IFM SI6200 Bruksanvisning
IFM
Måleutstyr
SI6200
Les nedenfor 📖 manual på norsk for IFM SI6200 (17 sider) i kategorien Måleutstyr. Denne guiden var nyttig for 13 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/17

Operating instructions
Flow monitors
SI6000
SI6100
SI6200
11412705/00 06/2011
UK

2
Contents
1 Safety instructions 3 ������������������������������������������������������������������������
2 Functions and features 4 �����������������������������������������������������������������
2�1 Application area ������������������������������������������������������������������������ 4
2�2 Operating principle flow monitoring 4 �������������������������������������������
3 Installation 5 ������������������������������������������������������������������������������������
3�1 Installation location 5 ��������������������������������������������������������������������
3�2 Sources of interference in the pipe system 6 �������������������������������
3�3� Mounting operation 6 �������������������������������������������������������������������
4 Electrical connection��������������������������������������������������������������������� 8
5 Operating and display elements 8 ���������������������������������������������������
6 Set-up and settings for water�������������������������������������������������������� 9
6�1 Change the switch point (optional) 9 ��������������������������������������������
6�2 High flow adjustment (optional) 10 �����������������������������������������������
7 Additional settings (optional)������������������������������������������������������� 10
7�1 Low flow adjustment 10 ����������������������������������������������������������������
7�2 Configure the switching output 10 ������������������������������������������������
7�3 Restore the factory setting (reset) ������������������������������������������� 11
7�4 Lock / unlock the unit ��������������������������������������������������������������� 11
8 Error during adjustment �������������������������������������������������������������� 11
9 Operation 12 ������������������������������������������������������������������������������������
10 Maintenance 12 �����������������������������������������������������������������������������
11 Scale drawing 13 ���������������������������������������������������������������������������
12 Technical data ��������������������������������������������������������������������������� 16

3
UK
Preliminary note
• Aninstructionisindicatedby“►”:
Example:►Checkwhethertheunitoperatescorrectly.
• Areactiontotheactionisindicatedby">":
Example:>LED9lights.
1 Safety instructions
• Please read the product description prior to set-up of the unit� Ensure that the
product is suitable for your application without any restrictions�
• Improper or non-intended use may lead to malfunctions of the unit or to un-
wanted effects in your application�
• That is why installation, electrical connection, set-up, operation and mainte-
nance of the unit must only be carried out by qualified personnel authorised by
the machine operator�
ForthescopeofvaliditycULus:
The device shall be supplied from an isolating transformer having a secondary
Listed fuse rated as noted in the following table�
Overcurrent protection
Control-circuit wire size Maximum protective device rating
Ampere
AWG (mm2)
26 (0�13) 1
24 (0�20) 2
22 (0�32) 3
20 (0�52) 5
18 (0�82) 7
16 (1�3) 10
