A S S E M B LY I N S T R U C T I O N S
Anthro Corporation® | 10450 SW Manhasset Dr. | Tualatin, OR 97062
Toll-free: 800.325.3841 | Fax: 800.325.0045 | email: sales@anthro.com | anthro.com
Outside the U.S. | Tel: 503.691.2556 | Fax: 503.691.2409
26" Extension Tube
for Zido® and POC-2
Rev B, August 2013
NOTE: The Zido cart is not included.
Product Part#
Zido Extension Tube ZET26SB
WELC O ME
Thank you for purchasing this
26" Extension Tube!
If you have any questions or if we
can help you in any way, please
contact us at 800.325.3841.
NOTE
A 7/32" drill bit and electric drill
are required for this assembly.
A 3-way wrench is supplied for
this assembly. If you have a 3/8"
wrench or socket, use that instead.
PAR TS L I S T
Before beginning assembly of your 26" Extension Tube,
please review the parts list to verify that your shipment is
complete.
2
Zido Extension Tube Quantity Part Number
01 Extension Tube 26" 1 500-1034-00
02 Nylock Nuts 4 325-5233-00
03 End Cap 1 175-5235-32
03
01
02
26" Extension Tube Assembly Instructions 3
STEP 1
Drill the Top
¡ Place the cart shelf upside down on a
non-marring surface that can stand to
have some holes drilled into it.
¡ Locate the Extension Tube hole array of four
1/8" holes.
¡ Drill through these holes with
the 7/32” drill bit.
¡ Complete your cart assembly.
STEP 2
Install the Extension Tube
¡ Align the Extension Tube with the holes on
the top of your cart. Make sure that the
vertical hole array on the Extension Tube
face the back of the cart.
¡ Slide the Extension Tube into place. Use the
3-way wrench (or your own 3/8" socket or
wrench) to secure with the four nylock nuts.
¡ Pop the End Cap into place.
CONGRATULATIONS! YOUR EXTENSION TUBE ASSEMBLY IS COMPLETE!
Ext Tube hole array
Nylock Nut 10-32
325-5233-00
Ext Tube hole array
Zido POC Cart 2
