Side 1/6
Model: AV-POE4
4-port PoE Switch
User Guide
V1.0
Please read this user guide
thoroughly before using.
www.avipas.com
Preface
Thank you for choosing AViPAS PoE Switch AV-POE4.
This guide introduces the functions, installation process and operation of -POE4. Prior to AV
installation and usage, please read the guide thoroughly.
Precautions
▪ To reduce the risk of re, electric shock, or damage to the product, when installing, operating,
and maintaining the equipment, follow the safety precautions described in the guide. “Warnings” and
“notes” in this guide do not represent all safety precautions that should be followed.
▪ When using this equipment, the user must read through all the relevant precautions and special
safety instructions provided in this guide and on www.avipas.com. The "safety warnings" listed in the guide
only reect some the requirements AViPAS will not bear any responsibilities for the loss caused by of .
violation of general safety operation requirements.
Installation environment requirements
▪ This device needs to be installed o desktop, wall-mounted, n or to be or 19’’rack-mounted.
▪ Temperature and humidity of the installation site must be kept within the working range.
Please refer to the data sheet for the normal working temperature range and relative humidity range of PoE
devic . es
▪ Grounding is essential for the installation process. Correct wiring of the grounding cable
protects the PoE device from lightning, high-voltage surge, interference, and static electricity.
Lightning protection requirements
▪ Do not use outdoor overhead (open) wiring. The equipment may be damaged by lightning.
Please use buried or steel pipe wiring.
▪ The fiber media converter must be grounded before being powered on to ensure that the
grounding resistance of the installation environment does not exceed 10Ω, otherwise the equipment may be
damaged.
Product Specications
▪ DC Input: DC 52V 1.25A
▪ Port M : 30W, Total: 65W ax
▪ PoE Output: IEEE 802.3af/at
▪ 4x PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports (unmanaged)
▪ 1x Gigabit Non-PoE Port for high-speed connections
Product installation
Installation instructions
▪ Please select a suitable installation location or cabinet according to th safety recommendation. e
▪ When installing the PoE device, the user needs to choose matching mounting accessories.
▪ Please wear protective gloves when installing.
▪ Do NOT install the PoE device with power on. its
Installation tools
▪ Labor protection gloves
▪ Plum screwdriver
▪ Flat screwdriver
Installation steps
▪ Desktop installation
Step 1: Place the PoE device an even desktop. Make sure that at least 10cm of space is reserved on on
both sides of the PoE device (the vents), shown in Picture 1, so that the PoE device can be well ventilated.
