Side 1/8
Owner’s Guide
• IL10
• IL30
• IL40
INTERLUDE™S SPEAKER YSTEMS
Infinity Interlude Series
The Interlude Series of loudspeakers continues Infinity’s
longstanding commitment to accurate sound reproduction.
Our proprietary Ceramic Metal Matrix Diaphragm
™(C.M.M.D.)
drivers, precision dividing networks and rigid, well-braced
enclosures combine to deliver uncompromised performance in
any stereo or multichannel home-theater system. In addition,
the IL10, IL30 and IL40 are magnetically shielded for safe
placement adjacent to a television.
If you suspect damage from transit, report it immediately to
your dealer. Keep the shipping carton and packing materials
for future use.
Stereo
Before deciding where to place your Interlude speakers, survey
your room and think about placement, keeping the following
points in mind:
•For best results, place the speakers 6'– 8' apart.
•Position each speaker so that the tweeter is at approximately
ear level.
•Generally, bass output will increase as the speaker is moved
closer to a wall or corner.
•Refer to “Home Theater” below if you also plan to use the
speakers for home-theater reproduction.
Home Theater
For front-channel use, place one speaker on the left and another
on the right along either side of the television monitor. Since the
speakers are magnetically shielded, you can place them without
worrying about the field distorting the TV picture.
For rear-channel use, place speakers on bookshelves or stands
alongside the listening position. Final placement depends on
room acoustics, availability of space and your listening
preference (Figure 2).
NOTE: An Infinity powered subwoofer will add impact and
realism to both music and film soundtracks. Contact your local
Infinity dealer for recommendations on subwoofer models for
your application.
PLACEMENT
UNPACKING THE SPEAKERS
F 1IGURE
Listening Position
Left
Channel
Right
Channel
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Innity
Subwoofer
(optional)
– Experiment with speaker placement to obtain the best
bass level and stereo imaging in your room.
F 2IGURE – This overhead view shows a typical home-theater plan.
2INTERLUDE
3
INTERLUDE
IL30 and IL40
Refer to Figure 3 as you perform the following steps:
1. Open each accessory pack and locate the following items:
four feet (with spike/round ends), four locking nuts, four
nylon domes and one wrench.
2. Lay each speaker on its side and locate the four threaded
holes on the bottom.
3. For carpets, screw the round end of a foot into each hole
and hand-tighten a nut onto each one. Leave a minimum of
5/8" of exposed spike. (On thicker carpets, you can increase
the length of exposed spike up to 1-1/8.") For hard-surface
oors, screw the spike end into each hole instead and leave
5/8" of round end exposed.
4. Carefully flip each speaker upright to sit on its feet.
5. If needed, adjust the feet so each speaker is level and then
tighten each nut with the enclosed wrench.To protect hard
surfaces (e.g., wood floors), slip a nylon dome onto each
round end.
INSTALLING FEET
Nylon Dome
(optional for
wood oors)
Locking Nut
HARD-SURFACE
FLOORS
CARPETED
FLOORS
Foot
round end
spike end
Bottom
of Speaker
5⁄8"
5⁄8" min.
11⁄8" max.
F 3IGURE – This cross section shows how to install a foot
onto the bottom of an IL30 or IL40 floorstanding speaker.
