Side 1/36
EN
Quick guide
* Available only on certain models
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
FIRST TIME USE
After installation, wait at least two hours before connecting the
appliance to the power supply. Once connected, it will start working
automatically. The ideal temperature settings are preset from the
factory.
After turning the appliance on, wait 4-6 hours for it to reach the correct
food storage temperature.
CONTROL PANEL
1. On/o
2. Fridge temperature indicator
3. Fridge temperature setting
4. Fast freeze indicator light
5. Fast freeze button (rapid freezing)
ON/OFF
The whole product (both fridge and freezer compartments) can be
turned on by pressing this button for 2 seconds. The last set value is
indicated on the interface. Press this button to turn o the device.
FRIDGE TEMPERATURE INDICATOR LIGHT
It shows the temperature of the fridge compartment.
FRIDGE TEMPERATURE SETTING
It allows you to change the fridge temperature value, in a cyclical way;
it also conrms the selected temperature on the interface.
Recommended setting for the refrigerator compartment is +4°C.
FAST FREEZE INDICATOR LIGHT
lluminates when the Fast freeze button is pressed.
FAST FREEZE FUNCTION
This function is recommended for freezing fresh food. Fresh food
should be frozen as quickly as possible, for the best possible
preservation and for keeping its nutritional value. Press the Fast freeze
button when you need to freeze fresh food; the Fast freeze indicator
will come on.
We recommend you press the Fast freeze button 24 hours before
putting the food in, in order to prepare the freezer compartment for
the best possible freezing conditions. We recommend you use the
bottom drawer to maximize the freezing capacity.
The Fast freeze function is automatically deactivated after 48 hours, or
you can disable it manually by pressing the Fast freeze button.
LED LIGHT
This product contains a light source of energy eciency class F.
If the LED light system does not work, please contact the Service to
replace it.
Important: The refrigerator compartment light switches on when
the refrigerator door is opened. If the door is kept open for more than
8 minutes the light will be automatically switched o.
6th SENSE
This function automatically works to ensure the optimal conditions
to preserve the stored food. The “6th Sense” function is automatically
activated when:
• a large amount of food is loaded into the refrigerator
• the refrigerator door is left open for a long time
• a prolonged power failure takes place, causing the internal
temperature of the appliance to increase to values that cannot
guarantee safe storage of food.
HOW TO STORE FRESH FOOD AND BEVERAGES
*
a) b)
* The number and type of door balconies depends on the model
Legend
TEMPERATE ZONE
Suggested for storage of tropical fruit, cans, drinks,
eggs, sauces, pickles, butter, jam
COOL ZONE
Suggested for the storage of cheese, milk, daily
food, delicatessen, yogurt
COOLEST AREA
a) Suggested for storage of cold cuts, desserts, meat
and sh
b) Suggested for storage of meat and sh.
The drawer available only on certain model
FRUIT & VEGETABLE DRAWER
FREEZER DRAWERS
(One drawer in models lower than 1,7m)
FREEZING ZONE DRAWER
(Max cool zone)
Suggested to freeze fresh / cooked food
REFRIGERATION COMPARTMENT
Refrigerator compartment defrosting is completely automatic.
Droplets of water on the rear wall inside the refrigerator compartment
indicate that the automatic defrost phase is in progress.
The defrost water is automatically run into a drain hole and collected in
a container, where it evaporates.
Fresh Box 0°C drawer *
The Fresh Box 0°C it is a drawer (b) ideal to store meat and sh. By
decreasing/increasing the fridge temperature, you impact the Fresh
Box 0°C compartment temperature as well. Keep in mind that this
compartment is a mechanical feature operating all the time and it
cannot be switched o.
Humidity Control*
Turn on the humidity regulator (position B) if you want to store food
in a less humid environment, like fruit, or turn it o (position A) if you
want to store food in a more humid environment, like vegetables.
A
B
Foldable shelf*
This shelf can be used in three dierent ways:
1. Full-depth, to use the entire surface.
2. Half-depth, to use the rear part and at the same time create space
for taller items (like bottles and jugs) on the shelf below. To adjust
the shelf to half-depth, slightly raise the front part then pull it in.
3. Flipped up if you need to make space for tall or bulky items on
the shelf below. To ip the shelf up, rst adjust it to the halfway
position from half-depth. Flip the shelf down to go back to using it
in half-depth and full-depth.
* Available only on certain models
FREEZER COMPARTMENT
Total No Frost freezers provide chilled air circulation around the
storage areas, and prevent the formation of ice, thereby completely
eliminating the need for defrosting.
Frozen items don’t stick to the walls, labeling stays legible and storage
space remains neat and clear.
The freezer compartment allows for the storage of frozen food and the
freezing of fresh food.
The quantity of fresh food that can be frozen in a specic time period
is indicated on the rating plate. Arrange the fresh food in the freezing
area inside the freezer compartment, leaving enough space around it
to allow air to circulate freely. Avoid allowing fresh food to come into
direct contact with frozen food. Load limits are determined by baskets,
aps, drawers, shelves etc..
Make sure that these components can still close easily after loading.
The freezing zone's drawer/compartment is shown in the picture
above. To optimize freezing speed and get more storage space, the
freezer compartment can be used without the freezer drawers and
the food can be placed directly on the bottom of the compartment.
To avoid food waste, please refer to the recommended setting and
storage found in the online user manual.
Ice cubes
Fill 2/3 of the ice tray with water and place it back in the freezer
compartment. Do not use sharp or pointed objects to remove the ice.
ACCESSORIES*
EGG TRAY ICE TRAY BOTTLE RACK FOLDABLE SHELF
GENERAL INFORMATION
The drawers, baskets, and shelves should be kept in their current
position unless otherwise specied in this quick guide.
The light system inside the refrigerator compartment uses LED lights,
which provide better lighting and use less energy than traditional
bulbs.
Doors and lids of the refrigerator should be removed before disposal,
to avoid children or animals getting trapped inside.
TROUBLESHOOTING
What to do if... Possible reasons Solutions
The appliance is not
working.
There may be an appliance power supply
problem.
• Check if power cable plugged into a live socket with the proper
voltage.
• Check if the protection devices and fuses of the electrical system in
your home
There is water in the defrost
pan.
This is normal in hot, damp weather. The
pan can even be half full.
• Make sure the appliance is level so that the water does not
overow.
The edges of the appliance
cabinet, which come in
contact with the door seal,
are warm to the touch.
This is not a defect. This is normal in hot
weather and when the compressor is
running.
The light does not work. The light may need replacing.
The appliance may be in On/ Stand-by
model.
• Make sure if the protection devices and fuses of the electrical
system in your home work well.
• Check if the power cable is plugged into a live socket with the
proper voltage
• In case the LEDs are broken the user must call the Service for
exchange of the same type available only at our Aftersales Service
Centers or authorized dealers.
The motor seems to run too
much.
Motor running time depends on dierent
things: number of door openings,
amount of food stored, temperature of
the room, setting of the temperature
controls.
• Make sure that the appliance controls are correctly set.
• Check if there is not a large amount of food been added to the
appliance.
• Check that the door is not opened too often.
• Check that the door close properly.
The appliance temperature
is too high.
There could be various causes (see
“Solutions”).
• Make sure that the condenser (back the appliance) is free of dust
and u.
• Make sure that the door properly closed.
• Make sure that the door seals properly tted.
• On hot days or if the room is warm, the motor naturally runs longer.
• If the appliance door has been left open for a while or if large
amounts of food have been stored, the motor will run longer in
order to cool down the interior of the appliance.
The doors do not open and
close properly.
There could be various causes (see
“Solutions”).
• Check that food packages are not blocking the door.
• Check that the internal parts or automatic ice maker are not out of
position.
• Check that the door seals are not dirty or sticky.
• Ensure the appliance is level.
