Side 1/10
INSTRUCTION MANUAL
FRANÇAIS p. 21
ESPAÑOL pg. 11
Utility Bucket Light
• 20V Lithium Ion
• 2500 Lumens
• IP56
ENGLISH
BAT20UBL
BAT20UBL1
2
ENGLISH
GENERAL SPECIFICATIONS
Klein Tools BAT20 UBL is designed for professional worksite illumination. The clamp function
allows this tool to be used on most utility buckets. This provides optimal lighting while working.
• Spot: 900 Lumens - 8.5 hours
(approximate using 20V 4Ah battery)
• Flood: 1600 Lumens - 5 hours
(approximate using 20V 4Ah battery)
• Spot + Flood: 2500 Lumens - 3.5 hours
• Operating/Storage: Altitude: 6562 ft (2000m)
• Operating Temperature: -5F to 131F (-15C to 55C)
• Charging Temperature: 40F to 104F (4C to 40C)
• Storage temperature: 50F to 104F (10C to 40C)
Specifications subject to change.
APower Button ESecondary Light ISide Warning Label
BClamp Release FSecondary Light Switch JLight Hinge
CBucket Clamp GBucket Corner Mounting Surface KLight Pivot
DLight Head HBattery Compartment Latch
FEATURE DETAILS
NOTE: There are no user-serviceable parts inside.
A B
D
C
F
E
G
H
J
K
FEATURE DETAILS
The label on your tool may include the following symbols.
The symbols and their definitions are as follows:
V
Volts
A
Amperes
Hz
Hertz
W
Watts
or DC Direct Current
or AC Alternating Current
Class I Construction
(grounded)
or
AC/DC Alternating or Direct Current
Alternating Current no No Load Speed
Visible Radiation Earthing Terminal
Safety Alert Symbol
/
IP56
Do not use on or near live
electrical circuits Read Instructions
I
3
ENGLISH
DEFINITIONS
The definitions below describe the level of severity for each signal word:
DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which, if not
avoided, may result in property damage.
WARNINGS
• submerge in water.DO NOT
• Battery Compartment must be properly sealed and latched to achieve IP56 water &
foreign object ingress protection. Keep seal free of dirt, oil, sand or other material
that interferes with proper sealing. Failure to do so can result in risk or fire or
electrical shock.
• DO NOT use if the product or batteries are damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury.
• Keep out of reach of children, heat produced by light may cause harm.
• look directly into light when light is turned on. DO NOT
• direct light at persons or animals.DO NOT
SAFETY
2) Electrical Safety:
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
3) Personal Safety:
Do not overreach. Keep proper footing and balance at all times. This enables better
control of the bucket light in unexpected situations.
Important Safety Instructions for All Battery Packs
When ordering replacement battery packs, be sure to include the catalog number and
voltage.
The battery pack is not fully charged out of the carton. Before using the battery pack and
charger, read the safety instructions below and then follow charging procedures outlined.
• charge or use the battery pack in explosive atmospheres, such as in the DO NOT
presence of flammable liquids, gases or dust. Inserting or removing the battery
pack from the charger may ignite the dust or fumes.
• force the battery pack into the charger. Do not modify the battery pack in NEVER
any way to fit into a non-compatible charger as battery pack may rupture causing
serious personal injury. Consult the chart at the end of this manual for compatibility
of batteries and chargers.
• Charge the battery packs only in designated DeWalt chargers.
• splash or immerse in water or other liquids.DO NOT
• store or use the tool and battery pack in locations where the temperature DO NOT
may reach or exceed 104° F (40° C) (such as outside sheds or metal buildings in
summer). For best life store battery packs in a cool, dry location.
NOTE: Do not store the battery packs in a tool with the trigger switch locked on. Never
tape the trigger switch in the ON position.
WARNING: . Never attempt to open the battery pack for any reason. FIRE HAZARD
If the battery pack case is cracked or damaged, do not insert into the charger. Do
not crush, drop or damage the battery pack. Do not use a battery pack or charger
that has received a sharp blow, been dropped, run over or damaged in any way (e.g.,
pierced with a nail, hit with a hammer, stepped on). Damaged battery packs should be
returned to the service center for recycling.
SAFETY
To ensure safe operation and service of the bucket light, follow these instructions. Failure
to observe these warnings can result in electric shock, re, severe injury or death.
1) Work Area Safety:
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
