Side 1/2
1
Model
GT-DB-02w / GT-DB-02b
In the box
• Transmitter (doorbell, inscribable), incl. mounting
plate, 2 wall plugs, 2 screws and double-sided ad-
hesive foam.
• Receiver (mains connection plug)
• Operating instructions incl. warranty
Explanation of symbols
This symbol/signal word indicates a
hazard with a moderate risk which,
if it is not avoided, can result in fatal or serious injury.
This signal symbol/word warns of
possible material damage.
This symbol gives you additional useful informa-
tion on the layout or operation of the product.
Class III: appliances in this class are operated
with safety extra-low voltage (SELV).
Class II: increased or double insulation be-
tween active and touchable parts. Mostly
without connection to the protective conductor.
IPX4 Protection against splashing water.
IP20:
Protected against penetration by solid objects
with a diameter >12.5 mm. No protection against water.
Transmitter: suitable for indoor and outdoor
use.
Receiver: only for use indoors
Alternating current
RCM (Regulatory Compliance Mark)
The product complies with the requirements
of the applicable Australian standards.
Application notes and warnings
Before starting up the product, please read
and follow the instructions, particularly
the safety and installation instructions.
Keep the instructions for reference later and pass
them on to any subsequent owner.
The Transmitter (doorbell) is suitable for indoor and
outdoor use.
The Receiver (mains connection plug) is only suita-
ble for indoor use.
The product is designed for private use.
Metal objects can have a negative effect on
the range between the Transmitter and Re-
ceiver. Do not position the Transmitter and Receiver
on or near metal objects.
Risk of suffocation! Children play-
ing with the packaging fi lm can
become entangled in it and choke.
This electrically operated product is not a toy. Do not let
children play with the product or the packaging fi lm.
Keep the product out of reach of children.
This product can be used by children from age 8 and
by persons with reduced physical, sensory, or men-
tal skills or lack of experience and/or knowledge, if
they are supervised or have been instructed in safe
use of the product and have understood the result-
ing dangers.
Cleaning and maintenance may not be carried out
by unsupervised children.
Risk of electric shock! Do not op-
erate the Receiver (mains connec-
tion plug) with wet hands.
Keep the Receiver away from contact with mois-
ture/water or any other liquid.
Checking the package contents
Risk of electric shock! Do not make
any technical changes to the
Transmitter and Receiver. Do not open the hous-
ing and do not insert any objects into the inside of
the housing
If parts are visibly damaged, stop using the prod-
uct to prevent hazards.
Remove all parts from the packaging and check that
the contents are complete and undamaged. Contact
the service address given on the guarantee card if
necessary.
Dispose of the packaging material in an environ-
mentally friendly way.
Starting up
Fire risk!
Do not cover the connected Receiver (mains con-
nection plug), e.g. with fabric, paper or plastic.
Risk of damage!
Only connect the Receiver (mains connection plug)
if the mains voltage of the power socket matches the
data on the nameplate.
Connect the Receiver only to an easily accessible
socket, so that you can disconnect it from the mains
quickly in the event of a fault.
Installation
Before you install the Transmitter in the planned
place, make sure that it functions properly. The
Transmitter and Receiver must be connected fi rst if
necessary (radio connection).
- Connect the Receiver to the planned power socket.
- Press the Bell button on the Transmitter:
No signal at the receiver? –> Keep Melody
button 1 pressed for approx. 3 seconds until
2 short sounds can be heard.
Press the Bell button 2 briefl y within 30 seconds.
- Position the Transmitter in the planned place and
press the Bell button to make sure that the Re-
ceiver receives the signal from the transmitter.
The distance may be too large, or the signal
is disrupted by metal objects. In this case,
you can remove the reception by moving the
Transmitter or Receiver.
1
2
Disconnecting the connection between the Re-
ceiver and Transmitter
If you want to disconnect the Transmitter (door-
bell) from the Receiver, press the Melody but-
ton 1 for approx. 10 seconds. After 2 short sounds can
be heard for the second time, the radio connection no
longer exists.
Attaching the Transmitter with the adhesive foam
With the help of the foam, the Transmitter
(doorbell) can be connected horizontally or
vertically to a smooth surface. It can then be removed
from the mounting plate, if necessary, by pushing in
the direction of the labelling fi eld.
Attaching the Transmitter with wall plugs and
screws
Risk of electric shock! Before install-
ing, make sure that there are no wa-
ter pipes or power cables in the area of the drillholes!
Risk of damage!
DIY skills and tools are required for the permanent in-
stallation. Contact an experienced fi tter if necessary.
-
Push the mounting plate in the direction of the Bell
button to remove it from the back of the Transmitter.
- Use a screwdriver, for example, to clear the screw
holes provided.
- Position the mounting plate in the planned place
and mark the drilling points.
- Use a 6 mm drill bit to drill holes 35 mm deep.
- Insert the wall plugs and screw on the mounting
plate.
Use the elongated screw retainer of the mount-
ing plate to align the plate horizontally or verti-
cally before tightening the screw if the drilled holes
are not exactly horizontal or vertical.
- Position the Transmitter on the mounting plate
and push it in the direction of the Bell button.
Kinetic wireless doorbell
GT-DB-02wGT-DB-02b
User Manual
MODEL:
GT-DB-02w, GT-DB-02b
831615
02/2024
The Transmitter name-
plate can be inscribed. To
do so, unhook the protective
fi lm fi rst.
- Press the fi lm down slightly
with your fi ngernail or a suit-
able object and remove it.
- Foil can be reinserted accord-
ingly.
Operation
The Receiver has 18 melo-
dies to choose from as a signal sound and a sig-
nal light. The sound volume can be set to 4 levels.
3
1
4
Setting the volume
Press the Volume button 3 repeatedly to increase the
signal volume in 4 levels.
Setting the melody
Press the Melody button 1 repeatedly to select the re-
quired signal melody (18 melodies).
Setting the signal type
You can choose between the following with the posi-
tion of the selector switch 4:
- melody signal only (switch in top position),
- light signal only (switch in middle position),
- melody with light signal (switch in bottom position).
Cleaning and Storage
Before cleaning, always discon-
nect the mains connection plug
from the mains! Risk of electric shock!
Risk of damage!
Do not use abrasive, solvent, or sharp-edged tools!
Clean the product with a slightly dampened cloth
and a mild washing up liquid.
Leave the product to properly dry and ideally store it
in its original packaging.
Disposal
Disposing of the packaging
Dispose of the packaging separated into single type ma-
terials. Dispose of cardboard and carton as waste paper
and foils via the recyclable material collection service.
Disposing of old devices
Old devices must not be disposed of with
household waste!
Should the device no longer be capable of being used
at some point in time, dispose of it in accordance with
the regulations in force in your city or state.
Please ensure your recycling information applies to
the local regulations.
Technical data
Receiver (mains connection plug)
(Class II, suitable for indoors)
IP20
Input: 220-240 V~, 50 Hz
Range: approx. 100 m (clear view)
Frequency: 433,05 - 434,79 MHz
Transmitter (doorbell)
(Class III, suitable for indoors and outdoors)
IPX4
Range: approx. 100 m (clear view)
Frequency: 433,05 - 434,79 MHz
Signal strength: max. 10 dBmv
Design and technical changes are possible, as we
continuously develop and improve our products.
These operating instructions can also be downloaded
from our website www.gt-support.de as a PDF fi le.
ALDI guarantees that our exclusive brand products are developed to our stringent quality specifications. If you
are not entirely satisfied with this product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our after sales support by calling the
supplier’s Customer Service Hotline.
AU
Made in China
DELTA® is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
Kinetic wireless doorbell
Repair and Refurbished Goods
or Parts Notice
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/
TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION
Unfortunately, from time to time, faulty products are manufactured
which need to be returned to the Supplier for repair.
Please be aware that if your product is capable of retaining user-
generated data (such as files stored on a computer hard drive,
telephone numbers stored on a mobile telephone, songs stored on a
portable media player, games saved on a games console or files stored
on a USB memory stick) during the process of repair, some or all of your
stored data may be lost.
We recommend you save this data elsewhere prior to sending the
product for repair.
You should also be aware that rather than repairing goods, we
may replace them with refurbished goods of the same type or use
refurbished parts in the repair process.
Please be assured though, refurbished parts or replacements are
only used where they meet ALDI’s stringent quality specifications.
If at any time you feel your repair is being handled unsatisfactorily, you
may escalate your complaint. Please telephone us on 1800 269 981 or
write to us at:
Wunsche (Australia) Pty Ltd
c/o Install and Fix Solutions Pty Ltd
Unit 1, 9 Kingsbury Street Brendale, Queensland 4500
AUSTRALIA
Hotline: 1800 269 981
Operating hours: 8.30-6.00 pm Monday – Friday
support@wunsche.com.au
YEAR
WARRANTY
YEAR
WARRANTY
1 1
AFTER SALES SUPPORT AFTER SALES SUPPORT
support@wunsche.com.au support@wunsche.com.au1800 269 981 1800 269 981
Kinetic wireless doorbell
Warranty Details
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/
TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION
The product is guaranteed to be free from defects in workmanship and
parts for a period of 12 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benefits conferred
by this warranty are in addition to all rights and remedies in respect
of the product that the consumer has under the Competition and
Consumer Act 2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Produkspesifikasjoner
| Merke: | Delta |
| Kategori: | Ringeklokke |
| Modell: | GT-DB-01b |
Trenger du hjelp?
Hvis du trenger hjelp med Delta GT-DB-01b still et spørsmål nedenfor, og andre brukere vil svare deg
Ringeklokke Delta Manualer
16 Oktober 2024
Ringeklokke Manualer
- Ringeklokke Arendo
- Ringeklokke Kogan
- Ringeklokke Eufy
- Ringeklokke Lorex
- Ringeklokke Bearware
- Ringeklokke Cata
- Ringeklokke Arlo
- Ringeklokke Imou
- Ringeklokke Elektrobock
- Ringeklokke Extel
- Ringeklokke NuTone
Nyeste Ringeklokke Manualer
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
24 Oktober 2024
21 Oktober 2024
21 Oktober 2024
20 Oktober 2024
