W A L L ZEPHYRONLINE.COM
TM
C
INTERNAL BLOWER
STANDARD
INTERNAL BLOWER with ACT™
AIRFLOW CONTROL TECHNOLOGY™*
Min. - Max. CFM
Min. - Max. Sones
350 - 1,200
2 - 9 *AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
is an exclusive feature built into specific Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
350 - 590 350 - 390
48” model
P R O
S I E N A P R O
FRONT
SIDE
TOP
16- ”11/16
35-15/16”, 41- ”15/16”, 47-15/16
16”
45°
12- ”3/16
12”
24”
2”
9/16”
STANDARD
min. ducted - 29”
max. - 42”
Z1C-00SP
min. ducted - 47”
max. - 77”
6- ”3/4
9-7/8”
1”
6-9/16”
Specifications subject to change, check zephyronline.com for up-to-date information.
Zephyr Ventilation | 2277 Harbor Bay Parkway, Alameda, CA 94502 | 888.880.VENT
MODEL
ZSP-E36DS
36”
350 - 1,200
2 - 9
350 - 590
350 - 390
590, 390
ICON Touch® LCD
5*
Yes
LumiLight LED with
TruHue™, 6W x2
Yes
Yes
Hybrid Baes x2
No
Yes, Up to 12’ Ceiling
Yes, w/ remote accessory
10” Round
NA
120V, 60Hz at Max. 9A
RC-0002
Z1C-00SP
AK1716
MUA010A
24” - 34”
3 years parts, 1 year labor
ZSP-E42DS
42”
350 - 1,200
2 - 9
350 - 590
350 - 390
590, 390
ICON Touch® LCD
5*
Yes
LumiLight LED with
TruHue™, 6W x2
Yes
Yes
Hybrid Baes x2
No
Yes, Up to 12’ Ceiling
Yes, w/ remote accessory
10” Round
NA
120V, 60Hz at Max. 9A
RC-0002
Z1C-00SP
AK1712
MUA010A
24” - 34”
3 years parts, 1 year labor
ZSP-E48DS
48”
350 - 1,200
2 - 9
350 - 590
350 - 390
590, 390
ICON Touch® LCD
5*
Yes
LumiLight LED with
TruHue™, 6W x2
Yes
Yes
Hybrid Baes x3
No
Yes, Up to 12’ Ceiling
Yes, w/ remote accessory
10” Round
NA
120V, 60Hz at Max. 9A
RC-0002
Z1C-00SP
AK1718
MUA010A
24” - 34”
3 years parts, 1 year labor
WA L L
Stainless Steel
Size
BLOWER PERFORMANCE
Blower CFM (Min. - Max.)
Sones (Min. - Max.)
ACT 590 CFM (Min. - Max.)
ACT 390 CFM (Min. - Max.)
FEATURES
ACT™ Technology
Controls
Speed Levels
Auto Delay-O
Lighting
Dual-Level Lighting
TruHue™
Filters
Recirculating Option
Extension Duct Cover Option
ADA Compliant
DUCT SPECIFICATIONS
Vertical Internal Blower
Horizontal Internal Blower
AC POWER
OPTIONAL ACCESSORIES
Wireless Remote Control Kit
Extension Duct Cover
Stainless Steel Telescopic Backsplash
Make-Up Air Kit
MOUNTING HEIGHT RANGE**
WARRANTY
*When ACT™ is enabled the maximum speed levels will change. ACT 590 CFM = 3 speeds and ACT 390 CFM = 2 speeds.
**Mounting height refers to distance between top of a 36” tall cooking surface and bottom of hood.
CEILING HEIGHT
EXTENSION
DUCT COVER
STANDARD
DUCT COVER Ducted Mounting Height*
Ducted Mounting Height*
8.5’8’
24” - 32.5”
NA
24” - 34”
NA
30” - 34”
24” - 27”
NA
24” - 33”
NA
24” - 34”
NA
24” - 34”
NA
24” - 34”
NA
30” - 34”
9’ 9.5’ 10’ 11’ 12’10.5’
P R O
S I E N A P R O
JUN24.0101
Airflow Control Technology™ (ACT™)
TM
C
is an exclusive feature built into specific Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
TruHue™
A bright idea: customize your hood’s light to harmonize with the
rest of your kitchen’s lighting at the touch of a button—from 2700K,
3000K, 3500K, 4000K to 5000K.
