Side 1/12
Prime
Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. 3.5”/2.5” HDD/SSD Installation
5. Cooling System Installation
6. ARGB Control Modes Switching
7. Fan Installation
Specifications
Model
Model Name: Prime
Model Number: CSAZ-360
Specifications
Type: ATX Mid Tower
Color: Black/Black(interior)
Side Panel Window:
Left side panel: Tempered glass with rubber mounts
Max CPU Cooler Height: UP to 170mm
Max Video Card Length: Up to 310mm long video card
Power Supply: Not included
Motherboard Compatibility:
ATX、
Micro ATX
、ITX
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays: Up to 3
Internal 3.5" Drive Bays: Up to 2
Expansion Slots: 7
Top Ports: Power button, LED bu�on, HD Audio, USB 3.0 x 2
Physical Dimension (HxWxD) 458x200x375mm/18x7.9x14.8 inches
Weight: 4.8Kg /10.6lbs
Tempered Glass Sides Window: High-quality tempered glass side window allows for clear visuals to inner components
Addressable RGB Light Effects: ARGB fans are controlled using the LED button. All addressable RGB devices can sync with the motherboard,
allowing the motherboard software to control lighting directly.
Available Fan Ports:
3x120mm or 2x140mm fan ports in the front (3x120mm LFO-4012D addressable ARGB fan included)
2x120mm fan ports on the top
1x120mm fan port in the rear
2x120mm fan ports on the top of Power Supply Shroud
Water Cooling: Supports radiators up to 240mm in the front
Dust Filters: Removable (magnetic) dustproof net on the top , removable dust filter on bottom of ch assis.
Power Supply Support: Bottom mounted ATX power supply
Expansion
Physical Specifications
Features
