Thank you for purchasing Infinity’s Kappa Series 65.1mb

midbass speakers. The 65.1mb was designed to fit the factory door

speaker locations of many vehicles which use a dash mounted midrange

in addition to a door-mounted woofer. The 65.1mb provides its best

performance when used to augment the low frequency output of a

component system or a small co-axial speaker.

We’ve organized this manual to make your installation as simple and

trouble-free as possible. Please read it thoroughly before proceeding.

Remember to keep your sales receipt with this manual in a safe place

so both are available for future reference.

A P PA

ERIES

65.1mb

I N S T R U C T I O N S

- 2 -

IMPORTANT: Installation of automotive stereo

components can require extensive experience

with a variety of mechanical and electrical proce-

dures. Although these instructions explain how to

install Kappa Series speakers in a general sense,

they do not show the exact installation methods

for your particular vehicle. If you do not feel you

have the experience, do not attempt the installa-

tion yourself, but instead ask your Authorized

Infinity Car Audio Dealer about professional

installation options.

WARNING: Playing loud music in an automotive

environment can permanently damage your hear-

ing, as well as hinder your ability to hear traffic.

The maximum volume levels achievable with

Infinity speakers, combined with high power

amplification, may exceed safe levels for

extended listening. We recommend using low

volume levels when driving. Infinity accepts

no liability for hearing loss, bodily injury, or

property damage as a result of use or misuse of

this product.

S PPEAKER LACEMENT

Kappa speakers are designed to be easily

installed in stock speaker locations. While mount-

ing your speakers in the original factory locations

will, in most cases, provide excellent sonic

results, the best sounding installations are a

result of adherence to a few basic rules.

• For the most spacious stereo image, place the

left and right speakers as far apart as possible.

• For enhanced center image, place the left and

right speakers so they are equidistant from the

listening position. If possible, try to place them

as far forward as possible.

• To ensure the best low-frequency output from

the 65.1mb, mount the speaker on a rigid, air-

tight baffle so that the sound emanating from

the frontward motion of the speaker cannot

contact the sound coming from the rearward

motion of the speaker and cause bass

cancellation.

INSTALLATION ARNINGS AND IPSW T

• Always wear protective eyewear when using

any tools.

• Turn off all audio systems and other electrical

devices before you start. Disconnect the (–) neg-

ative lead from your vehicle’s battery.

• Keep speakers in their package until final instal-

lation. When moving a speaker, always rest it

with the cone or dome facing up. Never use

force to install any speaker.

• Check clearances on both sides of a planned

mounting surface before drilling any holes or

installing any screws. Remember that the

screws can extend behind the surface.

• At the installation sites, locate and make a note

of all fuel lines, hydraulic brake lines, vacuum

lines and electrical wiring. Use extreme caution

when cutting or drilling in and around these

areas.

CAUTION: In some cars, fuel tanks may be

located directly beneath the rear deck. Check

for adequate speaker basket clearance before

considering this location!

• Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl, to

keep material from snagging in a drill bit or

saw.

• For door installations, check the clearance with

the windows throughout the range of the win-

dow’s travel, and verify that a mounted speaker

will not interfere with the window crank or

power window mechanism.

• If mounting speakers elsewhere, check for clear-

ance around rear-deck torsion bars, glove box

or other structural elements.

• Do not mount speakers where they will get wet.

Match Notch on

Speaker with

Notch on Trim Ring

Grille

Screen

Hole

Cutout

Grille

Trim Ring

INSTALLATION

Figure 1

Door Mounting with Grille. If mounting behind

factory grilles, omit the trim ring and the grille

screen.

- 3 -

A NOTE ON P HOWER ANDLING

Kappa speakers are designed to produce reason-

able volume levels with little amplifier power.

However, the addition of an amplifier to drive

your speakers and a subwoofer will enhance the

dynamic range of your system, and help over-

come the ambient noise in a moving vehicle.

Kappa speakers are designed to handle the

power of a dedicated amplifier driven at or below

its rated power. If an amplifier is driven far above

its rated power, the output signal will “clip”, and

the additional power present in a clipped signal

can damage any speaker. Distorted or “fuzzy”

sound from your speakers is an indication that

the amplifier has exceeded its rated power, and

you should reduce the volume level.

SPECIFICATIONS

65.1mbi

Type: 6" Midbass

Speaker Impedance: 4 ohms

Power Handling: 100W

Frequency Response: 40Hz ~ 2.5kHz

Sensitivity: 89Hz @ 2.83 V,

Mounting Depth, Drop-in: 2-7/16" (62 mm)

Cut-out Diameter: 5-1/8" (131 mm)

G CENERAL ARE

The loudspeaker grilles may be cleaned with a

slightly damp cloth. Do not use any cleaners or

solvents on the grilles or the speaker drivers.

DECLARATION OF CONFORMITY

We, Infinity Systems A/S

Kongevejen 194B

DK-3460 Birkerød

DENMARK

Steen Michaelsen

Infinity Systems A/S

Birkerød. DENMARK. 2/98

declare in own responsibility, that the products described in this owner’s manual are in compliance with technical standards:

EN 50 081-1/1992

EN 50 082-1/3.1995

Infinity Systems, Inc. • 250 Crossways Park Drive,

Woodbury, NY 11797 USA • (516) 496-3400 • FAX (516) 682-3583
