Side 1/8

HKS 2 LOUDSPEAKERS

HKS 2

LOUDSPEAKERS

OWNER’S MANUAL

Power for the Digital Revolution.

250 Crossways Park Drive, Woodbury, New York 11797

1.800.422.8027 (USA only) Fax: 516.682.3523

Part No. wi5176

SPEAKER PLACEMENT 3

SPEAKER PLACEMENT

2 INTRODUCTION

INTRODUCTION

2Introduction

3Speaker Placement

4Mounting Options

5Speaker Connections

5Connection Guide

5Configuring Your Receiver

or Processor

6Troubleshooting

7Specifications

Introduction

Thank you for purchasing the Harman Kardon

HKS 2 loudspeakers, with which you are

about to begin many years of listening enjoy-

ment. The HKS 2 has been custom-designed

to provide high-fidelity audio reproduction of

your favorite music and movie selections.

To obtain maximum enjoyment from your new

speakers, we urge you to take a few minutes

to read through this manual. This will ensure

that connections to your receiver or amplifier

are made properly. In addition, a few minutes

spent understanding the setup options will

enable you to take advantage of all the power

and refinement the HKS 2 is able to deliver.

If you have any questions about this product,

its installation or operation, please contact

your dealer, the best local source of information.

Features

The HKS 2 is a pair of identical, 2-way,

bass-reflex satellite speakers for use in the

left and right front speaker positions in a

two-channel stereo system; or they may

be used in a home theater system as

left/right front, surround, or surround

back channels.

Harman Kardon invented the high-fidelity

receiver almost fifty years ago. The

HKS 2 is a perfect complement to a

Harman Kardon receiver or any home

theater system.

■Matched Pair of Loudspeakers for

Use in Stereo, Multichannel or

Multiroom Applications

■Speakers Are Magnetically Shielded

for Flexible Placement Near Video

Monitors

■Four-Inch Driver in Bass-Reflex

Enclosure Features High-Output

1-Inch-Diameter Voice Coil

■One-Inch Balanced-Dome Tweeter

■High-Quality, 5-Way, Binding-Post

Speaker Terminals

■Removable Cloth Grille

■Elegant Cabinet Features Built-In,

2-Position Tilt for Aiming Output

Toward Listening Area

■Includes Wall-Mount Brackets and

Speaker Cables

Included

Two satellites for left/right front, surround,

or surround back channels

Two 40' speaker cables for connection

from receiver or amplifier to speakers

Two wall-mount brackets and eight screws

Surround Speakers

Surround Back Speakers

(7.1-Channel System)

Side Surround Speakers

5 – 6 ft.

Surround Back Speakers

(6.1-Channel System)

(place at least 4 feet apart)

When Used as Front Speakers

Front speakers should be placed the same

distance from each other as they are from

the listening position. They should be placed

at about the same height from the floor as

the listeners’ ears, or they may be angled

toward the listeners. The contoured design of

the HKS 2 speaker enclosure allows the

speaker to be placed on a lower shelf and

tilted upward toward the listener simply by

positioning the speaker back onto its tilted

surface.

When Used as Surround Speakers

For 5.1-channel applications, the two

surround speakers should be placed slightly

behind the listening position and, ideally,

should face each other and be at a level

higher than the listeners’ ears. If that is not

possible, they may be placed on a wall

behind the listening position, facing forward.

In 7.1-channel systems, place the side

surround speakers slightly behind the listening

position, as shown in the diagram to the left.

The surround back speakers should be

placed on the rear wall, facing forward, the

same distance apart as the main front speakers.

In 6.1-channel systems, you may use a pair

of HKS 2 speakers for the surround back

speakers in place of a single rear center

speaker. Using two speakers will provide a

more diffuse surround effect, and will also

increase the total sound output for the

surround back channel without overworking

any individual speaker. Place the two speak-

ers on the rear wall the same distance apart

as each speaker is from the listener, but at

least four feet apart.

The surround back speakers in a 6.1- or

7.1-channel system should be placed at the

same height as the surround speakers, about

5 to 6 feet above the floor.

The surround speakers should not call

attention to themselves. Experiment with their

placement until you hear a diffuse, ambient

sound accompanying the main-program

material heard in the front speakers.
