RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany
Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/
Visit us:
IB-DK2252AC
DisplayLink® Notebook DockingStation
with dual video output
Order Number
60797
EAN Code
4250078171331
Notebooks are much more practical than desktop PCs because of their portability - you can’t lug a desktop PC around between your home
and office. However, the limitation of the notebook is the screen size and often a lack of ports. Some notebooks come standard with only one
or two ports, one of which you need for charging. Many people prefer a mouse to the notebook’s trackpad or even a full-size keyboard. The
perfect setup would be a notebook for flexibility on the one hand and more ports on the other. The solution is an ICY BOX
®
DockingStation that
includes all these ports and to which you can connect your notebook with only one cable.
DisplayLink®
Driver installation required
before first use
www.displaylink.com / downloads
USB interfaces
6x USB 3.0 Type-A
with up to 5 Gbit / s
Multiple Display
LAN Port
RJ 45
Gigabit Ehernet
Supports 2x 4K@60 Hz
Host
Supports
USB Type-A,
USB Type-C®
Headset
3.5 mm combo jack
Plug and Display ™
RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany
Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/
Visit us:
FRONT VIE W VIEWRE AR
2x USB 3.0 Type-A (5 Gbit
/
s)
4x USB 3.0 Type A (5 Gbit
/
s)
Gigabit Ethernet
HDMI® 1 or DisplayPort™ 1
(DisplayLink®)
HDMI® 2 or DisplayPort™ 2
(DisplayLink®)
USB Type-B (Host)
Power supply interface
LED for power
Headset jack
SPECIAL FEATURES
The more, the better! Convective heat dissipation With one foot firmly on the ground
A DockingStation with a variety of
connections is a real added value
for a notebook that, after using the
charging port, may only have one
more port left for further applications.
With the IB-DK2252AC you can, for
example, connect a mouse, a full-si-
ze keyboard, you can connect one
or more larger external displays, con-
nect external hard drives or a printer
via USB ports and also enjoy stable
internet via the Ethernet port.
This DockingStation model is de-
signed for vertical positioning with
the help of a stand. Both enclosure
surfaces have ventilation slots that
allow convective heat dissipation
during operation: The heat genera-
ted during operation is dissipated
at the top, while cooler air is drawn
in from below through the vents and
cools the enclosure, and as a result
the heated air escapes again through
the top vents.
ICY BOX has a wide variety of dock
designs in its portfolio: flat, horizon-
tally lying models, those that are pla-
ced under a notebook in a wedge
shape for ergonomic working or tho-
se that are equipped with a stand like
this IB-DK2252AC. The stand gives
the device a secure hold - even when
plugging in and unplugging cables -
and in this case enables the upright
DockingStation to have effective
cooling qualities!
RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany
Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/
Visit us:
PACKING CONTENT
PRODUCT FEATURES
VIDEO CONNECTION AND DISPLAY OUTPUT MATRIX
SYSTEM REQUIREMENTS
Video matrix design (USB 3.0 DisplayLink®, maximum resolutions)
INPUTS (PLUGIN) DOCK OUTPUT
Number of displays HDMI® or DP 1 HDMI® or DP 2 Display 1 Display 2
Dual video output ✓ ✓ 3840x2160@60 Hz 3840x2160@60 Hz
Single video output ✓3840x2160@60 Hz
✓3840x2160@60 Hz
DP 1 DP 2 5120x2880@60 Hz
Supported Operating Systems Host compatibility
Windows® / macOS® / Chrome OS™ USB 3.0 Type-A / USB Type-C® / Thunderbolt™ 3 Type-C®
Colour Material LED CoolingUASP support Plug & Play Power supply
Black ABS, plastic, metal Yes Yes Power Passive External power supply AC
100-240 V; 50 / 60 Hz;
DC 20 V / 2 A; 40 W
▶1x IB-DK2252AC
▶1x Wall power supply with EU, UK, US adapter
▶1x USB Type-B to Type-A / Type-C® cable
▶1x Manual
HOST CONNECTION ON THE DOCKINGSTATION
Port Position Version & transfer rate Features
1x USB Type-B USB 3.0 (5 Gbit / s)Rear USB data transfer
