User Instructions

STAGE SETTER-8

4/16

specications, diagrams, images, and instructions herein are

subject to change without notice. ADJ Products, LLC logo and

identifying product names and numbers herein are trademarks

of ADJ Products, LLC. Copyright protection claimed includes all

forms and matters of copyrightable materials and information

now allowed by statutory or judicial law or hereinafter granted.

Product names used in this document may be trademarks or

registered trademarks of their respective companies and are

hereby acknowledged. All non-ADJ Products, LLC brands and

product names are trademarks or registered trademarks of their

respective companies.

ADJ Products, LLC and all aliated companies hereby dis-

claim any and all liabilities for property, equipment, building, and

electrical damages, injuries to any persons, and direct or indi-

rect economic loss associated with the use or reliance of any

information contained within this document, and/or as a result

of the improper, unsafe, unsucient and negligent assembly,

installation, rigging, and operation of this product.

Europe Energy Saving Notice

Energy Saving Matters (EuP 2009/125/EC)

Saving electric energy is a key to help protecting the enviroment.

Please turn o all electrical products when they are not in use. To

avoid power consumption in idle mode, disconnect all electrical

equipment from power when not in use. Thank you!

Introduction.... ........ ........ .... ..... ..... ..... ... ....... ... ....... ........ . ... ...... ..... . . . . . .... 2

Fe e ... ... ... ... ... ... ... ... ... ...atur s......... .......... .. ... ..... .. ... ..... .. ... ..... .. ... ..... .. ... ..... .. 4

Ov ieerv w............ ....... .... ...... ..... .. ...... ... ... ... ... ... ... ... ... .5.. ..... .. ... ..... .. ... ..... .. ...

Set Up. .. ... .. .. ..... ....- .. ... ... ... .. . ..... .... .... .... .. .. .. .. .. .. .. .. .. ... . . . . . .. . . . . .. . ... .. .. .. ... . .. . .6

Frt Panel Controls and Functions............................................................8

Rear Panel Controls and Functions.......................................................13

General Operation:

Operating Modes..................................................................................15

Master Scenes.......................................................................................15

Flash Scenes.........................................................................................16

Programming Chase Patterns:

2x8 and 8x8 Modes...............................................................................17

1x16 Mode............................................................................................18

MIDI Operation....................................................................................19

LCD Value Change...............................................................................20

Memory Dump.....................................................................................20

Wa y. . .rrant .... ... ......... .... ..... ..... ... ..... .... ..... .....................................................21

and unit may be made at any time without prior notice.

ADJ Products, LLC - www.adj.com - Stage Setter 8™ Instruction Manual Page 3

ge 8™ sSta Setter Content

Introduction:

Thank you for purchasing the ADJ Stage Setter 8.

™ To optimize the

performance of this product, please read these operating instructions

carefully to familiarize yourself with the basic operations of this unit.

The ADJ Stage Setter 8™ is a unique 16 channel DMX controller. This

unit has been tested at the factory before being shipped to you, there

is no assembly required.

Customer Support:

ADJ Products, LLC provides a toll free customer support line, to pro-

vide set up help and to answer any question should you encounter

problems during your set up or initial operation. You may also visit us

on the web at www.adj.com for any comments or suggestions.

Standard Time.

Voice: (323) 2-58 2650

Fax: (323) 582-2941

E-mail: support@AmericanDJ.com

Warning!

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

your nearest ADJ dealer.

Do not discard this cartoon in the trash. Please recycle when

ever possible.

Upon unpacking, carefully inspect your unit for any damage

that may have occurred during shipping. If damage may have

occurred, do not plug the unit in, please contact your dealer as

soon as possible.

ADJ Products, LLC www.adj.com Stage Setter 8™ Instruction Manual Page 2

Stage Setter 8™ I ro onnt ducti

Stage Setter 8™ Introduction

FEATURES:

Stage Setter 8™ features include:

• 3-pin XLR IN, OUT, and THRU DMX jacks

• Three different operating modes: 2 x 8, 8 x 8, and 1 x 16

• 12 pattern option: 4 built in and 8 user programmable

• 32 steps (scenes) per a program

• MIDI compatible

• Fog machine output button

• Scene crossfader

• Tap SYNC button

• 8 Bump Buttons

• Back up memory protection

• Full functional, 4 digit LCD display

ADJ Products, LLC - www.adj.com - Stage Setter 8™ Instruction Manual Page 4

Stage Setter 8™ Introduction

WARNINGS:

• Do not spill water or other liquids in to or on to your unit.

• Be sure that the local power outlet match that of the

required voltage for your unit.

• Do not attempt to operate this unit if the power cord has

been frayed or broken. Please route your power cord out of

the way of foot trac.

• Do not attempt to remove or break o the ground prong

from the electrical cord. This prong is used to reduce the

risk of electrical shock and re in case of an internal short.

• Disconnect from main power before making any type of

connection.

• Do not remove the top cover under any conditions. There

are no user serviceable parts inside.

• Disconnect the unit’s main power when left unused for long

periods of time.

• Never plug this unit in to a dimmer pack

• Always be sure to mount this unit in an area that will allow

proper ventilation. Allow about 6” (15cm) between this

device and a wall.

• Do not attempt to operate this unit, if it becomes damaged

in any way.

• Never operate this unit when it’s cover is removed.

• To reduce the risk of electrical shock or re, do not expose

this unit rain or moisture

• This unit is intended for indoor use only, use of this product

outdoors voids all warranties.

• During long periods of non-use, disconnect the unit’s main

power.

• Always mount this unit in safe and stable matter.

ADJ Products, LLC - www.adj.com - Stage Setter 8™ Instruction Manual Page 5
