Side 1/7
Pedestal with drawer
Installation InstructionAccessories
EN
595 mm
1000 mm
535 mm
305 mm
10x2x 2x 2x
1x
(D)
(A) (B) (C)
(E)
2x
(F)
Safety Information Product & Accessories
Information
Dimension
Do not stack a dryer on top of washing
machine if using a pedestal.
WARNING! Do not install it alone.
WARNING! Before proceeding
with installation, make sure there
is enough room.
2
WARNING!
(A)
(B)
(C)
(D)
(E)
(F)
2 front metal brackets.
2 rear brackets for washing machine.
2 rear brackets for tumble dryer.
10 screws. (For tumble dryer
8 screws will be sufficient.)
1 spanner to adjust the levelling feet.
2 additional containers
(where included)
Accessories
1.
2.
3.
3
Installation Procedure
Remove the pedestal and all
accessories form the box.
Make sure that the rear rubber
feet are mounted.
Adjust the front adjustable feet to
make the pedestal stable.
4. If you install the pedestal under a
brand new appliance, unpack the
appliance as indicated in the
instructions supplied with it and
then proceed with step 6.
7. For washing machine. Gently lay
the washing machine on its
detergent dispenser side.
Lay it on cardboard or on a piece
of polystyrene to avoid scratching
the cabinet.
5. If the appliance is already
connected:
6. Screw the front brackets on the
pedestal.
Disconnect the mains plug from
the mains socket.
-
For washing machine. Close the
water tap .
-
For washing machine.
Disconnect the inlet hose(s) from
the water tap and let the water
flow out from the inlet hose(s)
and the drain hose and collect it
in a shallow basin.
-
For tumble dryer. Empty the
water container in a wash basin
or, if available, activate the direct
drain system to let the water flow
out.
-
