VIA GO3 Quick Start
P/N:
2900- 301786QS
Rev:
1
Scan to go to website
For Installer
This guide helps you install and use your VIA GO3 for the first time.
Go to t
https://www.kramerav.com/product/VIA GO3 o download the latest user manual and check if
firmware upgrades are available.
Step 1: Check what’s bin the ox
VIA GO3 Collaboration Device
1 VESA mounting bracket
1 Quick start guide
1 Power cords EU for US and
1 VESA screw set
Step 2: Get to know your VIA GO3
# ction Feature Fun
1
3 x 3.0 ConnectorUSB DEVICE
Connect to a USB device, for example, a USB speaker.
2
Power Button with LED
Press to power ON or turn OFF the device.
3
Power Connector
Connect to the 12V DC power supply.
4
1 x HDMI OUT Connector
Connect to an HDMI sink.
HDMI OUT 2 is unavailable.
5
RJ-45 Connector
Connect to a LAN (default mode).
Step 3: O3 Mount VIA G
VIA GO3 can be installed on a flat surface / , wall rear of a or rack mount monitor using the included VESA mounting bracket and
screw set:
M to ount VIA GO3 the Mounting Bracket
1. Attach the mounting bracket to the VIA GO3 with 2 screws.
This step is required for all options detailed below.
To Mount to a Flat Surface / Wall
To Mount to rear of monitor
To Mount to a Rack Mount
Secure the mounting bracket to a
flat surface / wall with dedicated
screws.
Secure the mounting bracket to VESA
holes located on rear of monitor.
Secure the mounting bracket(s) to the rack
mount with dedicated screws.
Step 4: Connect inputs and outputs
Always switch OFF the power on each device before connecting it to your VIA GO3.
1. . Connect a USB device
2. Connect an HDMI
display.
3. Connect to the LAN
(default mode).
If you wish to use a
Kramer active optical
pluggable HDMI cable
with your VIA GO3,
contact your local
Kramer office to assist
in purchasing the
correct cable.
To achieve specified extension distances, use the recommended Kramer cables
available at www.kramerav.com/product/VIA GO3.
Using third
- party cables may cause damage!
Step 5: Connect power
Connect the 12V DC power adapter to and plug it into the mains electricity.VIA GO3
Caution:
There are no operator serviceable parts inside the unit.
Caution:
The device is intended to be installed at a height of 2 meters or less.
Warning:
Use only the Kramer Electronics power adapter that is provided with the unit.
Warning:
Disconnect the power and unplug the unit from the wall before installing.
See www.KramerAV.com for updated safety information.
Step 6: Configure VIA GO3
VIA is generally pre installed and should work right out of the box once connected to the network.-
If different VIA settings need to be adjusted, logging into the Gateway web interface will be necessary to customize the
settings according to network, customer, or IT requirements.
To open the VIA Gateway web interface for configuration, network connectivity is required onnect the VIA box to the local . C
network to begin.
Login to VIA
1. Open Chrome browser and browse to the IP address GO3 .
2. Click Manage Gateway Settings . on the upper right corner
3. Enter the Username (default = su), Password (default = supass), Captcha and click Login.
4. After logging in, the VIA Dashboard will open.
