Side 1/68
REV. 00. MAR 2023
DOC. NO. 71120203
WELCOME TO THE DOMINAR CLAN!
You are now the proud owner of a modern masterpiece,
Dominar 400 BS VI. The new Dominar 400 BS VI is designed
to deliver unparalleled technology with superior performance.
This makes your Dominar, unbeatable and unchallenged on
every terrain.
Before you ride out, please read this Owner's Manual carefully
and familiarise yourself with the operation mechanism,
controls and maintenance requirements of your
Dominar 400 BS VI. This will ensure you a safe and trouble
free ownership experience.
To keep your bike in perfect running condition and deliver
consistent performance, we have specially programmed the
periodic maintenance services which includes 3 free services
and subsequent paid services, as per the schedule contained
in this booklet. We earnestly advise you to avail all these
services at any of our Bajaj Dealers, who
are well equipped with all necessary facilities, genuine
parts, oils and trained manpower to ensure the best care
for your Dominar. Your comes with a 'Dominar 400 BS VI'
warranty of , whichever occurs 5 years or 75,000 KMs
earlier from the date of sale. For details please refer to
"Warranty: Scope & Limits" given in this manual.
Should you require any addition information, feel free to
contact us on helpline numbers given on backside of cover
page or e-mail us at:customerservice@bajajauto.co.in or
visit the Bajai Auto website www.bajajauto.com Also, do
like our Facebook page www.facebook.com/BajajDominar
and subscribe to our YouTube channel to stay tuned on any
new information on the brand.
DON'T HOLD BACK!!
SR.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18
DESCRIPTION PG. NO. DESCRIPTION PG. NO.
SAFETY AND WARNING INFORMATION:
Warning: This indicates that a potential hazard or injury to you or other
persons & to the vehicle can happen if advice provided is not followed.
Caution: This indicates that a potential hazard that could result in
vehicle damage. Follow the Advice provided with the caution.
The description and illustration in this booklet are not to be taken
as binding on the manufacturers. The essential features of the
type described and illustrated herein remaining unaltered. Bajaj
Auto Limited reserves the right to carry out at any moment
without being obliged to bring this booklet upto-date & to do
modifications on the vehicle, parts or accessories as may be
convenient and necessary.
1
3.
4
5
6
7
8
9
17
19
20
21
22
23
24
25
26
27
28
31
32
33
34
35
36
37
38
40
41
43
44
46
54
55
56
59
Technical Specification
Identification Data
Location of Parts
Steering - Ign. lock & Cranking ON OFF control
Fuel Tank Cap & Secondary Speedometer
Primary Speedometer Details
Twin Channel ABS System
Speedometer Functionality Details
Secondary Speedometer Setting
Mobile Charger
Carrier Unit Navigation
Control Switch RH
Automatic Headlamp & Lights Operation
Control Switch LH
Removal of Pillion & Rider Seat / Tool kit
Fitment of Rider & Pillion Seat
Grab Handle
Daily Safety Checks
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36
How to ride your Bike
Good Riding Habits
Safe Riding Tips & Monsoon Care
Engine Oil
Tubeless Tyre&Tyre Pressure
Battery
Engine Cooling System
Coolant
Periodic Maintenance Information
Brake Fluid / Headlamp Care
Saddle Guard
Usage of luggage straps with bungee cord
Free Service Guidelines
Periodic Maintenance & Lubrication Chart
Non Use Maintenance
Delivery Certificate
Warranty Scope & Limit
Battery Warranty Card
SR.
Engine 4 Stroke, Single Cylinder
Bore x Stroke 89 mm x 60 mm
Engine Displacement 373.27 cc
Compression Ratio 12.2 : 1
Idling Speed 1680 +/- 100 RPM
Max. Net Power 40 PS at 8800 RPM
Max. Net Torque 35 Nm at 6500 RPM
Ignition System DC
Fuel System Fuel Injection System
Spark Plug 1 Nos.
Spark Plug Gap 0.8 ~ 0.9 mm
Lubrication Wet sump forced Lubrication
Transmission 6 speed constant mesh
Gear shifting Pattern 1 Down 5 Up
Engine Cooling Liquid cooled
Starting Aid Self
Front & Rear Brake Disc
Parameter
Fuel Tank Capacity
Full 13 Liters (No Reserve)
Dimensions
Length 2156 mm
Width 863 mm
Height 1243 mm
Wheel base 1453 mm
Ground Clearance 157 mm
Tyre Size Front 110/70-R17, Tubeless
Tyre Size Rear 150/60-R17, Tubeless
Tyre Pressure
Front 2.04 Kgf/cm (29 PSI)
2
Rear (Solo) 2.25 Kgf/ (32 PSI)
2
cm
Rear (with pillion) 2.25 Kgf/cm (32 PSI)
2
Electrical System 12 Volts DC
Battery 12V 8Ah VRLA
Head Lamp LED
Dominar 400 BS VI Parameter Dominar 400 BS VI
Parameter
Position Lamp LED
Tail / Stop Lamp LED
Side Indicator LED
Neutral Indicator LED Green
Hi-Beam Indicator LED Blue
Turn Signal Indicator LED Green
Speedometer Illumination LCD
Fuel Level Indicator LCD Bar
Malfunction Indicator LED Yellow
Low oil pressure Indicator Alarm message
Coolant Temp. Indicator Alarm message
Low Battery Indicator Alarm message
REV Indicator LED Amber
Service Reminder Alarm message
Side Stand Indicator Alarm message
ABS Indicator LED Yellow
Generic Alarm LED Amber
Rear No. Plate Lamp LED
Parameter
Horn 12V DC
Vehicle Kerb Weight 192 kg.
Vehicle Gross Weight 342 kg.
NOTES
• All dimensions are under UNLADEN condition.
• Above information is subject to change without any notice.
• This vehicle complies to BS VI standards.
• AHO is government regulation.
Dominar 400 BS VI Dominar 400 BS VI
IDENTIFICATION DATA
The Frame and Engine serial numbers are used to
register the motorcycle.
They are the unique alpha-numeric codes to
identify your particular vehicle from others of the
same model and type.
FRAME NUMBER
LOCATION
On Seat Mounting Bracket
(Alpha-Numeric - 17 Digits)
ENGINE NUMBER
LOCATION
On LH Side Crankcase Near Gear
Change Lever (Alpha-Numeric - 11 Digits)
Reflex Reflector
Belly Pan
Backrest
Windshield
LED
STEERING CUM
IGNITION LOCK
It has three positions.
To lock the steering, turn the handle bar to the
left side. Turn the handle bar to the left or right.
Push & Rotate the key to “LOCK” position &
remove the key. Steering locking on handle
position left hand side only.
TO LOCK THE STEERING
Insert the key in steering cum ignition lock. Push
& Rotate it clockwise to “OFF” or “ON” position.
TO UNLOCK THE STEERING
LOCK: Steering locked. Ignition OFF.
OFF: Steering unlock. Ignition OFF.
ON: Steering unlock. Ignition ON.
A common key is used for ‘Steering cum Ignition lock’,
‘Fuel tank cap’ & ‘Rear Seat’
KEY
“Cranking ON and OFF duration” control –
• During Engine crank cycle cranking is allowed only for
fixed duration and in between successive cranks (in
case engine does not start) here is a cooling off
period.
• Cranking on-off duration control feature to avoid
battery discharge-
- 1st Crank ON (5 sec) & Disable for 2 sec.
- 2nd Crank ON (5 sec) & Disable for 2 sec.
- 3rd Crank ON (5 sec) & Disable for 10 sec.
After a gap of 10 sec cranking cycle continues.
• – With side Starter disabled if side stand down
stand down condition and vehicle in gear, Engine
cranking is disabled through ECU.
• Headlight control on rpm – Headlamp will be turned
ON only at Engine running condition.
FUEL TANK CAP & SECONDARY SPEEDOMETER
Speedometer display will work when lonicion switch is in 'ON' position
FUEL TANK CAP
• To open the fuel tank cap, open the flap. Insert the key in
the lock and turn it clockwise and lift fuel tank cap.
• To lock the 'Fuel Tank Cap' insert the key in the lock and turn
it clockwise and press fuel tank cap. 'Click' sound ensures
cap is fully locked.
PRECAUTION
Don't attach metallic 'Key chain' as it may damage paint of
petrol tank cover.
1. : The Odometer shows the total distance that Odometer
the vehicle has covered. Odometer can not be reset to
'Zero'. Range 0 to 9.99.999 km.
2. Trip Meter : Trip 1 & Trip 2 shows the distance travelled
since it was last reset to zero. Rolls over to zero after
999.9 km & continue updating.
3. : Mode button used for changing the mode Mode Button
while selecting & setting Trip1, Trip2, ODD, INFO. Clock &
Service reminder.
4. : Set button used for setting Clock & Service Set Button
reminder. On pressing set button display in primary
speedometer scrolls.
5. : It indicates time in HH: MM (AM/PM)Digital Clock
6. : It will display gear position from 1 to 6. It Gear indication
will display 0 when vehicle is in neutral position.
• There is no fuel cock.
• Always maintain minimum 3 Liter Petrol in fuel tank.
• Do not use adulterated fuel or fuel additives as it will result in
rusting & clogging of Injector, Fuel pump module & catalytic
Convertor.
PRIMARY SPEEDOMETER DETAILS
SPEEDOMETER DISPLAY WILL WORK WHEN IGNITION SWITCH IS IN 'ON' POSITION.
1. Tachometer Dial : It shows engine speed in RPM.
2. ABS Indicator ( ) : With Ignition switch ON the ABS indicator
glows. When vehicle speed is more than 5 Km/hr, the ABS
indicator goes OFF, if this indicator glows while vehicle is running,
it means there is problem in ABS.
3. Hi Beam Indicator ( ) : When Headlight is 'ON' & Hi beam or
'PASS' is selected then Hi beam indicator will glow.
4. : When the transmission is in Neutral, Neutral Indicator (N)
Neutral indicator will glow - 'N' in primary speedometer & 0
will be displayed in secondary speedometer.
5. Malfunction Indicator ( ) : It glows whenever any abnormality
is noticed in functioning of Fl system components.
6. Turn Signal Indicator ( ) : When Turn signal switch is pushed
to Left or Right. Turn Signal Indicator - LH or RH will flash.
7. It remains continuously ON if Generic Alarm Indicator ( ):
alarm message = 1, it blinks if alarm messages are
more than 1.
8. It reminds rider to drive Engine RPM Limit Indicator ( ) :
in safe engine RPM.
Within initial 2000Kms running (RUNNING IN period)
• RPM limit indicator blinks @ 6700 to 7000 RPM
• RPM limit indicator continuously glows if RPM is>7000 .
Beyond 2000 kms running –
• RPM limit indicator blinks @ 9200 to 9500 RPM
• RPM limit indicator continuously glows if RPM is > 9500
9. : Bajaj logo flying 'B' glows with ignition 'ON' Bajaj Logo
10. : It shows approximate fuel level in Fuel Level Indicator
fuel tank.
11. ( ) Low Fuel Level Indicator :
Fuel bar = 1 - Bar 1 glows steady & low fuel symbol blinks
Fuel bar = < 1 - Bar 1 & low fuel symbol both blinks Fuel bar
= 2 - Low fuel symbol glows steady
12. : Vehicle speed will be displayed in digital form Speedometer
in km/h.
13. Alarm / information messages will be displayed on Primary
speedometer in Dot Matrix format.
RPM
LIMIT
TWIN CHANNEL ABS SYSTEM
INSTRUCTIONS
Never drive by disconnecting wheel speedo gear cable.
Incase, Malfunction indicator, ABS indicator, coolant
temperature indicator, low battery & low engine oil
pressure indicator glows in speedometer while driving ,
bring the vehicle to nearest BAL dealership for inspection
/ repair.
18
H
MOBILE CHARGER
Mobile charging socket is provided near Ignition switch as an OE fitment.
The charger socket has been provided with cap to protect charger socket from
dust & water entry. Always ensure charger cap is firmly closed on socket when
charger socket is not in use.
This charger can be used for charging mobile only in engine running condition
Please ensure charger socket cap is firmly closed on socket while washing of
vehicle and in the event of rain.
CAUTION:
Do not use mobile phone while driving . Momentary lapse in concentration might
result in an accident.
19
The mobile charger will supply output voltage only in engine running condition.
Customer to use suitable USB cable for mobile charging.
21
Produkspesifikasjoner
| Merke: | Bajaj |
| Kategori: | Motor |
| Modell: | Dominar 400 |
Trenger du hjelp?
Hvis du trenger hjelp med Bajaj Dominar 400 still et spørsmål nedenfor, og andre brukere vil svare deg
Motor Bajaj Manualer
31 Desember 2025
31 Desember 2025
31 Desember 2025
Motor Manualer
- Motor Yamaha
- Motor Husqvarna
- Motor BodyCraft
- Motor Sherco
- Motor Honda
- Motor TVS
- Motor Indian
- Motor GasGas
- Motor Hyosung
- Motor Triumph
- Motor Mash
- Motor Reebok
- Motor Juki
- Motor Hero
Nyeste Motor Manualer
17 Februar 2025
16 Februar 2025
16 Februar 2025
16 Februar 2025
15 Februar 2025
15 Januar 2025
13 Januar 2025
9 Januar 2025
9 Januar 2025
8 Januar 2025
