Side 1/11

BL-550 | BL-650

INSTALLATION INSTRUCTIONS

INSTRUCTIONS D’INSTALLATION

INSTRUCCIONES DE INSTALACIÓN

安装说明

English

Important Product Information

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9. Protect the power cord from being walked on

or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the

apparatus.

10. Only use attachments/accessories specified by the

manufacturer.

11. Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination

to avoid injury from tip-over.

12. Unplug this apparatus during lightning storms or

when unused for long periods of time.

13. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or

plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does not

operate normally, or has been dropped.

Notes on Use

• Avoid high temperatures.

• Do not let foreign objects into the unit.

• Do not let insecticides, benzene, and thinner come

in contact with the unit.

• Never disassemble or modify the unit in any way.

• Naked flame sources such as lit candles should not

be placed on the unit.

• Do not sit or step on unit.

• Do not place unit in standing water.

Sound United, LLC

5541 Fermi Court

Carlsbad, CA 92008, USA

English

Conﬁguration

• Determine whether the system will operate in mono or stereo (see the example system connection diagrams in

Figure 3 and Figure 4 on the next page). In some applications, the listening positions will never be equidistant

from a left and right speaker, in which case mono may be the best option.

Recommended Spacing and Placement

• Minimum recommended distance between bollards: 8'; maximum recommended distance between bollards: 20'

• For optimal sound pressure levels, place the bollards as close as possible to the listening area.

• If using a subwoofer, refer to the manufacturer’s installation instructions for subwoofer placement details.

• For applications that require more bass, place the bollards and/or subwoofer near an acoustically reflective surface,

such as a wall or barrier, to reinforce the low frequencies.

• If possible, try placing the speakers in locations that minimize volume peaks and nulls throughout the outdoor

listening area.

• To avoid potential damage from landscapers, be mindful of where you mount the speakers. Locate the speakers

in an area that will not flood with standing

water and away from sprinklers.

Speaker Coverage Capabilities

• Each bollard speaker will cover a listening

area of approximately 50-150 square

feet. Make sure to use enough BL Series

bollards to provide adequate coverage

and volume. See the example layout in

Figure 1.

Creating Listening Areas

• For larger listening areas, surround the

area with the bollards equidistant from the

primary listening position, crisscrossing

or alternating the left and right channels.

For smaller listening areas, simply aim the

bollards in toward the listening position.

The Definitive Technology BL Series bollard speakers are engineered to deliver superb audio quality and durability in

residential and commercial outdoor landscape audio applications. The BL Series bollards provide a wide dispersion

pattern and a balanced frequency response. Pair the BL Series bollards with the Definitive Technology LS-100 subwoofer

for applications that require a higher bass response.

1. Introduction

Figure 1

3. Planning the Installation

Before installing the speakers, consider the following recommendations for optimizing the setup.

Ensure the following items are included in the box.

2. Box Contents

Waterproof

Wire Nut x2Bollard Speaker p3-x1 Skirt p3-x1 Softscape Spike p3-x3 Mounting Template

209.7

8.25

189.3

7.45

1. Use a level and t ape to secure the t emplate on the w all where you want to place the BL-550 landscape bollar d speaker.

Note: ensure the Listening Area is pointing in the desired direction.

2 . Use a sharp implem ent to make a small mar k wher e the mounting holes need to be drilled (see “MARK H ERE”). If you are

mounting the BL-550 to a surface using smal l screws ,markt he surface on the X symbols within the holes. If you ar e securing the

BL-550 with stakes or mounting it to a surface using lar ge screws or bolts, mark on the symbols within the keyhole slotes˜

3. After marking the mounting holes, rem ove the templat e and

align the BL-550 t o the corresponding marks.

4. Use the appropriate hardware for your surface ty pe (not included) and install the hardware as appropriate, securing the

speaker. Note: If you are unsure of what mounting hardware to use,

please consul t a professional.

1. Use a level and t ape to secur e the t emplate on the w all where

you want to place the BL-550 landscape bollar d speaker.

Note: ensure the Listening Area is pointing in the desired direction.

2. Use a sharp implement to make a small mark where the mounting holes need to be drilled (see “MARK HERE”). If you are

mounting the BL-550 to a surface using smal l screws,mar kt hesur face on the X sy mbols within the holes. If you are securing the

BL-550 with stakes or mounting it to a surface using large screws or bolts, mark on the symbols within the keyhole slotes˜

3. After marking the mounting holes, rem o ve the template and align the BL-550 to the corresponding marks.

4. Use the appropriate hardware for your surface type (not

included) and install the hardware as appropriate, securing the speaker.Note: If you are unsure of what mounting hardware to use,

please consult a professional.

1. Use a level and tape to secu re the t emplate on the wall where

you want to place the BL-650 landscape bollar d sp eaker.

Note: ensure the Listening Are a is pointing in the desi red direction.

2. Use a sharp implement to make a small mark where the

mounting holes need to be drilled (see “MA RK H ERE”). If you are mounting the BL-550 to a surf ace using smal l screws,m ark the

surf ace on the X symbols within the holes. If you ar e securing the BL-550 with stakes or mounting itto a surfac e using large screws

or bolts, mark on the symbols within the keyhole slotes ˜3. After marking the mounting holes, rem ove the templat e and

align the B L-650 to the corresponding marks.

4. Use the appropriate hardware for your sur face type (not included) and install the hardware as appropriate, securing the

speaker.Note: If you are unsure of wha t mounting hardware to use,

please consult a professional.

1. Use a level and tape t o secur e the template on the wall where you want to place the BL-550 landscape bollar d speaker.

Note: ensure the Listening Area is pointing in the desired direction.

2. Use a sharp implement to make a small mark where the mounting holes need to be drilled (see “MARK HERE”). If you are

mounting the BL-550 to a surface using smal l screws,mar k the surface on the X symbols within the holes. If you are securing the

BL-550 with stakes or mounting it to a surface using lar ge screws or bolts, mark on the ˜

symbols within the keyhole slotes

3. After marking the mounting holes, rem ove the templat e and align the BL-550 to the corresponding marks.

4. Use the appropriate hardware for your sur face type (not

included) and install the hardware as appropriate, securing the speaker.Note: If you are unsure of what mounting hardware to use,

please consult a professional.
