Kramer VS-48HDxl Bruksanvisning

Les nedenfor 📖 manual på norsk for Kramer VS-48HDxl (32 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 5 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Side 1/32
Kramer Electronics, Ltd.
USER MANUAL
Model:
VS-48HDxl
3G HD/SD SDI 4x8 Matrix Switcher
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 4
4.1
Using the IR Transmitter 8
5
Installing the VS-48HDxl in a Rack 9
6
Connecting the VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 10
6.1
Connecting the VS-48HDxl in the Dual-Link Mode 12
6.2
Working Mode Setting 13
6.3
Dipswitch Settings 14
6.3.1
Setting the Setup Dipswitches 14
6.4
Controlling via RS-232 (for example, using a PC) 15
6.5
Controlling via the RS-485 Port 16
6.6
Factory Reset 16
6.7
Switching Genlocked Video Signals 17
6.8
Controlling via ETHERNET 17
6.8.1
Connecting the ETHERNET Port directly to a PC (Crossover Cable) 17
6.8.2
Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 19
6.8.3
Configuring the Ethernet Port 19
6.9
Controlling via the REMOTE Connector 19
7
Operating the VS-48HDxl 20
7.1
Switching OUT-IN Combinations 20
7.1.1
Switch OUT-IN Combinations 20
7.1.2
Switch OUT-IN Combinations in the Dual-Link Mode 21
7.2
Confirming Settings 21
7.2.1
Toggling between the AT ONCE and CONFIRM Modes 22
7.2.2
Confirming a Switching Action 22
7.3
Storing/Recalling Input/Output Configurations 22
7.3.1
Storing an Input/Output Configuration 22
7.3.2
Recalling an Input/Output Configuration 23
7.4
Locking the Front Panel 23
8
Technical Specifications 24
9
Table of Hex Codes for Serial Communication 24
10
Kramer Protocol 2000 25
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Contents
ii
Figures
Figure 1: VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 5
Figure 2: Connecting the VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 11
Figure 3: Connecting the Dual-Link VS-48HDxl 3G HD/SD-SDI 4x8 Matrix Switcher 13
Figure 4: VS-48HDxl SETUP Dipswitches 14
Figure 5: Connecting a PC without using a Null-modem Adapter 15
Figure 6: Controlling via RS-485 (for example, using an RC-3000) 16
Figure 7: Local Area Connection Properties Window 18
Figure 8: Internet Protocol (TCP/IP) Properties Window 18
Figure 9: Using the Remote Connector 19
Tables
Table 1: Front Panel VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 6
Table 2: Rear Panel VS-48HDxl 3G HD/SD SDI 4x8 Matrix Switcher 7
Table 3: Machine # Dipswitch Settings 14
Table 4: Technical Specifications of the VS-48HDxl 24
Table 5: VS-48HDxl Hex Codes for Switching via RS-232/RS-485 24
Table 6: Protocol Definitions 25
Table 7: Instruction Codes for Protocol 2000 26
