Side 1/8
I-00217 Rev D
THANK YOU
Thank you for purchasing the CAB-COOL Cabinet Cooler(s). Please read these instructions
thoroughly before installing / assembling this product.
PRODUCT FEATURES
- Extends equipment life
- Removes heat from smaller cabinets and entertainment centers
- Grille can be painted to match aesthetics of any environment
Page 2
3 3/16"
[80mm]
3 1/8"
[78mm]
1/2"
[13mm]
5 1/4" [133mm]
4 1/2"
[114mm]
1 5/16"
[32mm]
9/16"
[15mm]
SPECIFICATIONS
FAN UNIT
INLINE FAN CONTROL
MODEL
TOP VIEW
SIDE VIEW
1 1/2"
[37mm]
POWER
REQUIREMENTS CFM dBA @ 1 METER
CAB-COOL 12 VDC @ 120mA 20 24
INLINE FAN CONTROL OPERATION
- Jumper on two center pins (default location) fan will turn on at 87 and turn off at 85.
- Jumper on two left pins, fan will remain off.
- Jumper on two right pins, fan will remain on.
oo
CAB-COOL-2 12 VDC @ 240mA 40 27
Page 3
PARTS
FAN UNIT QTY
CAB-COOL 1
CAB-COOL-2 2
Please read instructions
before using this template.
TOOLS REQUIRED
- 3.5" Hole Saw
- 3/32" Drill Bit
- #2 Phillips Head Driver
WIRE TIE QTY
CAB-COOL 5
CAB-COOL-2 10
WIRE TIE MOUNT QTY
CAB-COOL 5
CAB-COOL-2 10
WOOD SCREW QTY
CAB-COOL 8 (2 Extra)
CAB-COOL-2 16 (4 Extra)
LOUVERED GUARD QTY
CAB-COOL 1
CAB-COOL-2 2
POWER SUPPLY QTY
CAB-COOL 1
CAB-COOL-2 1
INLINE FAN CONTROL QTY
CAB-COOL 1
CAB-COOL-2 1
FAN UNIT QTY
CAB-COOL 1
CAB-COOL-2 2
