Side 1/36
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-800-4-D WALTe
Instruction Manual
Guide Dutilisation
Manual de instrucciones
DWE46125
5" (125 mm) Cutting Shroud
Coiffe de coupe 125 mm (5 po)
Cubierta de Corte de 125 mm (5")
DWE46127
7" (180 mm) Cutting Shroud
Coiffe de coupe 180 mm (7 po)
Cubierta de Corte de 180 mm (7")
English (original instructions) 1
Français (traduction de la notice d’instructions originale) 10
Español (traducido de las instrucciones originales) 20
English
1
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: will Indicates an imminently hazardous situation which, if not avoided, result in death or seriousinjury.
WARNING: could Indicates a potentially hazardous situation which, if not avoided, result in death or seriousinjury.
CAUTION: may Indicates a potentially hazardous situation which, if not avoided, result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: may propertydamage Indicates a practice which, if not avoided, not related to personal injury result in .
1 Swiveling dust port
2 Collar screw
3 Metal base
4 Depth of cut adjustor
5 Depth of cut adjustment knob
6 Removable guiding wheels
7 Front guard button
8 Side guard button
9 Upper guard
10 Lower guard
11 Short locking flange (silver)
(DWE46125 only)
12 Short backing flange (silver)
(DWE46125 only)
13 Long locking flange (black)
14 Long backing flange (black)
15 Inner spacer (DCG460 only)
16 Outer flange (DCG460 only)
17 Collar (DCG440 only)
18 Inner spacer (DCG440 only)
19 Outer flange (DCG440 only)
Fig. A
7
2
1
6
8
5
3
9
10
6
4
11
12
13
14
15
16
17
18
19
