Service and Troubleshooting
Package Terminal Air Conditioner / Heat Pump
Standard and Remote Applications with LED Controlboard
R32 and R-410A
© 2019-2023 Daikin Comfort Technologies Manufacturing, L.P.
This manual is to be used by qualied, professionally
trained HVAC technicians only. Goodman does not assume
any responsibility for property damage or personal injury
due to improper service procedures or services performed
by an unqualied person.
RS4200007r1
March 2023
TABLE OF CONTENTS
IMPORTANT INFORMATION ..........................................2
PRODUCT IDENTIFICATION ..........................................3
SYSTEM OPERATION ...................................................12
SCHEDULED MAINTENANCE ......................................30
SERVICING .....................................................................33
CHECKING VOLTAGE ................................................43
CHECKING THERMOSTAT AND WIRING ................ 43
HEATER ASSEMBLY ..................................................44
DRAIN PAN VALVE
(HEAT PUMP MODELS ONLY) ..................................45
CAPACITOR CHECK ..................................................45
CHECKING FAN AND MOTOR
BLOWER WINDINGS..................................................46
COMPRESSOR WINDINGS .......................................47
OVERLOAD .................................................................48
CHECKING COMPRESSOR EFFICIENCY ..............48
FILTER DRIER REPLACEMENT ...............................48
REVERSING VALVE ...................................................49
ACCESSORIES ..............................................................55
WIRING DIAGRAMS ......................................................68
Pride and workmanship go into every product to provide
our customers with quality products. It is possible, however,
that during its lifetime a product may require service.
Products should be serviced only by a qualied service
technician who is familiar with the safety procedures
required in the repair and who is equipped with the proper
tools, parts, testing instruments and the appropriate service
manual. REVIEW ALL SERVICE INFORMATION IN THE
APPROPRIATE SERVICE MANUAL BEFORE
BEGINNING REPAIRS.
® is a registered trademark of Maytag Corporation or its related companies and is used under license to
Goodman Company, L.P. Houston TX, USA. All rights reserved.
WARNING
DO NOT BYPASS SAFETY DEVICES.
ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL,
ADJUST, SERVICE, MAINTENANCE OR REPAIR
(HEREINAFTER, “SERVICE”) THE EQUIPMENT SPECIFIED IN
THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
THIS EQUIPMENT IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR
THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE EQUIPMENT.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR
ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SUPERVISION, SERVICE OR SERVICE
PROCEDURES. IF YOU SERVICE THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY INJURY OR PROPERTY
DAMAGE WHICH MAY RESULT. IN ADDITION, IN
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES
TO SERVICE THE EQUIPMENT SPECIFIED IN THIS
MANUAL, ONLY LICENSED PERSONNEL SHOULD SERVICE
THE EQUIPMENT. IMPROPER SUPERVISION, INSTALLATION,
ADJUSTMENT, SERVICING, MAINTENANCE OR REPAIR OF
THE EQUIPMENT SPECIFIED IN THIS MANUAL, OR
ATTEMPTING TO INSTALL, ADJUST, SERVICE OR REPAIR
THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT
PROPER SUPERVISION OR TRAINING MAY RESULT IN
PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
WARNING
IMPORTANT INFORMATION
2
OUTSIDE THE U.S., .
(Not a technical assistance line for dealers.) Your telephone company will bill you for the call.
While these items will not cover every conceivable
situation, they should serve as a useful guide.
Pride and workmanship go into every product to provide
our customers with quality products. It is possible, however,
that during its lifetime a product may require service.
Products should be serviced only by a qualied service
technician who is familiar with the safety procedures
required in the repair and who is equipped with the proper
tools, parts, testing instruments and the appropriate service
manual. REVIEW ALL SERVICE INFORMATION IN THE
APPROPRIATE SERVICE MANUAL BEFORE
BEGINNING REPAIRS.
This device, which was assembled by Daikin Comfort Technologies
Manufacturing, L.P., contains a component that is classied as an
intentional radiator. This intentional radiator has been certied by the
FCC: FCC ID TF7M90-1000. And this international radiator has an
Industry Canada ID: IC 27830-M901C1000.
The manufacturer of the intentional radiator (model no. M90H or
M90S) or FCC ID:TF-TF7M90-1000 is Everex Communications Inc,
which can be contacted by (510)-687-0075 (www.everexcomm.net).
This device complies with Part 15 of the FCC’s Rules. Operation of
this device is subject to two conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including
interference that may cause undesirable operation.
And this device meets the applicable Industry Canada technical
specication.
The FCC responsible party is Daikin Comfort Technologies
Manufacturing, L.P. , and may be contacted by calling 713-861-2500,
or at 19001 Kermier Rd., Waller TX 77484. (www.DaikinComfort.com)
This equipment complies with FCC radiation exposure limits. To ensure
compliance, human proximity to the antenna shall not be less than
20 cm during normal operations.
NOTE: Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for
help.
PRODUCT IDENTIFICATION
3
NOMENCLATURE
Model/Revision Description
PT*********** AA Redesign unit with 2 fan motors and R410A refrigerant
PT*********** AC 2 Speed Condenser Fan Motor
PT*********** BA M70 Control Board
PT*********** EA
Release of units with low displacement compressor 7
and 12 K HP PTAC models. Only for standard models and high efficiency models
PT*********** GA Transition from Fayetteville to Houston built product
Package Terminal Air Conditioner
PTC 07
3 K
35
A X X X A A
BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.
PTC = Standard Cooler PTAC
PTH = Standard Heat Pump PTHP
DRY = Dehumid Cooler PTAC
PMC = Cooler w/ Makeup Air Kit
PMH = Heat Pump w/ Makeup Air Kit
HEH = High Efficiency Heat Pump
HEC = High Efficiency Cooler
(OD DC Only)
COOLING CAPACITY
07 = 7000 BTUH (60 Hz)
09 = 9000 BTUH (60 Hz)
12 = 12000 BTUH
(50 or 60 Hz)
15 = 15000 BTUH (60 Hz)
17 = 16500 BTUH (60 Hz)
RATED VOLTAGE
3 = 230/208V 60Hz 1Ph FEATURE CODE Examples POTENTITIAL FEATURE CODE
4 = 265V 60Hz 1Ph
A = Standard Model PTC073K35AXXX B = Condenser affles Factory InstalledB
C = Corrosion Protection (Seacoast) PTC073K35CDXX S1 = Sleeve & Architectural Grill
D = Power Door PTC073K35CQVX S2 = Sleeve & Stamped AL Grill
DESIGN SERIES
E = Makeup Air lectric HeaterEPTC073K35CDQR
J = R-32
L = Lighting Control
K = R-410A Redesign 2023
P = Condensate Pump
HEATER SIZE Q = Quiet STC Kit
00 = no electric heat
15 = 1.5 kW
T = Transfere Fan
25 = 2.5 kW
V = Power Vent
35 = 3.5 kw (230/208V) Use up to 4 as needed
= 3.7kW (265V)
In Alphabetical order
50 = 5.0 kW
