Side 1/29
© LINDY Group - SECOND EDITION
(August 2023)
USB 3.2 Gen 2x2 Dual M.2 NVMe SSD
Enclosure with Clone Feature
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
Manual de Usuario Español
No. 43382
lindy.com
User Manual English
Safety Instructions
! WARNING !
Please read the following safety information carefully and always keep this document with
the product.
Failure to follow these precautions can result in serious injuries or death from electric
shock, fire or damage to the product.
Touching the internal components or a damaged cable may cause electric shock, which
may result in death.
This device is a switching type power supply and can work with supply voltages in the range 100 - 240
VAC For worldwide usability four different AC adapters are enclosed: Euro type, UK type, US/Japan type
and Australia/New Zealand type. Use the appropriate AC adapter as shown in the picture and ensure it
is firmly secured in place and does not detach by pulling before installing into a power socket.
To reduce risk of fire, electric shocks or damage:
Do not open the product nor its power supply. There are no user serviceable parts inside.
Only qualified servicing personnel may carry out any repairs or maintenance.
Never use damaged cables.
Do not expose the product to water or places of moisture.
Do not use this product outdoors it is intended for indoor use only.
Do not place the product near direct heat sources. Always place it in a well-ventilated place.
Do not place heavy items on the product or the cables.
Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket
Instructions for Use of Power Supply
Attach the required country adapter to the plug:
Place the country adapter on the power supply unit so that the 2 lugs on the lower end of the adapter fit
into the corresponding recesses on the power supply unit. Then slide the adapter down until it clicks into
place.
To remove, push the button and slide the adapter upwards.
User Manual English
Introduction
Thank you for purchasing the USB 3.2 Gen 2x2 Dual M.2 NVMe SSD Enclosure. This product has been
designed to provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free
lifetime technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
The Lindy USB 3.2 Gen 2x2 Dual M.2 NVMe SSD Enclosure allows the user to install two PCIe/NVMe
based M.2 SSDs as an external drive to USB hosts like laptops or PCs. The additional Clone feature
enables duplicating M.2 NVMe SSDs - even without connection to a computer ("offline cloning"). Support
for the USB 3.2 Gen 2x2 standard guarantees SuperSpeed 20Gbps data transfer rates. UASP support
also ensures faster speeds for UASP enabled computers.
Package Contents
USB 3.2 Gen 2x2 Dual M.2 NVMe SSD Enclosure
0.25m USB 3.2 Gen 2x2 Type C to C cable
Multi-Country Power Supply 12VDC 2A with country adapters (EU, UK; US, AUS)
2x thermal conductive pad
2x thermal conductive plate
4x M.2 rubber plug
Lindy Manual
Specification
Interface: USB to 2x PCIe/NVMe M.2 SSD
Interface Standard: USB 3.2 Gen 2x2, PCIe 3.0 p3-x2
Supported Bandwidth: 20Gbps (USB), 32Gbps - each up to 16Gbps (PCI 3.0 x2)
Chipset: JMS586U
Compatibility: USB Type C equipped computers
Special Features: supports 42/60/80mm SSDs, UASP & TRIM, LED indicator for Clone process
Inputs: 1 x USB Type C (Female)
Outputs: 2 x PCIe based M.2 (Female), M key and B+M key
Power: 5.5/2.5mm DC socket
Product Dimensions WxDxH: 143x77x17.5mm (5.63x3.03x0.69in)
Housing Material: Aluminium and ABS
Net Weight: 0.174kg (0.38lb)
Operating Temperature: 5°C - 35°C (41°F - 95°F)
Storage Temperature: -10°C - 90°C (-14°F - 122°F)
Humidity: 10 - 90% RH (non-condensing)
