Side 1/4
Dolly for Video Tripods
with Dual-Angle Spiked Feet
Owner’s
Manual
DSF-132
Assembling the dolly:
Rotate the outside legs into position, and secure by
tightening the locking knob
1 . When collapsed, use
the handle 5 for transport.
Locking the wheels:
Use the brake tabs 3 to lock and unlock the wheels.
Mounting your tripod:
1. Remove your Magnus tripod’s rubber feet if
they’re attached. Then, fit the slot in the tripod’s
spiked feet onto the leg supports
2 . You may need
to adjust the tripod’s leg length or spreader angle
to properly fit the tripod feet into the leg supports.
2. Pull the locking straps 4 onto the notches on the
outer edges of the tripod feet.
Using Your DSF-132 Dolly
5 5
2
4
2
3
1
Dolly Components
Specifications
Working Footprint: 37 in. (94 cm)
Maximum Load: 132 lb. (59.9 kg)
Folded Length: 20 in. (50.8 cm)
Wheel Diameter: 4 in. (10.2 cm)
Images are for illustrative purposes only
