Side 1/20
KMFC65 | KMFC8
Manual del Propietario | Español
Gabinete de torre KICKER MARINE
Benutzerhandbuch | Deutsch
KICKER MARINE Can-Gehäuse
Manuel d’utilisation | Française
Boîtiers pour haut-parleurs verticaux
KICKER MARINE
KMFC
Loaded Marine Cans
Owner’s Manual
2
KICKER LOADED MARINE CANS
Owner’s Manual
Authorized KICKER Dealer:
Purchase Date:
Serial Number:
MODEL: KMFC65 | KMFC8
The KICKER KMFC Loaded Marine Cans are the perfect way to bring your music out into the marine or
powersports environment. The KMFC65 and KMFC8 come loaded with the KICKER KM65 and KM8 LED
speakers. The injection-molded ABS enclosures are UV treated, splash resistant, and weather resilient. Mount
the KMFC Loaded Marine Cans in your boat or get creative with a pair of them in the garage, patio, on your 4x4
or Side-by-Side, or in any other fl at-mounted application.
KMFC65
KMFC8
8-3/16"
[208mm]
11-1/4"
[285.7mm]
8-1/16"
[204.8mm]
1-5/16"
[33.3mm]
9-3/4"
[247.7mm]
1"
[25.4mm]
4-1/16"
[103.2mm]
9-1/16"
[230.2mm]
[77.8mm]
9-1/2"
[241.3mm]
8-5/8"
[219.1mm]
1/2"
[12.7mm]
7/8"
[22.2mm]
4-1/16"
[103.2mm]
8-15/16"
[227mm]
9-7/8"
[250.8mm]
11/16"
[17.5mm]
1-3/8"
[34.9mm]
4"
[101.6mm]
9-7/16"
[239.7mm]
8-3/4"
[222.2mm]
7"
[177mm]
8-1/8"
[206.4mm]
6-7/8"
[174.5mm]
9-11/16"
[245.6mm]
1-5/16"
[33.3mm]
8-1/2"
[215.9mm]
7-7/8"
[200mm]
1"
[25.4mm]
4-1/16"
[103.2mm]
8-1/4"
[209.6mm]
3-1/16"
[77.8mm]
7-3/8"
[187.3mm]
7-11/16"
[195.3mm]
4-1/16"
[103.2mm]
7/8"
[22.2mm]
1/2"
[12.7mm]
8-11/16"
[220.7mm]
7-1/2"
[190.5mm]
8-3/16"
[208mm]
4"
[101.6mm]
1-3/8"
[34.9mm]
11/16"
[17.5mm]
3
INSTALLATION
Step 1: Determine the location, placement, and mounting confi guration of the KMFC cans onto the
surface to which you are mounting. The KMFC may be mounted to a fl at surface at an angle of 0, ±5°,
or ±10°. Spreading the KMFC Loaded Marine Cans apart will provide better stereo performance, and is
usually preferable. When determining the best locations for mounting, be careful to look for obstacles or
obstructions that could complicate mounting the KMFC. Please keep in mind the routing of your speaker
wires as this can affect where you fi nally mount your cans. You will need to mark and drill three holes in
the mounting surface at 5/16” (8mm) in diameter; two for the mounting bolts, and one for wire routing.
Use the included mounting hardware as a template. The placement of the holes must line up with the fi nal
position of the mounting hardware; ie the holes should be about 90° from the direction the speakers will
be aimed and in-line with the wiring coming from the mounting bracket.
Step 2: Loosely thread the speaker and LED wires through the bottom of the mount base, mount wedge
(if applicable), mount gasket, mounting surface, and the mount plate that will be used to mount the KMFC.
The mounting hardware design provides versatility in vertical positioning to direct the speaker’s output to
the ideal listening position, with the following confi gurations available. The mount base and mount wedge
may be rotated 180° from the diagrams shown below to aim the speakers at the opposite angle.
0 Degrees 5 Degrees 10 Degrees
Model: KMFC65 KMFC8
Rated Impedance [Ω] 4 4
Sensitivity [1W, 1m] 90 92
Peak Power Handling [ Watts] 195 300
Continuous Power Handling [Watts RMS] 65 150
Enclosure Diameter/Width [in, cm] 7, 17.8 8-3/16, 20.8
Enclosure Depth [in, cm] 9-11/16, 24.6 11-1/4, 28.5
SPECIFICATIONS
IMPORTANT: You must apply a thin layer of the included anti-seize compound to threaded fasteners ALL
before installation to prevent galling, corrosion, seizing, and to improve gasket performance.
