Installation Instructions
Inductive sensor
DC / unipolar
701223 / 02 02 / 2014
UK
2
Function and features
This sensor detects metals without contact and indicates their presence by
providing a switched signal. Nominal sensing range (Sn) see type label; (value
based on standard measurement with mild steel; a shorter sensing range for other
metals).
Installation
• Flushornon-flushinstallation(seetypelabel:Sn=XmmforXmmnf)
(→fig.1)
• Openspacearoundthesensingfacewhenmountedinmetal(→fig.2).
• Minimumdistancewhenseveralsensorsofthesametypearemounted
(→fig.3,4).
Sn = x mm f Sn = x mm nf
1
2
nn
n
3
UK
Sn = x mm f Sn = x mm nf
3
 
  
 
4
nn
Electrical connection
►Disconnectpowerbeforeconnecting
theproximityswitch;connection:
→fig.5).


• Forcableslongerthan30mandwiresgreaterthan0.5mm²thecableshould
belaidseparatelyfromsourcesofinterference(atadistanceofabout50cm)
or a screened cable should be used.
• Connecttheloadbeforeapplyingtheoperatingvoltage.
• Observethevaluesforcurrentratingandminimumloadcurrent.
• Ifcapacitiveloadsareused,ensurethatthepeakcurrentratingisnot
exceeded.
