Operating instructions
Diffuse reflection sensor
OL
704984 / 00 12 / 2010
UK
2
Contents
Function and features ����������������������������������������������������������������������������������������������3
Electrical connection������������������������������������������������������������������������������������������������3
Montage�������������������������������������������������������������������������������������������������������������������4
Commissioning ��������������������������������������������������������������������������������������������������������4
Setting of the sensitivity with stationary objects �����������������������������������������������������5
Setting of the sensitivity with moving objects ���������������������������������������������������������6
Setting of the maximum sensitivity ��������������������������������������������������������������������������7
Programming the output function ����������������������������������������������������������������������������7
Operation �����������������������������������������������������������������������������������������������������������������8
Function check output �����������������������������������������������������������������������������������������8
Maintenance ������������������������������������������������������������������������������������������������������������8
3
UK
Function and features
The diffuse reflection sensor detects objects and materials without contact and
indicates their presence by a switched signal�
Range (r): see type label (value referred to white paper 200 mm x 200 mm)�
Electrical connection
Isolate power, then connect the unit�
Connect the unit as follows:
DC PNP
Sensor with terminals Sensor with connector
L
L+
3
2
4
1
L
L+
3
2
4
1
DC NPN
Sensor with terminals Sensor with connector
L
L+
3
4
2
1
L
L+
3
4
2
1
AC/DC Relais
Sensor with terminals Sensor with connector



Insert a miniature fuse according to the technical data sheet, if specified�
