Installation and operation manual
Human Comfort Interface English
Installation and operation manual
Human Comfort Interface
BRC1HHDAW
BRC1HHDAS
BRC1HHDAK
Table of contents
Installation and operation manual
2
BRC1HHDAW + BRC1HHDAS + BRC1HHDAK
Human Comfort Interface
4P534400-1B – 2021.06
Table of contents
1 General safety precautions 2
1.1 For the user ............................................................................... 2
1.2 For the installer.......................................................................... 2
2 About this document 3
For the user 4
3 User interface: Overview 4
3.1 Buttons ...................................................................................... 4
3.2 Status icons............................................................................... 4
3.3 Status indicator.......................................................................... 4
4 Operation 4
4.1 Basic usage............................................................................... 4
4.1.1 Home screen............................................................... 4
4.1.2 Operation screens....................................................... 5
4.1.3 Main menu .................................................................. 5
4.2 Space heating/cooling control ................................................... 5
4.2.1 To turn ON/OFF space heating/cooling operation ...... 5
4.2.2 To change the room temperature ............................... 5
4.2.3 To change the space operation mode ........................ 6
4.3 Domestic hot water control ........................................................ 6
4.3.1 To turn ON/OFF domestic hot water operation........... 6
4.3.2 To change the domestic hot water temperature ......... 6
4.3.3 Using DHW powerful operation................................... 6
4.4 Advanced usage........................................................................ 7
5 Maintenance and service 7
5.1 Overview: Maintenance and service ......................................... 7
6 Troubleshooting 7
6.1 Overview: Troubleshooting........................................................ 7
For the installer 7
7 About the box 7
7.1 To unpack the user interface..................................................... 7
8 Preparation 7
8.1 Wiring requirements .................................................................. 7
9 Installation 7
9.1 Mounting the user interface ....................................................... 7
9.1.1 To mount the user interface........................................ 8
9.2 Connecting the electrical wiring................................................. 8
9.2.1 To connect the electrical wiring................................... 8
9.3 Closing the user interface.......................................................... 9
9.3.1 To close the user interface.......................................... 9
10 Starting up the system 9
11 Maintenance 9
11.1 Maintenance safety precautions................................................ 9
11.2 To clean the user interface........................................................ 9
1 General safety precautions
Please read these general safety precautions carefully before
installing air conditioning equipment, and be sure to install the
equipment correctly.
Failure to follow these instructions properly may result in property
damage or personal injury, which may be serious depending on the
circumstances.
Meaning of warnings and symbols
These safety messages are used to attract your attention. The
meaning of each safety message is described below:
WARNING
Indicates a situation that could result in death or serious
injury.
CAUTION
Indicates a situation that could result in minor or moderate
injury.
DANGER
Indicates a situation that results in death or serious injury.
DANGER: RISK OF EXPLOSION
Indicates a situation that could result in explosion.
INFORMATION
Indicates useful tips or additional information.
NOTICE
Indicates a situation that could result in equipment or
property damage.
1.1 For the user
INFORMATION
Also see the operation manual delivered with the outdoor
and indoor unit.
WARNING
Do NOT play with the unit or its user interface. Accidental
operation by a child may result in impairment of bodily
functions and harm health.
WARNING
To prevent electric shocks or fire:
▪ Do NOT operate the user interface with wet hands.
▪ Do NOT disassemble the user interface and touch
interior parts. Contact your dealer.
▪ Do NOT modify or repair the user interface. Contact
your dealer.
▪ Do NOT relocate or reinstall the user interface by
yourself. Contact your dealer.
WARNING
Do NOT use flammable materials (e.g. hairspray or
insecticide) near the user interface.
NOTICE
To clean the user interface, do NOT use organic solvents,
such as paint thinner. damage,Possible consequence:
electrical shock, or fire.
1.2 For the installer
The precautions described in this document cover very important
topics, follow them carefully.
INFORMATION
This user interface is an option and cannot be used
standalone. It can ONLY be used in combination with a
main user interface. Also see the installation and operation
manual of the indoor and outdoor units.
2 About this document
Installation and operation manual
3
BRC1HHDAW + BRC1HHDAS + BRC1HHDAK
Human Comfort Interface
4P534400-1B – 2021.06
WARNING
Improper installation or attachment of equipment or
accessories could result in electrical shock, short-circuit,
leaks, fire or other damage to the equipment. ONLY use
accessories, optional equipment and spare parts made or
approved by Daikin.
WARNING
All field wiring and components MUST be installed by a
licensed electrician and MUST comply with the applicable
legislation.
NOTICE
The user interface MUST be mounted indoors.
NOTICE
When the user interface is used as room thermostat, select
an installation location where the average temperature in
the room can be detected.
Do NOT install the user interface in the following places:
▪ In places where it is exposed to direct sunlight.
▪ In places where it is near a heat source.
▪ In places that are affected by outside air or air draught due to e.g.
door opening/closing.
▪ In places where the display can easily get dirty.
▪ In places where there is NO easy access to the controls.
▪ In places with temperatures <–10°C and >50°C.
▪ In places where the relative humidity is >95%.
▪ In places where there is machinery that emits electromagnetic
waves. Electromagnetic waves may disturb the control system,
and cause malfunction of the equipment.
▪ In places where it may be exposed to water, or in generally moist
areas.
If you are NOT sure how to install or operate the unit, contact your
dealer.
After finishing installation:
▪ Conduct a trial operation to check for faults.
▪ Explain the user how to operate the user interface.
▪ Ask the user to store the manual for future reference.
INFORMATION
Consult your dealer regarding the relocation and
reinstallation of the user interface.
2 About this document
Target audience
Authorised installers + end users
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪Installation and operation manual:
▪ Installation instructions
▪ Basic operation instructions
▪ Format: Paper (in the box of the user interface)
▪Installer and user reference guide:
▪ Extended installation and operation information
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
▪Declaration of conformity:
▪ Hereby, Daikin Europe N.V. declares that the radio equipment
type BRC1HHDA is in compliance with the Directive 2014/53/
EU. The original declaration of conformity is available from the
BRC1HHDA product pages https://qr.daikin.eu/?
N=BRC1HHDW https://qr.daikin.eu/?N=BRC1HHDS
, , and
https://qr.daikin.eu/?N=BRC1HHDK.
▪ Format: Digital file from the product pages
(BRC1HHDAW)
(BRC1HHDAS)
(BRC1HHDAK)
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your dealer.
The original documentation is written in English. All other languages
are translations.
Technical engineering data
▪ A of the latest technical data is available on the regionalsubset
Daikin website (publicly accessible).
▪ The of latest technical data is available on the Daikinfull set
Business Portal (authentication required).
