Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modifications reserved.
File: \\aa-fas-2\office\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4010191_11012.doc
Erstelldatum/create date: 07.03.2013 10:04:00Aktualisiert/up dated: 05.03.2014
TE-AC 400/100/10 D
Air Compressor
Art.
-
N
o
. 40.
101.91
Features
Metal filter pressure reducer with separator for
condensation water
High running time
2 cylinder air compressor
Belt drive
100 litre tank
Pressure switch
Pressure gauge and quick-release coupling for
unregulated tank pressure
1 pressure gauge and 2 quick-release couplings
for regulated working pressure
Non-return valve
Safety valve
2 guide rollers and 2 large wheels
10 years warranty against rusting through of the
tank
Technical Data
Mains: 400 V 3~ 50 Hz 3-phase
Power: 2.2 kW (3 HP)
Idle speed: 1,060 rpm
Intake capacity: 400 l / min
Output power: at 0 bar: 313 l/min
at 4 bar: 281 l/min
at 7 bar: 257 l/min
Tank capacity (liters): 100 l
Operating pressure: max. 10 bar
No. of cylinders: 2
Product weight: 64.0 kg
Logistic Data
Net weight: 64.0 kg
Gross weight: 73.0 kg
Packing dimensions: 1,010 x 410 x 895 mm
Bar Code: 4006825 593136
Sales Unit: 1 pc
The 2 cylinders, the powerful 400 volt engine and the belt drive care for a high intake capacity. The 10 bar of the large 100
litre vessel allows a variety application spectrum and by using of highgrade components a very long runtime is secured. By
quick couplings the vessel pressure or a lower regulated working pressure can be taken out. For the regulated working
pressure 2 quick couplings are available. Due to large wheels and guide rollers the compressor is mobile.
