Visa or MasterCard by calling 1 800-448-4639 during
normal business hours. Payment must be made within 30 days of purchase. Name, address,
telephone number, purchase date, Yand 5-digit model number required. ou can also mail a
check for $5 to: Timex Extended Warranty, P.O. Box 1676, Dept. EF, Little Rock, AR 72203.
Please read instructions carefully to understand how to operate your Timex® watch.
Your model may not have all of the features described in this booklet.
THANK YOU FOR PURCHASING YOUR TIMEX® WATCH.
TIME
To set the time:
1. PULL crown out to “C” position.
2. TURN crown either way to correct time.
3. PUSH crown in to “A” position.
To adjust to a new time zone:
1. PULL crown out to “B” position.
2. TURN crown either way to move the hour hand in hour increments.
CALENDAR
To set the calendar:
1. PULL crown out to “B” position.
2. TURN crown either way to move hour hand. Two complete revolutions relative to the
12 o’clock position will move the date forward or backward. This will correct both date and
24-hour time.
3. PUSH crown in to “A” position.
NOTE: The date changes automatically every 24 hours.
D A B C
➧
PUSHER “A”
DATE
CHRONOGRAPH
1/20 SECOND
CROWN
POSITION
PUSHER “B”
SECOND
CHRONOGRAPH
SECOND
CHRONOGRAPH
MINUTE
HOUR
MINUTE
2
W-91
www.timex.com
CHRONOGRAPH
The chronograph is capable of measuring:
• 1/20 seconds elapsed up to 1 second (2 o’clock eye).
• Seconds elapsed up to 1 minute (chronograph second hand).
• Minutes elapsed up to 30 minutes (10 o’clock eye).
NOTE: Chronograph will operate continuously for 4 hours, after which it will automatically
stop and reset.
NOTE: The hand does not move during chronograph function, the 1/20th seconds are
indicated when chronograph is stopped and not yet reset.
BEFORE USING THE CHRONOGRAPH, adjust all the chronograph hands to the “0” or 12-hour
positions.
To adjust chronograph hands:
1. PULL crown out to “B” position.
2. PRESS pusher “B” until the hand at the 10 o’clock eye resets to the “30” position.
3. PULL crown out to “C” position.
4. PRESS pusher “A” until the chronograph second hand resets to the “0” or “60” or 12-hour
position.
5. PRESS pusher “B” until the hand at the 2 o’clock eye resets to the “0” position.
6. PUSH in Crown to “A” position.
NOTE:
• Make sure the chronograph is stopped and reset before adjusting.
• PRESSING and HOLDING either pusher “A” or “B” for 2 seconds will cause the hands to move
continuously until the pusher is released.
Standard chronograph measurement:
1. PRESS pusher “A” .to start timing
2. PRESS pusher “A” .to stop timing
3. PRESS pusher “B” to reset.
Split Time Measurement:
1. PRESS pusher “A” .to start timing
2. PRESS pusher to split.“B”
3. PRESS pusher “B” to resume timing.
4. PRESS pusher “A” .to stop timing
5. PRESS pusher “B” to reset.
INDIGLO® NIGHT-LIGHT
With the crown in the “A” .position, position. PUSH crown to the “D” Entire dial will be illuminated
Patented (U.S. pat 4,527,096 and 4,775,964) electroluminescent technology used in INDIGLO®
night-light illuminates entire watch face at night and in low light conditions.
NIGHT-MODE® FEAT URE
To use NIGHT-MODE® Feature:
1. PUSH and HOLD Crown to “D” position for 4 seconds to activate NIGHT-MODE® feature
(U.S. pat. 4,912,688). PRESSING any pusher will cause the INDIGLO® night-light to stay on for
3 seconds.
2. NIGHT-MODE® f .eature will last for 8 hours
3. Or PUSH and HOLD Crown to “D” position for 4 seconds to deactivate NIGHT-MODE® f .eature
If your watch is water-resistant, meter marking or ( ) is indicated.
Water-Resistance Depth p.s.i.a.* Water Pressure Below Surface
30m/98ft 60
50m/164ft 86
100m/328ft 160
WATER RES IST ANCE
WARNING: TO MAINTAIN WATER-RESISTANCE, DO NOT PRESS ANY BUTTONS UNDER WATER.
1. Watch is water-resistant only as long as lens, push buttons and case remain intact.
2. W .atch is not a diver watch and should not be used for diving
3. Rinse watch with fresh water after exposure to salt water.
*pounds per square inch absolute
3
W-91
www.timex.com
BATT ERY
Timex strongly recommends that a retailer or jeweler replace battery. If applicable,
push reset button when replacing battery. Battery type is indicated on caseback. Battery life
estimates are based on certain assumptions regarding usage; battery life may vary depending
on actual usage.
DO NOT DISPOSE OF BATTERY IN FIRE. DO NOT RECHARGE. KEEP LOOSE BATTERIES
AWAY FROM CHILDREN.
BRACELET LINK REMOVAL
Removing Links: Place bracelet upright and insert pointed tool in
opening of link. Push pin forcefully in direction of arrow until link is
detached (pins are designed to be difficult to remove). Repeat until
desired number of links are removed.
Reassembly: Rejoin bracelet parts. Push pin back into link in opposite direction of arrow. Press
pin down securely into bracelet until it is flush.
SOLID LINK BRACELET
Removing Links: Using a very small screwdriver, remove screws by
turning counterclockwise. Repeat until desired number of links are
removed. Do not remove links adjacent to clasp.
Reassembly: Rejoin bracelet parts and insert screw in end of open-
ing where it was removed. Turn screw clockwise until tight and flush
with bracelet.
BRACELET ADJUST MENT
TIMEX INTERNATIONAL WARRANTY
(U.S. – LIMITED WARRANTY – PLEASE SEE FRONT OF INSTRUCTION BOOKLET
FOR TERMS OF EXTENDED WARRANTY OFFER)
Your TIMEX® watch is warranted against manufacturing defects by Timex Corporation for a period of ONE YEAR from
the original purchase date. Timex and its worldwide affiliates will honor this International Warranty.
Please note that Timex may, at its option, repair your watch by installing new or thoroughly reconditioned and
inspected components or replace it with an identical or similar model. IMPORTANT — PLEASE NOTE THAT THIS
WARRANTY DOES NOT COVER DEFECTS OR DAMAGES TO YOUR WATCH:
1) after the warranty period expires;
2) if the watch was not originally purchased from an authorized Timex retailer;
3) from repair services not performed by Timex;
4) from accidents, tampering or abuse; and
5) lens or crystal, strap or band, watch case, attachments or battery. Timex may charge you for replacing any of
these parts.
THIS WARRANTY AND THE REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PUR-
POSE. TIMEX IS NOT LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some countries and
states do not allow limitations on implied warranties and do not allow exclusions or limitations on damages, so these
limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights
which vary from country to country and state to state.
To obtain warranty service, please return your watch to Timex, one of its affiliates or the Timex retailer where the
watch was purchased, together with a completed original Watch Repair Coupon or, in the U.S. and Canada only, the
completed original Watch Repair Coupon or a written statement identifying your name, ,address telephone number
and date and place of purchase. Please include the following with your watch to cover postage and handling (this is
not a repair charge): a US$ 7.00 check or money order in the U.S.; a CAN$6.00 cheque or money order in Canada;
and a UK£2.50 cheque or money order in the U.K. In other countries, Timex will charge you for postage and handling.
NEVER INCLUDE A SPECIAL WATCHBAND OR ANY OTHER ARTICLE OF PERSONAL VALUE IN YOUR SHIPMENT.
For the U.S., please call 1-800-448-4639 for additional warranty information. F For Canada, call 1-800-263-0981. or
Brazil, call +55 (11) 5572 9733. For Mexico, Fcall 01-800-01-060-00. or Central America, the Caribbean, Bermuda and
the Bahamas, call (501) 370-5775 (U.S.). For Asia, call 852-2815-0091. For the U.K., call 44 020 8687 9620. For Portugal,
call 351 212 946 017. For France, Fcall 33 3 81 63 42 00. or Germany, Fcall 49 7 231 494140. or the Middle East and
Africa, call 971-4-310850. For other areas, please contact your local Timex retailer or Timex distributor for warranty
information. In Canada, the U.S. and in certain other locations, participating Timex retailers can provide you with a
postage-paid, pre-addressed Watch Repair Mailer for your convenience in obtaining factory service.
©2006 Timex Corporation. TIMEX and NIGHT-MODE are registered trademarks of Timex C -orporation. INDIGLO is a reg
istered trademark of Indiglo Corporation in the US. and other countries.
