Side 1/2

Berker GmbH & Co. KG, Zum Gunterstal, 66440 Blieskastel, Germany - + 49 6842 945 0 + 49 6842 945 4625 info@berker.de berker.comT F

Operating and

assembly instructions

8004 00 0x

Busapplicationunitﬂush-

mounted,system-/easylink

01.2023

(1)

(5)

(4)

(5)

(2)

(3)

(5)

(8)

(7) (6)

Safety instructions z

Electrical equipment may only be installed and

assembledbyqualiﬁedelectricians.Always

followtherelevantaccidentpreventionregulati-

ons.

Failuretocomplywiththeseinstallationinstruc-

tionsmayresultindamagetothedevice,ﬁreor

otherhazards.

Wheninstallingandlayingcables,alwayscomply

withtheapplicableregulationsandstandardsfor

SELVelectricalcircuits.

Duringrenovationwork,protectthedevicefrom

pollutionbypaint,wallpaperpaste,dustetc.The

devicecanbedamaged.

Theseinstructionsareanintegralcomponentof

theproductandmustberetainedbytheend

user.

Designandlayoutofthedevice

Figure 1: Front view

Figure 2: Rear view

(1) Illuminated programming button

(2) Mounting device for fastening clamps

(3) Dust protection cover for user interface (suitable

for labelling  eld sticker)

(4) User interface

(5) Screw holes for dismantling protection

(6) Plug-in interface for temperature sensor

(7) KNX bus connection terminal

(8) Attachment claws

Function

System information

This device is a product of KNX system and corre-

sponds to the KNX guidelines. Detailed specialised

knowledge obtained from KNX training courses

is required for comprehension. The planning, installa-

tion and commissioning are carried out with the help

of KNX-certi ed software.

systemlinkstart-up

The function of the device is software-dependent.

The software is to be taken from the product databa-

se. You can  nd the latest version of the product da-

tabase, technical descriptions as well as conversion

and additional support programmes on our website.

easylinkstart-up

The function of the device is con guration-depen-

dent. The con guration can also be done using

devices developed specially for simple setting and

start-up.

This type of con guration is only possible with

devices of the easy link system. easy link stands

for easy, visually supported start-up. Precon gured

standard functions are assigned to the in/outputs by

means of a service module.

Correct use

- Attaching application modules, e.g. push-button,

thermostat, to the KNX system

- Installation into wall box according to DIN 49073

Productcharacteristics

- Start-up and programming in S-mode and E-mode

- Localisation function by integrated buzzer (siren)

- Connection for external temperature sensor

- Integrated dust protection cover for protection of

the user interface

Information for electricians

Installation and electrical connection

DANGER!

Touchinglivepartsintheinstallation

environmentcanresultinanelectric

shock!

Anelectricshockcanbelethal!

Disconnecttheconnectingcables

beforeworkingonthedeviceand

coveralllivepartsinthearea!

Connectingandinstallingthedevice

Connect bus line via KNX bus terminal (7): red +,

black –.

Connect external temperature sensor via connec-

ting terminal (6) if necessary.

For mounting in a  ush-mounted wall box use

 xing claws (8) or in a hollow wall wall-box use

screws for  xing.

Mount the device into the wall box in the correct

position.

If no application module is mounted, close dust

protection cover for user interface.

6LE000469C

6LE000469C__80040001__BUSANKOPPLER-UP__GB__2021-03__manual_Arbeitsdatei.indd 1

6LE000469C__80040001__BUSANKOPPLER-UP__GB__2021-03__manual_Arbeitsdatei.indd 1 23.01.2023 12:33:51

23.01.2023 12:33:51

Berker GmbH & Co. KG, Zum Gunterstal, 66440 Blieskastel, Germany + 49 6842 945 0 + 49 6842 945 4625 info@berker.de berker.comT F

01.2023

Start-up z

systemlink-Loadingthephysicaladdressand

applicationsoftware

The device is mounted and connected to the KNX

bus. Application module is not mounted. The pro-

gramming button and LED are accessible.

The physical address is only ever assigned for

one device. Only one device can ever be in pro-

gramming mode.

Switch on bus voltage.

Press programming button (1).

The button lights up.

If the button does not light up, no bus voltage is

present.

Load the physical address into the device.

The programming LED goes out.

Load application software into the device.

Note the physical address on the bus application

unit (3) and on the associated application module.

The application software of the application module

can be fully loaded into the bus application unit.

The bus application unit automatically detects the

application module after mounting.

easylink

Information on the system conguration can be taken

from the extensive description of the service module

easy link.

Appendix

Technicaldata

KNX Medium TP 1

Start-up mode system link, easy link

Rated voltage KNX DC 21 ... 32 V SELV

Connection mode KNX bus connecting terminal

Power consumption KNX max. 150 mW

(with application module)

User interface

output power max. 100 mW

Dimensions (W x H x D) 71 x 71 x 32 mm

Clamping range of attachment claws 52 … 70 mm

Degree of protection IP20

Protection class III

Operating temperature -5 … +45 °C

Storage/transport temperature -20 … +70 °C

Troubleshooting

Bus operation is not possible

Cause: Bus voltage is not present.

Check bus connection terminals for correct

polarity.

Check bus voltage by briey pressing the pro-

gramming button (1), red LED lights up if bus

voltage is present.

Warranty

We reserve the right to make technical and formal

changes to the product in the interest of technical

progress.

Our products are under guarantee within the scope

of the statutory provisions.

If you have a warranty claim, please contact the

point of sale or ship the device postage free with a

description of the fault to the appropriate regional

representative.

6LE000469C__80040001__BUSANKOPPLER-UP__GB__2021-03__manual_Arbeitsdatei.indd 2

6LE000469C__80040001__BUSANKOPPLER-UP__GB__2021-03__manual_Arbeitsdatei.indd 2 23.01.2023 12:33:51

23.01.2023 12:33:51
